ASSEMBLY INSTRUCTIONS
SKU: VL-ET
Description :
Dimension
Product
Cube Size
VALENCIA RECTANGULAR NIGHT STAND END TABLE
VALENCIA RECTANGULAR NIGHT STAND END TABLE
: 22"x15.7"x28"
: 24"x17.7"x16.3"
- 1
-
175 Southbelt Industrial Dr,
Houston, TX 77047
Email:sales@eastwestfurniture.net
NW: 33 LBS
GW: 37.4 LBS
Advertisement
Table of Contents
Related Manuals for East West Furniture VL-ET
Summary of Contents for East West Furniture VL-ET
- Page 1 ASSEMBLY INSTRUCTIONS SKU: VL-ET 175 Southbelt Industrial Dr, Houston, TX 77047 Email:sales@eastwestfurniture.net Description : VALENCIA RECTANGULAR NIGHT STAND END TABLE Dimension : 22”x15.7”x28” Product Cube Size : 24”x17.7”x16.3” NW: 33 LBS GW: 37.4 LBS VALENCIA RECTANGULAR NIGHT STAND END TABLE...
- Page 2 BEFORE ASSEMBLY Thank you for purchasing our product. This product has been designed for easy assembly and long lasting use. Please take the time to read and follow the assembly instructions carefully. Be sure to check all packing material carefully for small parts that may have come loose inside the carton during shipment. Please separate, identify, and count all parts and metal hardware.
- Page 3 HARDWARE LIST When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have all of the following hardware: Description Sketch Description Sketch Bolt Bolt Screw ( M6x30mm) (M6x40mm) Screw Screw (M4x35mm) (M4x25mm) Lock washer Plat washer...
- Page 4 STEP 2 Attach shelf (C) to the legs (B) (on step 1) and attach both the other legs to the bottom frame (D) with bolt screws (2) tighten with the Allen Key (7). Use the screw driver to tighten the screws (3) as shown below.
- Page 5 STEP 4 Attach the bottom of the chest (completed in step 2) to the Chest (Step 3) with bolts (1) and washers (5), (6) . Tighten with Allen key (7). Use the screw driver to tighten the screws (4) as shown below. VALENCIA RECTANGULAR NIGHT STAND END TABLE...
