Summary of Contents for Home appliances ACK60
- Page 1 USER MANUAL ACK60 60CM CERAMIC COOKTOP www.arcappliances.com.au...
- Page 2 We also carry a complete range of spare parts for all Home Appliance products. For all your spare parts enquiries please contact our team at Pronto Parts on 1300 306 973 Again, thank you for choosing an appliance brought to you by Home Appliances and we look forward to being of service to you. Kind regards,...
-
Page 3: Table Of Contents
Content Foreword Foreword ..................3 1.1 Safety Warnings ................3 Safety Warnings 1.2 Installation ................. 3 1.2.1 Electrical Shock Hazard ..........3 Your safety is important to us. Please read this information 1.2.2 Cut Hazard ..............3 before using your cooktop. 1.2.3 Important safety instructions ........... -
Page 4: Electrical Shock Hazard
• Failure to install the appliance correctly could invalidate any always store safely and out of reach of children. warranty or liability claims. • Failure to use caution could result in injury or cuts. 1.3.5 Important safety instructions Operation and maintenance •... -
Page 5: Product Introduction
Ceramic glass. Congratulations on the purchase of your new Ceramic Hob. • If the supply cord is damaged, it must be replaced by the We recommend that you spend some time to read this Instruction / Installation Manual in order to fully manufacturer, its service agent or similarly qualified persons understand how to install correctly and operate it. -
Page 6: Working Principle
Working Principle How to use This ceramic cooker hob directly employs resistance wire heating, and adjust the output power by the 3.2.1 Start cooking power regulation with the mechanical controls. Place a suitable pan on the cooking zone that you wish to use. •... -
Page 7: Simmering, Cooking Rice
Boilovers, melts, and Remove these immediately with a • Remove stains left by melts and 4.1.1 Simmering, cooking rice hot sugary spills on fish slice, palette knife or razor sugary food or spillovers as soon Simmering occurs below boiling point, at around 85˚C, when bubbles are just rising occasionally to the glass blade scraper suitable for Ceramic as possible. -
Page 8: Before Locating The Fixing Brackets
L(mm) W(mm) H(mm) D(mm) A(mm) B(mm) X(mm) 560+4 490+4 50 mini Under any circumstances, make sure the ceramic cooker hob is well ventilated and the air inlet and outlet are not blocked. Ensure the ceramic cooker hob is in good work state. As shown below Note: The safety distance between the hotplate and the cupboard above the hotplate should be at least 760mm. - Page 9 1. If the cable is damaged or needs replacing, this should be done by an after-sales technician using the proper tools, so as to avoid any accidents. 2. If the appliance is being connected directly to the mains supply, an omnipolar circuit breaker must be installed with a minimum gap of 3mm between the contacts.
- Page 10 We also carry a complete range of spare parts for all Home Appliance products. For all your spare parts enquiries please contact our team at Pronto Parts on 1300 306 973 Again, thank you for choosing an appliance brought to you by Home Appliances and we look forward to being of service to you. Kind regards,...
