- Page 1 COSEC VEGA CPM MIFARE SMART...
-
Page 2: Table Of Contents
TABLE OF CONTENT IMPORTANT SAFETY INSTRUCTIONS…………………..…Page No.3 GENERAL……………………………………………………………… Page No.4 SPECIFICATION…………………………………………………….. Page No.5 Pin Description………………………………………….…………..Page No.5 INSTALLATION ………………………………………………..… Page No.6 ANTENNA………………………………………………..…………… Page No.8 OPERATION ………………………………………………………… Page No.8 FCC REGISTRATION INFORMATION……………………… Page No.9... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using your COSEC CPM MIFARE SMART Reader, basic safety precautions should always be followed to reduce the risk of fire, electrical shock, and injury to persons. In addition, the following should also be followed: 1. Read and understand all instructions. 2. -
Page 4: General
GENERAL The MATRIX COSEC CPM MIFARE SMART MODULE is an elegant looking reader which can be mounted to metal door frame (mullion) or any flat wall surface. MATRIX COSEC CPM MIFARE SMART MODULE Reader uses an electronic module in epoxy potting that ensures successful operation even in harsh environments. -
Page 5: Specification
SPECIFICATION Model COSEC VEGA CPM MIFARE SMART Write/Read Range 2-8 cm Power/Current 5 - 5.5VDC (12VDC adapter through host product) Working Frequency 13.56 MHz Operating Temperature -40 to 85°C Dimension in mm 71.4 x 43.4 Weight 20 g Pin Definition... -
Page 6: Installation
[1] This pin is used for connection of a buffer capacitor. Connection of a supply voltage might damage the device INSTALLATION Insert the RF reader module “COSEC VEGA CPM MIFARE SMART”, matching the connector pins on the module with those provided on the card reader slot. - Page 7 4. Press the free end of the module inwards with your fingertips to lock it in place as shown in figure. 5. Replace the back cover as shown in fugure.
-
Page 8: Antenna
ANTENNA COSEC VEGA CPM MIFARE SMART Antennas are PCB based with different dimensions and having around 2µH +/- 2% µH inductance. The module supports for different Matrix make antennas, the intentional radiator (COSEC VEGA CPM MIFARE SMART) may be operated with the antenna with which it is authorized. -
Page 9: Fcc Registration Information
FCC REGISTRATION INFORMATION 2.2 list of applicable FCC rules This device complies with part 15.225 of the FCC rules. 2.3 Summarize the specific operation use conditions This module can be used in household electrical appliances as well as lighting equipment’s. The input voltage to the module should be nominally 5.0 to 5.5V d.c., The ambient temperature of the module should not exceed 80˚C. - Page 10 2.10 Addition testing, Part 15 subpart B disclaimer The final host/module combination need to be evaluated against the FCC Part 15B criteria for unintentional radiators in order to be properly authorized for operation as a Part 15 digital device The host integrator installing this module into their product must ensure that the final composite product complies with the FCC requirements by a technical assessment or evaluation to the FCC rules, including the transmitter operation and should refer to guidance in KDB 996369.
- Page 11 To comply with the FCC RF exposure compliance requirements, this device and its antenna must not be co-located or operating to conjunction with any other antenna or transmitter, except if installed in compliance with FCC Multi Transmitter procedures. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
