Summary of Contents for Electronics Diversified T-12
- Page 1 T-12 User Manual Electronics Diversified, Inc. T-12 User Manual 070-0740-00 1675 NW Cornelius Pass Road • Hillsboro OR 97124 USA (503) 645-5533 • (800) 547-2690 • FAX: (503) 629-9877 June 2004 ® www.edionline.com Page 1 of 5...
- Page 2 Adjusting the Fade Time............4 Overriding the Fade ..............4 Editing Presets in Blind Mode..........4 Copy Mode.................... 5 Lockout Mode ..................5 Override Mode................... 5 Returning Settings to Factory Default ....... 5 JUNE 2004 070-0740-00 T-12 USER MANUAL Page 2 of 5...
- Page 3 DISPLAY Patching The T-12 can patch any of 512 dimmers to any of its 12 channels. To enter Patch mode, press ON and Preset 2 simultaneously and hold for 5 seconds. The alphanumeric display will show the last selected dimmer address. Dimmers are selected by pressing the UP and DOWN arrows of the master channel.
- Page 4 Recording an Active Preset A preset stores dimmer settings using each of the 12 channels on the T-12. It is possible to store up to 10 preset “looks” with the 8 preset buttons and the ON and OFF buttons. To record an active preset for a look, adjust each of the 12 individual channels to the desired level.
- Page 5 5 seconds. CPY will be displayed in the alphanumeric display. Press any of the preset but- tons to copy the look to a preset on the T-12. The preset button will light. Press the master UP button to copy the look to the channels.
