ORDER NO. MKE0001203A1
B15 (U.S.A.), B4 (PUERTO RICO)
Compact VHS Camcorder
PV-L580 / PV-L680
Please use this manual together with the Service Manual for Order
No. MKE0001200C1; / Model No. PV-L550/ PV-L650.
