- Page 1 ® Recycler 40 cm Model 40 cm 21020, 21022 Serial-No.: 230 000 101 & up Operator's Manual © by The Toro Company...
- Page 2 General Maintenance and Upkeep Safety Spare Parts and Troubleshooting Assembly and Start-up Hints on Tending the Lawn Operation © by TORO Company...
- Page 3 2,0 kW nance. The TORO lawn mower has been designed for the private use in the garden. Lawn mowers for the private garden are units which motor speed: 3000 min are - as a rule - in use for not more than 50 hours per year, and which are mainly used for the tending of patches of grass and lawns;...
-
Page 4: Ec Declaration Of Conformity
8111 Lyndale Ave.So. Bloomington, MN 55420-1196, USA Declare that the machine Lawnmower, walk behind with combustion engine (EN836): Type: TORO 21020 / 21022, Cuttingwidth: 40cm Conforms to the specifications of the following EC directives: 98/37/EG, 89/336/EWG, 84/538/EWG Where appropriate applied standards:... - Page 5 • after the lawn mower has hit against a foreign matter. Check regarded as inexpedient. The Toro Company is not liable for leaves and dirt. your lawn mower for damages and make the necessary damages resulting from this.
- Page 6 Read the instructions for use before starting Third parties have to be kept out of the hazardous area Warning! Rotating cutter! Keep hands and feet off Disconnect spark plug connector before servicing the cutting tool © by The Toro Company...
- Page 7 11 Oil filling pipe and oil measuring stick refer to chapter start-up 12 Air filter Cleaning refer to chapter maintenance and upkeep 13 Spark plug connector plug on spark plug before start-up 14 Carrying handles 15 Washing connection © by The Toro Company...
- Page 8 4. Fasten the upper part of the handlebar by screwing down the butterfly nut fingertight. 5. Adjust the height of the handlebar with the tommy nuts on the mower housing - asdjusting range approx. 10 cm (Fig.7). 6. Attach starter rope to handlebar eyelet (Fig. 8). © by The Toro Company...
- Page 9 1. First push the mower onto the lawn - the scale must be parallel to the ground. 2. Now you can read the length of the uncut grass on the scale and choose the recommended adjustment. setting height-of-cut B - F © by The Toro Company...
- Page 10 After sufficient fuel has been filled in, close the tank cover with manual force and wipe off spilled fuel, if any. Do not fill up fuel up to the filling pipe, but leave an ”extension space” of approx. 1 cm. © by The Toro Company...
-
Page 11: Operation
The cutter will coast for a short time. Do not touch underneath the mower. Turn the mower off when driving off the lawn. Wait until the cutters stand still and remove the spark plug connec- tor before transporting or lifting the mower. © by The Toro Company... - Page 12 Then mow with the usual adjustment. Lumpy grass and chockings inside the mowing channel effect a throttling or stop of the motor. In such cases, you should mow at least one step higher. © by The Toro Company...
- Page 13 Disconnect the spark plug connector when leaving the mower. Remove the grass-collecting device and tilt it a bit to the back so that no grass will fall out. Dump the full grass-collecting device by shaking it slightly (Fig. 24). © by The Toro Company...
- Page 14 - danger of injury! Mowing without the grass-collecting device is recommended for mowing high grass or if no grass collection is desired. Remove the grass-collecting device and the Recycler-plug (Fig. 25 + 26). © by The Toro Company...
-
Page 15: Maintenance And Upkeep
A break of the cutter can be the consequence, and parts of the cutter can be hurled away. Operate the mower only with perfect cutters! Only use original TORO spare parts or parts released by TORO. © by The Toro Company... - Page 16 Do not start motor without air filter. Dust or dirt may cause serious damage to the motor. 4. Dry insert and spray with motor oil. 5. Install air filter insert, close cover and attach air filter safely to the carburetor. © by The Toro Company...
- Page 17 5. Screw sealing plug back on. Old oil may not seep into the gound or get in the sewerage system. Collect the old oil in a larger container and deliver it to an old oil collecting place. © by The Toro Company...
- Page 18 Adjust electrode distance to 0.75 mm (Fig. 36). Insert spark plug with packing and tighten. Tightening torque: 20 Nm If a torque wrench is not available, screw spark plug tight. © by The Toro Company...
- Page 19 Clean the mower. Check all bolts, screws and nuts. Replace damaged parts. Use only original TORO spare parts resp. go to a specialized TORO-dealer. Before longer storage, empty fuel tank and let the motor run to fully consume all the fuel.
-
Page 20: Spare Parts And Troubleshooting
(Fig. 38). Always give both numbers when ordering spare parts or corre- sponding. Insert the type and serial number of your TORO lawn mower here: Type number: Serial number: Spare parts can be purchased at any TORO customer service by giving the type and serial number. -
Page 21: Troubleshooting
As soon as the motor starts, turn it off and mount the air filter element. 8. Ignition system defective (no ignition spark). 8. Consult TORO customer service. 9. Cutter is loose. 9. Consult TORO customer service. - Page 22 3. Mount correct spark plug with an electrode distance of 0.75 mm. 1. Cutter screw is loose. Motor has irregular vibrations. 1. Consult TORO customer service. 2. Cutter has not been balanced. 2. Consult TORO customer service. 3. Clean mower.
-
Page 23: Spare Parts
95-6832 Mount Adapter- Engine 92-1648 Screw 95-6732 Screw 95-6689 Screw 95-6705 Distance 95-6583 Blade 95-6792 Retainer-Blade ( incl. Ref.#14) 95-6728 Screw-Blade 95-6727 Disc 92-2289 Plate-Logo 46-6290 O - Ring 95-6537 Hose - Adapter 95-6787 Parallel-key © by The Toro Company... -
Page 24: Chassis Parts
Spring-HOC 95-6830 Rod-HOC (inl.*) 95-6741 Spacer 95-6565 Push Nut 65-6709 Decal-HOC 95-6525 Balance Spring- 95-6670 Plate-Axle Front 95-6667 Plate-Axle Rear 95-6560 Srew 95-6869 Decal Recycler 40 cm 95-6666 Smartwheel Assy. (incl. Ref. 6 & 7) © by The Toro Company... - Page 25 (incl. Ref.#13) 95-6842 Spring- Rear Door 95-6786 Handle 95-6698 Screw 95-6831 Recycler Plug 95-6575 Kicker-Middle 95-6753 Kicker-Front 95-6560 Screw 95-6552 Frame-Bag 95-6550 95-6554 Ramp-Bag 95-6573 Decal-Safety 95-6770 Bushing- Rear Door 95-6900 Manual-GB * not illustrated © by The Toro Company...
-
Page 26: Handle Parts
Ref. # 11) 95-6885 Adjusting Disk- Handle 95-6568 Holding Disk- Handle 95-6694 Bold-left 95-6740 95-6777 Bold-right 95-6569 Nut M8 95-6588 Bail - Brake 95-6592 Cable - Brake 95-6729 Screw 95-6730 95-6731 Washer 95-6710 Guide - Rope © by The Toro Company... -
Page 27: Hints On Tending The Lawn
This available, which are also manufactured by TORO. These fertilization is to be repeated according to the demands you make sprinkling systems work automatically, however, they are also on your lawn. - Page 28 The Toro Company, 8111 Lyndale Ave. So. , Bloomington, MN 55420 - 1196, USA 95-6900...
