- Page 1 User’s Manual 3307568 Version 1.00 4/17/2007...
- Page 2 3307568 User’s Manual Copyrights This manual is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer.
-
Page 3: Sata Power Y Cable X
3307568 User’s Manual Packing List Please check package component before you use our products. Hardware: 3307568 Full-Size CPU Card x 1 Cable Kit: Floppy flat cable x 1 4-pin to 3-pin ATX cable x 1 DB25 & DB9 cable x 1... - Page 4 3307568 User’s Manual Chapter1 <Introduction> 1.1 <Product Overview> ...7 1.2 <Product Specification> ...8 1.3 <Block Diagram> ...10 1.4 <Mechanical Drawing > ... 11 Chapter 2 <Hardware Setup> 2.1 <Connector Location>...12 2.2 <Jumper Reference>…………………………………………………………………..13 2.3 <Connector Reference>...14 2.3.1 <Internal Connectors> 2.3.2 <External Connectors>...
- Page 5 3307568 User’s Manual Chapter 3 <System Configuration> 3.1 <SATA configuration>...36 3.2 <SATA RAID Configuration> ...37 3.3 <Audio Configuration> ...41 3.4 <Video Memory Setup> ...42 3.5 <Display Properties Setting>...44 Chapter 4 <BIOS Setup> Appendix A <I/O Port Pin Assignment> A.1 <Serial ATA Port>...48 A.2 <IrDA Port>...48...
- Page 6 3307568 User’s Manual (This Page is Left for Blank...
-
Page 7: Chapter1
Chapter1 <Introduction> 1.1 <Product Overview> 3307568 is the Full-size single board computer with last Intel desktop technology with PICMG form factor. Based on Intel Q965 and ICH8DO, the board integrates a new Core 2 Duo processor 775-pin socket, DDR2 memory socket, Intel Graphic Media Accelerator 3000 technology, Serial ATA II with RAID function for a powerful desktop system. -
Page 8: Product Specification
3307568 User’s Manual 1.2 <Product Specification> General Specification Form Factor Full-size PICMG CPU card Intel® Core 2 Duo / Pentium 4 / Pentium D / Celeron D processor with Package type: PLGA 775 Front side bus: 533/800/1066MT/s (133/200/266MHz x 4) Intel®... - Page 9 3307568 User’s Manual Ethernet Interface Controller One or two Intel 82573L Gigabit Ethernet controller Type Triple speed 10/100/1000Base-T Auto-switching Fast Ethernet Full duplex, IEEE802.3U compliant Connector Two External RJ45 connectors with LED on bracket Audio Interface Chipset Intel® ICH8DO with Realtek ALC260 HD Audio...
-
Page 10: Block Diagram
3307568 User’s Manual 1.3 <Block Diagram> Intel Core 2 Duo with 775 pin PLGA processor CH7307 LVDS CH7308 6 x USB2.0 ports HD Audio W83627THG 2 x Serial ports 1 x Parallel port 1 x Floppy port 8-bit GPIO 1 x IrDA... -
Page 11: Mechanical Drawing
3307568 User’s Manual Introduction 1.4 <Mechanical Drawing > Mechanical Drawing... -
Page 12: Chapter 2
3307568 User’s Manual Hardware Setup Chapter 2 <Hardware Setup> 2.1 <Connector Location> RJ45_2 RJ45_1 Connector Location... -
Page 13: Jumper Reference
3307568 User’s Manual 2.2 <Jumper Reference> Jumper Function JRTC CMOS Operating/Clear Setting JVLCD Panel Voltage Setting (3307568C & D Only) JVLCD Jumper Reference Hardware Setup JRTC... -
Page 14: Connector Reference
3307568 User’s Manual 2.3 <Connector Reference> 2.3.1 <Internal Connectors> Connector LGA775 CPU socket DDRIIA/B 240 -pin DDR2 SDRAM DIMM socket 34-pin floppy connector CN_LPT 13 x 2-pin LPT connector S_ATAII1/2/3/4/5/6 7-pin Serial ATA II connector CN_12V 8-pin +12V additional power supply connector... -
Page 15: Cpu And Memory Setup
3307568 User’s Manual 2.4 <CPU and Memory Setup> 2.4.1 <CPU installation> 3307568 has a LGA775 CPU socket onboard; please check following steps to install the processor properly. Attention If 3307568 need RMA please Keep CPU socket cover on the CPU Socket. -
Page 16: Memory Installation
3307568 User’s Manual 2.4.2 <Memory installation> 3307568 has two 240-pin DDR2 DIMM support up to 3GB of memory capacity. The memory frequency supports 533/667/800MHz . Only Non-ECC memory is supported. Please check the pin number to match the socket side well before installing memory module. -
Page 17: Cmos Setup
3307568 User’s Manual 2.5 <CMOS Setup> The board’s data of CMOS can be setting in BIOS. If the board refuses to boot due to inappropriate CMOS settings, here is how to proceed to clear (reset) the CMOS to its default values. -
Page 18: Serial Ata Installation
3307568 User’s Manual 2.6 <Serial ATA installation> 3307568 has six Serial ATA II interfaces with RAID function, the transfer rate of the Serial ATA II can be up to 300MB/s. Please go to ATA technology information. Based on Intel Technology with combination of RAID 0,1,5 and 10. The main features of RAID on ICH8DO are listed below: Supports for up to RAID volumes on a single, two-hard drive RAID array. -
Page 19: Lan Interface
3307568 User’s Manual Hardware Setup 2.7 <LAN Interface> The Intel 82573L supports triple speed of 10/100/1000Base-T, with IEEE802.3 compliance and Wake-On-LAN supported. LAN Interface... -
Page 20: Onboard Display Interface
3307568 User’s Manual Hardware Setup 2.8 <Onboard Display Interface> Based on Intel Q965 chipset with built-in graphics, the board provides one DB15 connector on real external I/O port, and one 40-pin LVDS interface with 5-pin LCD backlight inverter connector. (3307568C & D Only) The board also provides 26-pin DVI interface. -
Page 21: Lvds Display 3307568C & D Only
3307568 User’s Manual 2.8.2 <LVDS Display 3307568C & D Only > The board provides one 40-pin LVDS connector for 18/24-bit dual channel panels, supports up to 1600 x 1200 (UXGA) of resolution, with one LCD backlight inverter connector and one jumper for panel voltage setting. - Page 22 3307568 User’s Manual Connector: CN_INV Type: 5-pin LVDS Power Header Connector model: JST B5B-XH-A Description +12V ENABKL Connector: CN_LVDS Type: onboard 40-pin connector for LVDS connector Connector model: HIROSE DF13-40DP-1.25V Connector: JVLCD Type: 3-pin Power select Header Signal LCDVCC ATX0-...
- Page 23 LCD Installation Guide: Preparing the 3307568, LCD panel and the backlight inverter. Please check the datasheet of the panel to see the voltage of the panel, and set the jumper JVLCD to +5V or +3.3V.
- Page 24 3307568 User’s Manual After setup the devices well, you need to select the LCD panel type in the BIOS. The LCD type mapping is list below: Single channel Output format 800 x 600 (18bit) 1024 x 768 (24bit) BIOS panel type selection form...
- Page 25 3307568 User’s Manual 2.8.3 <DVI Display 3307568DG/ DG2 Only > The board provides optional DVI-D interface with Intel Q965, compliant with DVI 1.0 standard. Connector: CN_DVI Connector type: 26-pin header connector (pitch = 2.0mm) Pin Number Onboard Display Interface Assignment...
-
Page 26: Audio Installation
3307568 User’s Manual 2.9 <Audio Installation> The board integrates onboard audio interface with REALTEK ALC260 codec, with Intel next generation of audio standard as High Definition Audio, it offers more vivid sound and other advantages than former HD audio compliance. - Page 27 3307568 User’s Manual Connector: CN_AUDIO Type: 10-pin (2 x 5) header (pitch = 2.54mm) Description MIC_L MIC_R Speaker_R SENSE Speaker_L Connector: CDIN Type: 4-pin header (pitch = 2.54mm) Description CD – Left Ground Ground CD – Right Audio Installation Hardware Setup...
-
Page 28: Gpio Interface
3307568 User’s Manual 2.11 <GPIO interface> The board provides a programmable 8-bit digital I/O interface for control panel application. Connector: CN_DIO Type: onboard 2 x 6-pin header, pitch=2.0mm Description Ground GP10 GP11 GP12 GP13 Hardware Setup Description Ground GP14 GP15... -
Page 29: Usb2.0 Interface
3307568 User’s Manual 2.12 <USB2.0 Interface> Based on Intel ICH8HDO , the board provides 6 USB2.0 ports. The USB2.0 interface provides up to 480Mbps of transferring rate. The Intel ICH8DO contains two Enhanced Host Controller Interface (EHCI) and five Universal Host Controller Interfaces (UHCI), it can determine whether your connected device is for USB1.1 or USB2.0, and change the transfer rate automatically. -
Page 30: Power And Fan Installation
3307568 User’s Manual 2.13 <Power and Fan Installation> The 3307568 provides a standard ATX power supply with additional 12V connector, and the board provides one fan for CPU cooler and two 3-pin cooler fan connectors for system and Northbridge chip. - Page 31 3307568 User’s Manual Connector: CN_12V Type: 8-pin ATX power connector PIN assignment Connector: DC_IN Type: 4-pin P-type connector for +5V/+12V input Description +12V Connector: CN_PS Type: 3-pin ATX function connector Description 5V Standby Connector: CPUFAN Type: 4-pin fan wafer connector...
-
Page 32: Serial Port
3307568 User’s Manual 2.14 <Serial Port> The board supports one RS232 serial port and one jumper selectable RS232/422/485 serial ports. The jumper JCSEL1 & JCSEL2 can let you configure the communicating modes for COM2. Connector: CN_COM1/2 Type: 10-pin (5 x 2) 2.54mm x 2.54mm-pitch header for COM2... - Page 33 3307568 User’s Manual RS-422 RS-485 RS-232 Serial Port JCSEL1 JCSEL2 Hardware Setup...
-
Page 34: Switch And Indicator
3307568 User’s Manual 2.15 <Switch and Indicator> The JFRNT provides front control panel of the board, such as power button, reset and beeper, etc. Please check well before you connecting the cables on the chassis. Connector: JFRNT Type: onboard 14-pin (2 x 7) 2.54-pitch header... - Page 35 3307568 User’s Manual (This Page is Left for Blank)
-
Page 36: Sata Configuration
3307568 User’s Manual System Configuration Chapter 3 <System Configuration> 3.1 <SATA configuration> SATA Mode: This option can let you select whether the Serial ATA hard drives would work under normal IDE mode or RAID mode. The RAID mode need more than one HDD is applied. -
Page 37: Sata Raid Configuration
3307568 User’s Manual System Configuration 3.2 <SATA RAID Configuration> The board integrates Intel ICH8DO with RAID function for Serial ATA II drives, and supports the configurations below: RAID 0 (Stripping): Two hard drives operating as one drive for optimized data R/W performance. - Page 38 3307568 User’s Manual Please press <CTRL+I> to enter the RAID configuration menu. You can setup the RAID under operation system for Microsoft Windows XP SP1 or Windows 2000 SP4 version, please install the Intel Application Accelerator Ver.4.5 later to support RAID configuration with Intel Matrix Storage Technology.
- Page 39 3307568 User’s Manual System Configuration 2. Select Actions to Create RAID Volume Rename the Volume name Select RAID Level as 0 Left as default SATA RAID Configuration...
- Page 40 3307568 User’s Manual 3. Please select two hard drives to prepare to set the RAID volume 4. Specify the Volume size Tune this bar to specify the volume size, if you specify the volume size lower than maximum, you can create a second volume for another RAID set.
-
Page 41: Audio Configuration
3307568 User’s Manual 3.3 <Audio Configuration> The board integrates Intel ICH8DO with REALTEK ALC260 codec. It can support 2-channel sound under system configuration. Please follow the steps below to setup your sound system. Install REALTEK HD Audio driver. Lunch the control panel and Sound Effect Manager. -
Page 42: Video Memory Setup
3307568 User’s Manual System Configuration 3.4 <Video Memory Setup> Based on Intel Q965 chipset with GMA (Graphic Media Accelerator) 3000, the board supports Intel DVMT (Dynamic Video Memory Technology) 3.0, which would allow the video memory be triggered up to 256MB. - Page 43 3307568 User’s Manual Fixed + DVMT Memory Size: You can select the fixed amount and the DVMT amount at the same time for a guaranteed video memory and additional dynamic video memory, please check the table below for available setting.
-
Page 44: Display Properties Setting
3307568 User’s Manual 3.5 <Display Properties Setting> Based on Intel Q965 GMCH with GMA3000 (Graphic Media Accelerator), the board supports two DACs for display device as different resolution and color bit. Please install the Intel Graphic Driver before you starting setup display devices. - Page 45 3307568 User’s Manual 3. This setup options can let you define each device settings. Click Monitor to setup the CRT monitor for Colors, Resolution and Refresh Rate Click Intel® Dual Clone setup display mode as same screen Set the main display device here...
-
Page 46: Chapter 4
3307568 User’s Manual Chapter 4 <BIOS Setup> The motherboard uses the Award BIOS for the system configuration. The Award BIOS in the single board computer is a customized version of the industrial standard BIOS for IBM PC AT-compatible computers. It supports Intel x86 and compatible CPU architecture based processors and computers. - Page 47 3307568 User’s Manual (This Page is Left for Blank)
-
Page 48: Appendix A
3307568 User’s Manual Appendix A <I/O Port Pin Assignment> A.1 <Serial ATA Port> Connector: S_ATA1/2/3/4/5/6 Type: 7-pin wafer connector GND RSATA_TXP1 RSATA_TXN1 GND RSATA_RXN1 RSATA_RXP1 GND A.2 <IrDA Port> Connector: CN_IR Type: 5-pin header for SIR Port Description IRRX Ground... -
Page 49: A.3
3307568 User’s Manual A.3 <VGA Port> Connector: CRT Type: 15-pin D-sub female connector on bracket Description GREEN BLUE Ground A.4 <LAN Port> Connector: RJ451/2 Type: RJ45 connector with LED on bracket Description Description VGA Port Description Ground Ground Ground Ground... -
Page 50: Appedix B
3307568 User’s Manual System Resources Appedix B <System Resources> B1.<I/O Port Address Map> I/O Port Address Map... - Page 51 307568 User’s Manual System Resources I/O Port Address Map...
- Page 52 3307568 User’s Manual System Resources B2.<Memory Address Map> Memory Address Map...
- Page 53 3307568 User’s Manual System Resources B3.<System IRQ Resources> System IRQ Resources...
-
Page 54: Appedix C
3307568 User’s Manual Appedix C <Flash BIOS> C.1 BIOS Auto Flash Tool The board is based on Award BIOS and can be updated easily by the BIOS auto flash tool. You can download the tool online at the address below: h ttp://www.award.com... -
Page 55: Appendix D
3307568 User’s Manual Appendix D <Programming GPIO’s> The GPIO’can be programmed with the MSDOS debug program using simple IN/OUT commands.The following lines show an example how to do this. GPIO0…..GPIO7 bit0……bit7 -o 4E 87 -o 4E 87 -o 4E 07... -
Page 56: Appendix E
3307568 User’s Manual Appendix E <Watch Dog timer Setting > The watchdog timer makes the system auto-reset while it stops to work for a period. The integrated watchdog timer can be setup as system reset mode by program. Timeout Value Range... -
Page 57: Contact Information
3307568 User’s Manual Any advice or comments about our products and service, or anything we can help you with please don’t hesitate to contact with us. We will do our best to support you for your products, projects and business.
