DenMat PSP Pro-Select Platinum Operation And Instruction Manual

Ultrasonic scaling and heated irrigation system

Advertisement

Operation and instruction manual
Pro-Select Platinum® Operation and Instruction Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSP Pro-Select Platinum and is the answer not in the manual?

Questions and answers

Summary of Contents for DenMat PSP Pro-Select Platinum

  • Page 1 Operation and instruction manual Pro-Select Platinum® Operation and Instruction Manual...
  • Page 2 easy on you, easy on your patients Two instruments in one – ultrasonic scaling and heated irrigation system. PSP® is a superb piezo ultrasonic scaling solution and the only system that combines scaling with heated subgingival irrigation. Upgrade your practice today.
  • Page 3: Table Of Contents

    Contents Page Product Documentation Overview Accesories Getting Started Operation Operation • Foot pedal • Scaler mode • Irrigation mode Cleaning, Disinfection and Sterilization • Control unit • Bottles • Cables • Handpieces • Tips • LED lights Maintenance and Service •...
  • Page 4: Product Documentation

    Product Documentation Date installed: ___/___/_______ Installer: Control Unit #: Handpiece #: Irrigator #: Tips: Tip # Date of first use Handpiece cable: Cable # Date started Date finished LED lights Solution ordered: Date Pro-Select Platinum® Operation and Instruction Manual...
  • Page 5: Overview

    Overview Control unit Front view Brackets Solution bottles Handpiece holder LED bottle selection indicators Light button Power button Handpiece cable Bottle select button connector LCD status display Flow rate button Irrigation button Adjustment buttons Back view Serial number Fuse Foot pedal jack Power transformer jack Serial number bottom module...
  • Page 6: Accesories

    Accessories Included with the PSP® Item Re-order # Description Solution bottles S40200 Deliver purified or distilled water and antimicrobial solutions, such as chlorhexidine and fluoride Warning Use distilled or sterile water only in the water bottle. Do not use tap water. This will void warranty. Particulate suspensions or viscous fluids should not be used in PSP®...
  • Page 7 Item Re-order # Description Transformer Connect transformer to control 100200 (US) unit then plug into a standard power outlet S30500 (CAN) Tip wrench 100773 Tighten and remove tip from handpiece and measure tip wear Tip grip 100540 Non-slip rubber makes tip changing easier 2.0% NaF* 2037MTM...
  • Page 8: Getting Started

    • Do not force or pull on transformer, handpiece cable or foot pedal • Do not use tips on metal or ceramic restorations • Check tip before every use Bent, worn or compromised tips should be replaced • Contact DenMat at 800-433-6628 for parts and support Pro-Select Platinum® Operation and Instruction Manual...
  • Page 9 Plug in foot control Warning PSP® foot pedals are not compatible with any other brand or model. Interchanging will void warranty. 1. Plug black pedal control connector into black jack on control unit back 2. Push until clicks 3. To remove, depress locking tab and remove connector from jack Plug in power transformer 1.
  • Page 10 2. Align bottle with flat sides of lid perpendicular to control unit 3. Grasp bottle by cap 4. Align bottle with control unit bracket. Slide onto bracket until it stops 5. Using cap, rotate bottle right 1/4 turn until it stops 6.
  • Page 11 3. To connect scaler tip: • Place handpiece in center of tip grip • Using a clockwise rotation, screw tip onto handpiece • Align tip wrench with flat sides of tip base • Use tip grip and wrench to tighten until tip is secure 4.
  • Page 12: Operation

    Operation Turn on the PSP® Press or Press to turn PSP® on or off Change scaler and irrigation modes Press and hold down outer pedal, roll foot to center or press to switch from scaler mode to irrigator mode Increase power level Decrease power level Press or press...
  • Page 13: Operation

    Scaler mode Attention • Liquid is utilized to flush area and cool frictional heat at tooth surface and scaler tip interface. Liquid flow should be used at all times during operation. • Use linear motion similar to hand scaling, move side of tip across tooth surface. Horizontal orientation Vertical orientation •...
  • Page 14: Irrigation Mode

    5. To reset default press and hold until four beeps are heard 6. A light pen grasp using a stabilizing fulcrum, rather than a power fulcrum, is all that is required using PSP® Irrigation mode Attention • Attach irrigator handpiece while in scaler mode or when power is off. •...
  • Page 15: Cleaning, Disinfection And Sterilization

    Cleaning for Scaler Handpiece, Irrigator Handpiece, and Scaler Tips. Cleaning protocol (hand piece, irrigator, h/p cable, wrench, tips, tip grip, LEDs) Step Solution Time (min) Temperature Instructions Clean thoroughly - Immerse and soak for Warm, as delivered required time, scrub all external surfaces Hospital grade At least 10 from the available...
  • Page 16 2. Place tip wrench and tip grip in an autoclave bag and sterilize by following autoclave manufacturer’s instructions. Any method of sterilization not specifically recommended in this Operation and Instruction Manual should be approved by DenMat prior to its use, in order to prevent voiding of warranty Pro-Select Platinum® Operation and Instruction Manual...
  • Page 17: Maintenance And Service

    4. New tips can be purchased by calling DenMat at 800-433-6628 or at denmat.com. Service To return materials: Please call DenMat Customer Care at 800-433-6628 for an RMA (Return Material Authorization) number. Shipping your product in original packaging will offer the best protection against damage during shipping.
  • Page 18: Control Unit

    No, replacement only *If the Control Unit needs to be sent in for repair, all components of the PSP must be included so that DenMat’s technical support team can repair the unit and test it for functionality prior to returning to the customer.
  • Page 19: Troubleshooting Guide

    • Try second handpiece • Try second tip • If problem persists, contact DenMat Customer Care at 800-433-6628 • Check to ensure that the flow rate is set on Low, Med, or Hi on the LCD display • Make sure the bottles are locked in and there is liquid in the bottles •...
  • Page 20: Parts, Accessories And Specifications

    Parts, Accessories and Specifications Replacement part numbers When inquiring about new or replacement parts for your PSP® system, please refer to the following part numbers 2037MTM 2.0% Neutral NaF irrigation solution (64oz) 2054 Irrigator cannulas (100/Box) 2193B 0.12% Chlorhexidine irrigation solution (16 oz.) 100351 Autoclave cassette 100540...
  • Page 21: Disclaimers And Special Conditions

    • Please dispose of any and all component parts of this product according to all local and national regulations governing the disposal of electronic devices. • Service is to be performed by a qualified DenMat professional only. • Pacemakers and Ultrasonics - Modern pacemakers are shielded against electromagnetic interference. However, most electronic devices do generate an electromagnetic field.
  • Page 22 1017 W. Central Ave. Lompoc, CA 93436 | 1-800-433-6628 | www.denmat.com Manufactured and distributed by DenMat®. ©2014 Den-Mat Holdings LLC. All rights reserved. PSP™, Pro-Select®, Pro-Select Platinum® and Pro-DenRx® are registered trademarks. 823060400 09/14BA...
  • Page 23 1017 W. Central Ave. Lompoc, CA 93436 | 1-800-433-6628 | www.denmat.com Manufactured and distributed by DenMat®. ©2014 Den-Mat Holdings LLC. All rights reserved. PSP™, Pro-Select®, Pro-Select Platinum® and Pro-DenRx® are registered trademarks. 823060400 09/14BA...
  • Page 24 Manufactured and distributed by DenMat®. 800-433-6628 PSP®, Pro-Select®, Pro-Select Platinum® and Pro-DenRx® are registered trademarks. CONFORMS TO UL STD 60601-1 denmat.com ©2020 Den-Mat Holdings LLC. All rights reserved. 823060400 R:2 02/20CM CERTIFIED TO CAN/CSA STD C22 NO.601.1...
