Home appliances CI6SE2 Quick Manual

Cooktops
CI6SE2
specifications
Cooking zones: Front Left - 140mm, 1200W (Booster -1500W)
Rear Left - 180mm, 2300W (Booster -2600W)
Centre Right - 280mm, 3000W (Booster -4000W)
Kilowatt rating: 7.2 kW (30amp, hardwired)
Power: 220-240 volt / 50Hz
Weight: Net - 9.5kg, Gross - 11.5kg
dimensions
Product Dimensions 590mm (L) x 520mm (B) x 56mm (D)
Cut Out Dimensions
560mm (L) x 490mm (B)
Induction 600mm
• 3 cooking zones with BOOSTERS
• Ceramic glass cooking surface
• Front Touch Controls with RED
display
• 9 power settings for each zone
• 99 minute timer
• Child lock
• Overflow protection
• Residual heat indicators
IMPORTANT INSTALLATION NOTE
When installing Electric / Induction
cooktops above a cupboard opening
or set of drawer drawers a heat shield is
required
Induction cooktops will also require a heat
barrier in the middle to ensure less transfer
of heat from fornt to back of cooktop
Refer to our website for DETAILS
warranty - customer service
2 years Parts and Labour
Our Nationwide Service Team can be
contacted on our Toll Free Customer Service
Number 1800 805 300 or by logging on to
http://customersupport.hapl.com.au/
