TX-29EG20RU-IRAN Note: Specifications are subject to change without notice. Mass and dimensions shown are approximate. CONTENTS Page Page 1 Safety Precautions 4.2. COLOUR PURITY 1.1. General Guide 4.3. CONVERGENCE 1.2. Leakage Current Cold Check 4.4. WHITE BALANCE (MARKET MODE CHK 4) 1.3.
TX-29EG20RU-IRAN 1 Safety Precautions 1.3. Leakage Current Hot Check (See Fig. 1) 1.1. General Guide 1. Plug the AC cord directly into the AC outlet. Do not use an 1. It is advisable to insert an isolation transformer in the AC isolation transformer for this check.
TX-29EG20RU-IRAN 2 Service Hints 2.1. HOW TO MOVE CHASSIS INTO SERVICE POSITION. 1. Remove 9 screws. 2. Draw out Main Chassis. 3. Stand the Main Chassis.
TX-29EG20RU-IRAN 3 Market Mode Function 3.1. Service Mode Access 1. Set timer ON. 2. Press remote’s RECALL ( ) and panel’s volume down key simultaneously to enter SERVICE 1. 3. Set to normal mode : Press the volume down button on front, together press the off timer button on remote control.
TX-29EG20RU-IRAN 4 Adjustment Procedure 4.1. Adjustment Procedure 4.1.1. +B Voltage 4.1.2. High Voltage Item / preparation Item / preparation 1. Operate the TV set. 1. Receive the crosshatch pattern. 2. Set control as follows : 2. Set to 0 Beam.
TX-29EG20RU-IRAN 7. Adjust the purity magnet so that a vertical green field is by rotating (RB)-G static convergence magnet. obtained at the center of the screen. 5. Lock convergence magnets with silicone sealer. 6. Remove the DY wedges and slightly tilt the Deflection Yoke vertically.
TX-29EG20RU-IRAN 4.4. WHITE BALANCE (MARKET MODE CHK 4) Preparation 1. Receive a colour bar signal with colour “OFF”, and operate the TV set for more than 30 minutes. 2. Set the picture menu to “DYNAMIC NORMAL” and the AI to off.
TX-29EG20RU-IRAN 4.5. ADJUSTMENT OF CRT VRS NOTE: FOR FLAT CRT ONLY PREPARATION 1. Set DY to CRT not to tilt up and down left and right deflection. 2. Set CY to CRT and set CY magnet primarily. Pur Mg : Set Pur Mg that 2 magnets are (top position) VRS Mag : Set VRS Mg that 2 magnets are (horizontal position) only 21”, 25”...
TX-29EG20RU-IRAN 8.2. Replacement Parts List Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks A68LZU185X46 C3155 F1J1H103A590 C 0.01UF, J, 50V EASG15S509A2 SPEAKER C3156 F2A1C101A244 E 100UF, 16V N2QAJB000161 REMOTE CONTROL C3157 F2A1C101A310...
Page 28
TX-29EG20RU-IRAN Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks C633 ECJ1VC1H471J C 470PF, J, 50V C965 F2A2C2200010 E 22UF, 160V C634 ECJ1VC1H471J C 470PF, J, 50V C966 ECA1CHG101 E 100UF, 16V C635...
Page 29
TX-29EG20RU-IRAN Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks IC853 C0DAEJG00001 IC, POWER SUPPLY Q4850 B1ADDF000005 TRANSISTOR IC857 C0DBEHE00005 IC, POWER SUPPLY Q501 2SC4212H TRANSISTOR IC860 B3PAA0000363 PHOTO COUPLER Q520 B1ADBM000004 TRANSISTOR...
Page 30
TX-29EG20RU-IRAN Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks R3005 ERJ3GEYJ750 M 75OHM,J,1/16W R507 ERDS2TJ561 C 560OHM,J, 1/4W R3006 ERJ3GEYJ750 M 75OHM,J,1/16W R508 ERG3FJ821H M 820OHM,J, 3W R3008 ERJ3GEYJ104 M 100KOHM,J,1/16W R509 ERG3FJ122 M 1.2KOHM,J, 3W...
Page 31
TX-29EG20RU-IRAN Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks R825 ERJ3GEYJ471 M 470OHM,J,1/16W K1KA06AA0659 CONNECTOR R827 ERJ3GEYJ153 M 15KOHM,J,1/16W K1KA08AA0659 CONNECTOR R828 ERJ3EKF5602 F 56KOHM,J, 1/10W K1KA08AA0659 CONNECTOR R829 ERJ3EKF3092 F 30.9KOHM,J, 1/10W...
