INTERCONNECTIONS
Installation Drawing Ref. No. 0G0325
INSTALLATION LAYOUT
46.02
DOOR TYP
AUTO
OFF
QUARTZ
SET
EXERCISE
OFF
TIME
ON
HOURS
1/10
MANUAL
OVER CRANK
OVER SPEED
LOW COOLANT LEVEL
HI COOLANT TEMPERATURE
LOW OIL PRESSURE
LOW BATTERY
LOW FUEL PRESSURE
SYSTEM READY
DANGER
FUSES
LOCATED
High voltage.
Contact with terminals
INSIDE
may result in personal
injury or death.
SEE INSTALL DWG 0G9370 FOR DETAILS
62.2
Generac Power Systems, Inc. • P .O. Box 8, Waukesha, WI 53187 • generac.com
©2008 Generac Power Systems, Inc. All rights reserved. All specifications are subject to change without notice. Bulletin 0179200SBY/Printed in U.S.A. 09.08
22
240 1 Ø
22
208 3 Ø
33.5
FRONT VIEW
QT022
125
#2 to 1/0
100
#4 to 1/0
28.98
WEIGHT: 843 lbs.
