Panasonic PV-L650 Manual

Attaching Optional Filters and Lenses
When you remove the Lens Hood, pinch the Lens Hood
and turn it counterclockwise as illustrated at right.
Then attach an optional filter or lens.
• Be careful not to touch the lens itself.
• Replace the Lens Hood after removing the accessory.
Lens Hood Area Operation Caution
With a Wide or Telephoto conversion lens (optional) attached, the four corners of the
screen may darken when zoom is set to maximum wide angle.
When attaching the lens hood, a Wide or Telephoto conversion lens (optional), etc. after
a filter (optional) has been attached, the four corners of the screen may darken when
zoom is set to maximum wide angle.
With two filters (optional) attached, the four corners of the screen may darken when zoom
is set to maximum wide angle.
Cleaning EVF (Electronic Viewfinder)
To Remove
L650 p45-56

Operation Notes

1
2
3
45
A
B
Turn the EVF Eyepiece
counterclockwise 1/8 of a turn.
Pull free.
Remove any lint or dust particles
with a soft clean cloth being careful
not to scratch the glass surfaces.
To re-install EVF
Line up the marks on the Eyepiece
with the grooves inside the EVF
shaft and attach. Turn the EVF
clockwise 1/8 of a turn to lock in
place.
