Digital Touch Systems DTS-6560KN User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
REG. DATE : 2020.4.21
REV. DATE :
User Manual for
User Manual for
DTS-6560KN
DTS-6560KN
Appendix
REV.NO : 1.0
PAGE :
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DTS-6560KN and is the answer not in the manual?

Questions and answers

Related Manuals for Digital Touch Systems DTS-6560KN

Summary of Contents for Digital Touch Systems DTS-6560KN

  • Page 1 User Manual for REG. DATE : 2020.4.21 REV.NO : 1.0 DTS-6560KN REV. DATE : PAGE : User Manual for DTS-6560KN Appendix...

  • Page 2: Table Of Contents

    REG. DATE : 2020.4.21 User Manual for REV.NO : 1.0 DTS-6560KN PAGE : REV. DATE : Content Revision History ....................3 Recommended Use ....................4 1. Package Contents ..................5 2. Product Configuration ..................6 3. Interface Description..................7 4. OSD Control Board Description …………............8 5.

  • Page 3: Revision History

    REG. DATE : 2020.4.21 User Manual for REV.NO : 1.0 DTS-6560KN PAGE : REV. DATE : Change History of Revision Revision Date Contents of Revision Change Remark Release 20.4.21...

  • Page 4: Recommended Use

    REG. DATE : 2020.4.21 User Manual for REV.NO : 1.0 DTS-6560KN PAGE : REV. DATE : Recommended Use FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE FOLLOWING WHEN SETTING UP AND USING THE TOUCH SCREEN MONITOR. • DO NOT OPEN THE MONITOR.

  • Page 5: Package Contents

    REG. DATE : 2020.4.21 User Manual for REV.NO : 1.0 DTS-6560KN PAGE : REV. DATE : Thank you for your selection of 4K Touch Screen Display Monitor Please take a few minutes to read this User’s manual for the best performance of this monitor.

  • Page 6: Product Configuration

    REG. DATE : 2020.4.21 User Manual for REV.NO : 1.0 DTS-6560KN PAGE : REV. DATE : 2. Product Configuration OSD Button ( Attached page 8) Interface Terminal ( Attached page 7) Note ) Actual Touch Screen Monitor may differ from those in this user's drawing...

  • Page 7: Interface Description

    REG. DATE : 2020.4.21 User Manual for REV.NO : 1.0 DTS-6560KN PAGE : REV. DATE : 3. Interface Description HDMI1 HDMI2 Power Switch AC-Inlet (Touch) Name Description AC-Inlet • AC input terminal : 100V~240V ( 50hz~60hz) Power Switch • Power On/Off Switch HP Out •...

  • Page 8: Osd Control Board Description

    REG. DATE : 2020.4.21 User Manual for REV.NO : 1.0 DTS-6560KN PAGE : REV. DATE : 4. OSD Control Board Description 4.1 OSD Interface Description IR Sensor LED Name Description IR Sensor • IR Sensor for remote control • Indicated LED -.
  • Page 9 REG. DATE : 2020.4.21 User Manual for REV.NO : 1.0 DTS-6560KN PAGE : REV. DATE : 4.2 OSD Setting  Press “MENU” button to display the main menu • Press “MENU” button again choose to the present menu or Press “ UP” (▲) button to exit the present menu.
  • Page 10 REG. DATE : 2020.4.21 User Manual for REV.NO : 1.0 DTS-6560KN PAGE : REV. DATE : [ Picture Mode ] ◀/▶ • Press button to select picture mode. (Backlight, Brightness, Contrast, Sharpness) ◀/▶ • Select correspond item, press “DOWN“(▼) button or button to enter in the submenu •...
  • Page 11 REG. DATE : 2020.4.21 User Manual for REV.NO : 1.0 DTS-6560KN PAGE : REV. DATE : [ Color Mode ] ◀/▶ • Press button to select Color mode. (Gamma, Temperature, Color effect, Hue, SAT) ◀/▶ • Select correspond item, press “DOWN“(▼) button or button to enter in the submenu •...
  • Page 12 REG. DATE : 2020.4.21 User Manual for REV.NO : 1.0 DTS-6560KN PAGE : REV. DATE : [ Advance Mode ] ◀/▶ • Press button to select advance mode. (Aspect ratio, Over Scan, Over Drive, DP Option, DP-EDID ) ◀/▶ • Select correspond item, press “DOWN“(▼) button or button to enter in the submenu •...
  • Page 13 REG. DATE : 2020.4.21 User Manual for REV.NO : 1.0 DTS-6560KN PAGE : REV. DATE : [ Input Mode ] • Press ◀/▶ button to shift the cursor • Press “DOWN” (▼) button to select signal source • Press “ UP” (▲) button to return to the previous menu or exit the present menu.
  • Page 14 REG. DATE : 2020.4.21 User Manual for REV.NO : 1.0 DTS-6560KN PAGE : REV. DATE : [ Other ] ◀/▶ • Press button to select Other mode. (Reset, Menu time, OSD H, V position, Language, OSD Transparency, OSD Rotate) ◀/▶...

  • Page 15: Remote Control

    REG. DATE : 2020.4.21 User Manual for REV.NO : 1.0 DTS-6560KN PAGE : REV. DATE : 5. Remote Control (Options) • Use a remote control up to 7 meters distance and 30 degree (left/right) within the receiving unit scope. -Format : NEC...

  • Page 16: Trouble Shooting

    REG. DATE : 2020.4.21 User Manual for REV.NO : 1.0 DTS-6560KN PAGE : REV. DATE : 6. Trouble shooting Phenomenon Confirmation and action • Check that the Power code is properly connected to the display. • Check that Power on/off button on the OSD •...
  • Page 17 REG. DATE : 2020.4.21 User Manual for REV.NO : 1.0 DTS-6560KN PAGE : REV. DATE : Phenomenon Confirmation and action • Video timing outside of range Image will not adjust • Use the one-screen menu to adjust the clock setting.

  • Page 18: Specification

    REG. DATE : 2020.4.21 User Manual for REV.NO : 1.0 DTS-6560KN PAGE : REV. DATE : 7. Specification (1) MONITOR SPECIFICATIONS ITEMS SPECIFICATION Screen Diagonal 64.53 inch Active Display Area 1428.48 x 803.52mm Display Type Transmissive mode, Normally black Max. Resolution...
  • Page 19 REG. DATE : 2020.4.21 User Manual for REV.NO : 1.0 DTS-6560KN PAGE : REV. DATE : (3) MECHANICAL SPECIFICATIONS ITEMS SPECIFICATION Outline Dimension 1530.4±1.2mm x 905.6±0.8mm x 63.6±0.3mm(Without Handle) 1530.4±1.2mm x 905.6±0.8mm x 67.6±0.3mm(Without Handle) (HxVxD) Weight(Net/ Gross) 67Kg Approx./ 75Kg Approx.
