  • Page 1 REG. DATE : 2019.12.10 REV.NO : 1.1 User Manual for DTS-5560KN PAGE : REV. DATE : 2020.04.22 User Manual for DTS-5560KN Appendix...

  • Page 2: Table Of Contents

    REV.NO : 1.1 REG. DATE : 2019.12.10 User Manual for DTS-5560KN PAGE : REV. DATE : 2020.04.22 Content Revision History ....................3 Recommended Use ....................4 1. Package Contents ..................5 2. Product Configuration ..................6 3. Interface Description..................7 4.

  • Page 3: Revision History

    REV.NO : 1.1 REG. DATE : 2019.12.10 User Manual for DTS-5560KN PAGE : REV. DATE : 2020.04.22 Change History of Revision Revision Date Contents of Revision Change Remark Release 19.12.10 Number of Touch Point 18 Page 20.03.12 10 Points Multi-Touch -> 40 Points Multi-Touch...

  • Page 4: Recommended Use

    REV.NO : 1.1 REG. DATE : 2019.12.10 User Manual for DTS-5560KN PAGE : REV. DATE : 2020.04.22 Recommended Use FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE FOLLOWING WHEN SETTING UP AND USING THE TOUCH SCREEN MONITOR. • DO NOT OPEN THE MONITOR.

  • Page 5: Package Contents

    REV.NO : 1.1 REG. DATE : 2019.12.10 User Manual for DTS-5560KN PAGE : REV. DATE : 2020.04.22 Thank you for your selection of 4K Touch Screen Display Monitor Please take a few minutes to read this User’s manual for the best performance of this monitor.

  • Page 6: Product Configuration

    REV.NO : 1.1 REG. DATE : 2019.12.10 User Manual for DTS-5560KN PAGE : REV. DATE : 2020.04.22 2. Product Configuration OSD Button ( Attached page 8) Interface Terminal ( Attached page 7) Note ) Actual Touch Screen Monitor may differ from those in this user's drawing...

  • Page 7: Interface Description

    REV.NO : 1.1 REG. DATE : 2019.12.10 User Manual for DTS-5560KN PAGE : REV. DATE : 2020.04.22 3. Interface Description HDMI1 HDMI2 Power Switch AC-Inlet (Touch) Name Description AC-Inlet • AC input terminal : 100V~240V ( 50hz~60hz) Power Switch • Power On/Off Switch HP Out •...

  • Page 8: Osd Control Board Description

    REV.NO : 1.1 REG. DATE : 2019.12.10 User Manual for DTS-5560KN PAGE : REV. DATE : 2020.04.22 4. OSD Control Board Description 4.1 OSD Interface Description IR Sensor LED Name Description IR Sensor • IR Sensor for remote control • Indicated LED -.
  • Page 9 REV.NO : 1.1 REG. DATE : 2019.12.10 User Manual for DTS-5560KN PAGE : REV. DATE : 2020.04.22 4.2 OSD Setting  Press “MENU” button to display the main menu • Press “MENU” button again choose to the present menu or Press “...
  • Page 10 REV.NO : 1.1 REG. DATE : 2019.12.10 User Manual for DTS-5560KN PAGE : REV. DATE : 2020.04.22 [ Picture Mode ] ◀/▶ • Press button to select picture mode. (Backlight, Brightness, Contrast, Sharpness) ◀/▶ • Select correspond item, press “DOWN“(▼) button or button to enter in the submenu •...
  • Page 11 REV.NO : 1.1 REG. DATE : 2019.12.10 User Manual for DTS-5560KN PAGE : REV. DATE : 2020.04.22 [ Color Mode ] ◀/▶ • Press button to select Color mode. (Gamma, Temperature, Color effect, Hue, SAT) ◀/▶ • Select correspond item, press “DOWN“(▼) button or button to enter in the submenu •...
  • Page 12 REV.NO : 1.1 REG. DATE : 2019.12.10 User Manual for DTS-5560KN PAGE : REV. DATE : 2020.04.22 [ Advance Mode ] ◀/▶ • Press button to select advance mode. (Aspect ratio, Over Scan, Over Drive, DP Option, DP-EDID ) ◀/▶...
  • Page 13 REV.NO : 1.1 REG. DATE : 2019.12.10 User Manual for DTS-5560KN PAGE : REV. DATE : 2020.04.22 [ Input Mode ] • Press ◀/▶ button to shift the cursor • Press “DOWN” (▼) button to select signal source • Press “ UP” (▲) button to return to the previous menu or exit the present menu.
  • Page 14 REV.NO : 1.1 REG. DATE : 2019.12.10 User Manual for DTS-5560KN PAGE : REV. DATE : 2020.04.22 [ Other ] ◀/▶ • Press button to select Other mode. (Reset, Menu time, OSD H, V position, Language, OSD Transparency, OSD Rotate) ◀/▶...

  • Page 15: Remote Control

    REV.NO : 1.1 REG. DATE : 2019.12.10 User Manual for DTS-5560KN PAGE : REV. DATE : 2020.04.22 5. Remote Control (Options) • Use a remote control up to 7 meters distance and 30 degree (left/right) within the receiving unit scope.

  • Page 16: Trouble Shooting

    REV.NO : 1.1 REG. DATE : 2019.12.10 User Manual for DTS-5560KN PAGE : REV. DATE : 2020.04.22 6. Trouble shooting Phenomenon Confirmation and action • Check that the Power code is properly connected to the display. • Check that Power on/off button on the OSD •...
  • Page 17 REV.NO : 1.1 REG. DATE : 2019.12.10 User Manual for DTS-5560KN PAGE : REV. DATE : 2020.04.22 Phenomenon Confirmation and action • Video timing outside of range Image will not adjust • Use the one-screen menu to adjust the clock setting.

  • Page 18: Specification

    REV.NO : 1.1 REG. DATE : 2019.12.10 User Manual for DTS-5560KN PAGE : REV. DATE : 2020.04.22 7. Specification (1) MONITOR SPECIFICATIONS ITEMS SPECIFICATION Screen Diagonal 54.64 inch Active Display Area 1209.6 x 680.4mm Display Type Transmissive mode, Normally black Max.
  • Page 19 REV.NO : 1.1 REG. DATE : 2019.12.10 User Manual for DTS-5560KN PAGE : REV. DATE : 2020.04.22 (3) MECHANICAL SPECIFICATIONS ITEMS SPECIFICATION Outline Dimension (HxVxD) 1294.6±1.2mm x 765.4±0.8mm x 62±0.3mm Weight(Net/ Gross) 46Kg Approx./ 52Kg Approx. Standard Accessory HDMI Cable, USB Cable, Power Cord, Remote control...
