Hardware - AMPLIFIED ENGINEERING fatbox G3 Manual

ABOUT
The FATBOX G3 is available in two versions.
1.2

HARDWARE

STANDARD VERSION
With rugged anodized
aluminium chassis
NOTE: The client is required
to have their own mounting
screws (M3 size) to suit the
surfaces the G3 will be on.
OEM VERSION
101mm
VERSION SPECIFICATIONS
OEM
INTERFACE
- LAN
- SERIAL
- I/O
- USB
DIMENSION
- L 114mm
- W 108mm
- H 19mm
INTEGRATED
MOUNTING
WEIGHT 110g
PERIPHERALS INCLUDED
· GSM antenna (with 2M wire)
High-gain outdoor antenna option
· CAT-5 LAN cable (3M)
· Power supply unit (230/110VAC to 24VDC 0.5A)
fatbox G3
STANDARD
149mm
111mm
37mm
375g
