Panasonic RX-ES29GS Service Manual
Hide thumbs Also See for RX-ES29GS:
Table of Contents

Advertisement

Quick Links

Specification
n RADIO
Frequency range
FM
AM
n CD PLAYER
Sampling frequency
Decoding
Beam source
No. of channels
Wow and flutter
D/A converter
n TAPE RECORDER
Track system
Monitor system
Recording system
Erasing system
Frequency range
Normal position
n GENERAL
Speakers
All manuals and user guides at all-guides.com
87.50-108.00 MHz (50 kHz steps)
522-1629 kHz (9 kHz steps)
520-1630 kHz (10 kHz steps)
44.1 kHz
16 bit linear
Semiconductor laser (wavelength
780 nm)
2 channel, stereo
Below measurable limit
MASH (1 bit DAC)
Stereo
Variable sound monitor
AC bias
Multi Pole magnet
50-14000 Hz
8 cm 5.4Ω x 2
Portable Stereo CD System
RX-ES29GC
RX-ES29GS
RX-ES29GT
Colour
(S)..........Silver Type
Jacks
Output
Power requirement (For GC/GS)
AC
Power consumption
Power requirement (For GT)
AC
Power consumption
Battery
l Do not use rechargeable type batteries
Memory backup for
computer/clock
l Do not use rechargeable type batteries
Dimensions
Mass (For GC/GS)
Mass (For GT)
Power consumption in standby
mode (For GC/GS)
Power consumption in standby
mode (For GT)
Notes:
1. Specifications are subject to change without notice.
2. Mass and dimensions are approximate.
© 2005 Matsushita Electric Industrial Co. Ltd.. All
rights
reserved.
distribution is a violation of law.
Order No. MD0503060C3
Phones: 3.5 mm stereo (16-32Ω)
110-127 V / 220-240 V, 50/60 Hz
33 W
110 V, 60 Hz
32 W
12 V [Eight R20/LR20 (D, UM-1)
batteries]
6 V [Four R6/LR6 (AA, UM-3)
batteries]
529 mm (W) x 144 mm (H) x 276
mm (D)
4.4 kg without batteries
4.2 kg without batteries
3.0 W (117 V)
3.5W (240 V)
2.7 W
Unauthorized
copying
and
