- Page 1 COSEC CPM EM PROX...
-
Page 2: Table Of Contents
Table of Content Important Safety Instructions General Specification Installation Antenna LED indication in the host product Operation FCC registration information... -
Page 3: Important Safety Instructions
Important Safety Instructions When using your COSEC CPM EM PROX Proximity Reader, basic safety precautions should always be followed to reduce the risk of fire, electrical shock, and injury to persons. In addition, the following should also be followed: 1. Read and understand all instructions. -
Page 4: General
General The MATRIX COSEC CPM EM PROX MODULE is an elegant looking reader which can be mounted to metal door frame (mullion) or any flat wall surface. MATRIX COSEC CPM EM PROX MODULE Reader uses an electronic module in epoxy potting that ensures successful operation even in harsh environments. -
Page 5: Installation
Working Frequency : COSEC CPM EM PROX module working frequency is from 120 KHz to 130.43 KHz. Purpose : When 125KHz EMPROX module is inserted in the End product (door controllers), due to some environmental disturbance the end product may not work at 125KHz and which may result in poor card reader range . -
Page 6: Antenna
COSEC CPM EMPROX RFID Antennas are winded wire gauge with different dimensions and having around 900µH +/- 20µH inductance value with a DC resistance of 12-17ohm. The module supports for different Matrix make antennas, the intentional radiator (COSEC CPM EM PROX) may be operated with the antenna with which it is authorized. - Page 8 2. Premium LF Coil Antenna (COSEC VEGA) Parameter Specifications: Frequency: 120KHz to 130.43KHz Inductance: 900µ H +/- 20µ H DC Resistance: 12 ohms +/- 10% Wire Gauge: 36 AWG or Large...
- Page 9 3. NGT LF Coil Antenna (COSEC NGT) Parameter Specifications: Frequency: 120KHz to 130.43KHz Inductance: 900µ H +/- 20µH DC Resistance: 12 ohms +/- 10% Wire Gauge: 36 AWG or Large...
- Page 10 4. CDC FP LF Coil Antenna (COSEC PATH) Parameter Specifications: Frequency: 120KHz to 130.43KHz Inductance: 900µ H +/- 20µ H DC Resistance: 17ohms +/- 10% Wire Gauge: 36 AWG or Large...
-
Page 11: Led Indication In The Host Product
LED indication in HOST product Operation Matrix COSEC CMP EM PROX RFID (radio-frequency identification) is the wireless non- contact use of radio-frequency electromagnetic fields, for the purposes of identifying and tracking tags attached to objects. The reader continuously emits RF carrier signals, and keeps observing the received RF signals for data. - Page 12 127.66 KHz 129.03 KHz 130.43 KHZ IMPROTANT: The modification/change in frequency is possible only through Matrix Door controller with the help of Service engineer. FCC Compliance Statements This device complies with Part 15 of the FCC rules. Operation is subject to following Two conditions: 1.
- Page 13 2. In the user manual, final system integrator must ensure that there is no instruction provided in the user Manual to install or remove the transmitter module. 3. Transmitter module must be installed used in strict accordance with the Manufacturer’s instructions as described in the user documentation that comes with the product.
- Page 14 Installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the Interference by one or more of the following measures: - Reorient or relocate the receiving antenna.
