WORLD HEADQUARTERS
CANADA
U.S.A.
Yorkville Sound Limited
Yorkville Sound Inc.
550 Granite Court
4625 Witmer Industrial Estate
Pickering, Ontario
Niagara Falls, New York
L1W 3Y8 CANADA
14305, USA
Voice: 905-837-8481
Voice: 716-297-2920
Fax: 905-837-8746
Fax: 716-297-3689
SERVICE MANUAL
TC112 +TC115 + TC210 +TC210NEO
+ TC410 + TC410-4 + TC412
+ TC808 + TC810 + TC1510
SMT Disclaimer
Due to the complex nature of the use of SMT installed components
in Yorkville equipment, we highly caution all service technicians in
attempting to repair or replace SMT factory installed components.
Many of these components may be glued prior to initial soldering.
Replacing SMT components requires expensive
specialized de-soldering equipment and training.
Yorkville Sound will repair and replace defective SMT components
to ensure proper quality assurance and installation is maintained.
Manual-Service-Traynor-TC-Cabinets-00-1v4 • Feb 22/2022
Advertisement
Related Manuals for YORKVILLE Traynor TC112
Summary of Contents for YORKVILLE Traynor TC112
- Page 1 Due to the complex nature of the use of SMT installed components 550 Granite Court 4625 Witmer Industrial Estate in Yorkville equipment, we highly caution all service technicians in Pickering, Ontario Niagara Falls, New York attempting to repair or replace SMT factory installed components.
-
Page 2: Important Safety Instructions
IMPORTA NT SA FETY INSTRUCTIONS This lightning flash with arrowhead symbol, within an The exclamation point within an equilatereal triangle is intended to alert the user to the presence equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous of important operating and maintenance (servicing) instructions in the literature accompanying voltage”... - Page 3 M1334 Parts Reference List 2/24/2016 YS # Description YS # Description YS # Description 5942 __3U3 100DC10%CAP BLK RAD POLYE FLM 5930 _10U 100DC 10%CAP BLK RAD POLYE FLM 3924 1/4" JCK PCB MT VERT 2XTIP HICURNT 3924 1/4" JCK PCB MT VERT 2XTIP HICURNT 3628 SPKON 4C PCB MT VERT 250TAB GRY #4 3628...
- Page 4 SPEAKER LIST: LS1004 #7459 18" 8R 800WPGM (2 IN PARALLEL) 1/4in JCK 1/4in JCK LS1208 #7460 18" 4R 1200WPGM SLEEVE SLEEVE LS608 #7459 18" 8R 800WPGM 3924 3924 LS808 #7469 18" 8R 1200WPGM LS908 #18/029Y4M 18" 8R 800WPGM LS2104 #7500 18" 4R 3000WPGM TC115 #7475 15"...
- Page 5 LS-SERIES M593 TC115 M1333 TC115 M1333 3628 3628 NOTE: SP2 IS USED ON LS1004 ONLY TIP2 TIP1 CLINCH Top Assy X8000V8.00 INSERT ORIGIN LONG AXIS ORIGIN SEE LAYOUT DOCUMENTATION...
- Page 6 SEE LAYOUT DIAGRAM PRODUCTION NOTES: X8000 HISTORY MODEL(S):- LS SERIES SUB-WOOFERS/TC115 DATE VER# DESCRIPTION OF CHANGE 1. M593 (LS-SUBS): STUFF ALL PARTS EXCEPT JUMPERS X11, X12 & X14 07-JUN-2007 V1.00 DERIVED FROM M593 LS-SUB PCB 25-SEP-2007 V2.00 ROTATED ALL THE JUMPERS TO ZERO 06-NOV-2007 V8.00 RELEASE IDENTICAL VER.
- Page 7 RAD POLY 100V 1/4in JCK SLEEVE Taper 3924 4476 4 W1:A Yorkville Sound 06/05/07 14:51:28 P1:A 300UH HORNWOOF 3784 #7543 1" 8R 40W HORN 1/4in JCK SLEEVE 3924 J4:A 300UH 3784 SPEAKON 4C 3628 100V #7474 10" #7474 10" 200WPGM...
- Page 8 100V TWEETER #7543 1" 8R 40W 5942 HORN HORN WOOFER WOOFER 4476 R T V TC410 / TC412 M1334 NL4MP-1 NL4MP-1 Yorkville 2007 BLACK YELLOW 3628 3628 BLACK HORN SPEAKON 4C SPEAKON 4C Cable tie 3903 R T V R T V...
- Page 9 SEE LAYOUT DIAGRAM PRODUCTION NOTES M1334 HISTORY MODEL(S):- TC410 / TC412 DATE VER# DESCRIPTION OF CHANGE MAY-08-2007 1.00 FIRST DESIGN FEB-04-2016 DOUBLE SIDED PCB. POTENTIOMETERS/SWITCHES AND KNOBS MODEL(S):- TC410 M1334 {TITLE} FUNCTION POT/SW YS# KNOB HF LEVEL 4476 8619...
- Page 10 FOR TC210 FOR TC1510 RAD POLY 100V 1/4in JCK SLEEVE 3924 Taper 4476 4 W1:A P1:A 300UH 3784 HORN #7543 1" 8R 40W CELESTION 1/4in JCK SLEEVE 3924 NOTE: TC210, HORN IS OUT OF PHASE J4:A SPEAKON 4C 3628 3628 SPEAKON 4C J4:B #7473 10"...
- Page 12 100V FOR TC210 NOTE: TC210 HORN IS REVERSE POLARITY 4476 370UH R T V 22AWG M1335 / M1338 TC 210/1208/1510 3805 NL4MP-1 NL4MP-1 Yorkville 2016 3628 3628 SPEAKON 4C SPEAKON 4C Cable tie CLINCH INSERT X1014 ORIGIN TC 210/1208/1510 LONG AXIS...
- Page 13 SEE LAYOUT DIAGRAM PRODUCTION NOTES X1014 HISTORY MODEL(S):- TC210 / TC1208 / TC1510 DATE VER# DESCRIPTION OF CHANGE MAY-07-2007 1.00 FIRST DESIGN 1. TC210: - M1335 26-OCT-2011 ADD TC1208 06-APR-2016 No eyelets, double sided board. - DO NOT STUFF W2 02-NOV-2021 PC#9715 TC210 M1335 V02 Replace C1 3U3 YS#5942 with 560N YS#5963.
- Page 16 25.W FUNCTION 100V 1/4in JCK 1A85 25.W 6494 3924 4476 10.W P1:A 24V0 1N5359B 220UH 3780 #7435 24V0 HORN 1N5359B FUNCTION 1/4in JCK 24V0 3924 #7435 Description: 1N5359B 8R 30W TWEETER 24V0 1N5359B J3:B FUNCTION SPEAKON 4C 500UH SPEAKON 4C 3756 FUNCTION J3:A...
- Page 17 BlankSize - 13825x12850 ETCH StepAndRepeat - X3@4.375Y1@0.0 GUIDE Cable tie 3903 PCB CONN 4 CIR BOTTOM .156 R T V 3924 3924 6494 TIP1 TIP1 4476 TC808 M1336 V1.00 SPEAKON 4C SPEAKON 4C 3628 3628 NL4MP-1 NL4MP-1 Cable tie Cable tie 3903 PCB CONN 4 CIR BOTTOM .156 R T V...
- Page 18 PRODUCTION NOTES SEE LAYOUT DIAGRAM M1336 DRILL HISTORY M1336 HISTORY MODEL(S):- TC808 MODEL(S):- TC808 DATE VER# DESCRIPTION OF CHANGE APR-27-2007 P2 CORRECT LPAD PATTERN AND DOUBLE ROUTE LINES DATE VER# DESCRIPTION OF CHANGE 24-MAY-2007 1.00 FIRST DESIGN M1336 PENDING CHANGES MODEL(S):- TC808 PENDING CHANGE...
- Page 19 M1337 HISTORY MODEL(S):- TC810 DATE VER# DESCRIPTION OF CHANGE 16-APR-2007 1V00 FIRST DESIGN UPPER SPEAKERS LOWER SPEAKERS #7287 10" 32R 100WPGM NEO #7287 10" 32R 100WPGM NEO WOOFER WOOFER UPPER 4X10 DUAL MODE OR MONO MODE IN/OUT JACK LOWER 4X10 DUAL MODE OR MONO MODE IN/OUT JACK 1/4in JCK 1/4in JCK SLEEVE...
- Page 20 StepAndRepeat - X3@4.200Y2@5.175 ETCH Pcb Mech M1337 v1.00 GUIDE Top Assy M1337 v1.00 BlankSize - 13250x11000 UPPER SPEAKERS UPPER 4X10 DUAL MODE OR MONO MODE IN/OUT JACK 3924 3924 TIP1 TIP1 LOWER 4X10 DUAL MODE OR MONO MODE IN/OUT JACK DUAL +W U TC810...
- Page 21 PRODUCTION NOTES SEE LAYOUT DIAGRAM M1337 DRILL HISTORY M1337 HISTORY MODEL(S):- TC810 MODEL(S):- TC810 DATE VER# DESCRIPTION OF CHANGE 16-APR-2007 V01 FIRST DESIGN DATE VER# DESCRIPTION OF CHANGE 16-APR-2007 1V00 FIRST DESIGN M1337 PENDING CHANGES MODEL(S):- TC810 PENDING CHANGE *PLACE IMPLEMENTED CHANGES INTO BOARD HISTORY...
- Page 22 FOR TC210 FOR TC1510 1/4in JCK 100V 100V Model SLEEVE Traper 4476 370UH P1:A TC1208 3805 #7464 4.5" 8R 30W HORN 1/4in JCK TC1510 #7573 1" 8R 40W SLEEVE NOTE: TC1208 AND TC1510, HORN IS IN PHASE J4:A SPEAKON 4C 3628 Model 3628...
- Page 23 100V FOR TC210 NOTE: TC1208/1510 HORN IS NORMAL POLARITY 4476 370UH R T V 22AWG M1335 / M1338 TC 210/1208/1510 3805 NL4MP-1 NL4MP-1 Yorkville 2016 3628 3628 SPEAKON 4C SPEAKON 4C Cable tie CLINCH INSERT X1014 ORIGIN TC 210/1208/1510 LONG AXIS...
- Page 24 SEE LAYOUT DIAGRAM M1338 PRODUCTION NOTES X1014 HISTORY MODEL(S):- TC210 / TC1208 / TC1510 DATE VER# DESCRIPTION OF CHANGE MAY-07-2007 1.00 FIRST DESIGN 1. TC210: - M1335 26-OCT-2011 ADD TC1208 06-APR-2016 No eyelets, double sided board. - DO NOT STUFF W2 - P1 RED WIRE GOES TO W4 TC1208: - M1338 - DO NOT STUFF W2...
- Page 25 #10 X 3/4 PAN PH TYPE A BLACK OXIDE 2 & 3 Corner & Handle Screws Screws Caster Screws *NOTE: Replacement grills & HF Driver supports are 'Special-Order' and are only available while the model is in production. ** Internal Lightbulb not shown SERVICE-QuickGuide-TC115-00-1v0.xls ftp.yorkville.com...
- Page 26 DATE ISSUED 25-06-07 YORKVILLE SOUND WIRE LIST MODEL:TC115 mm/dd/yy M1333 QUANTITY________/ ______ WIRE PT# COLOUR LENGTH COMMENTS WIRE CUTTING LIST WIRE PROCESS FINISHING DEP. 3940 20" ADD #3549 TO 1 END,3491 OTHER 3941 BLACK 20" SAME--------TWISTED INSERT ABOVE WIRES INTO #3558...
- Page 27 Part# Description Labeled Components 8815 8-32 X 3/4 PAN PH TAPTITE JS500 3924 1/4" JCK PCB MT VERT 2XTIP HICURNT 8619 L-PAD KNOB #TP-150-006 BLACK(SIFAM) 4476 L-PAD 50WATT 3628 SPKON 4C PCB MT VERT 250TAB GRY #4 8729 #4 X 3/8 FLAT QUAD TYPE A JS500 BLK 8906 #14X2 ALLEN FLAT HD WOOD SCRW JS500 10019...
- Page 28 DATE ISSUED 23-04-08 YORKVILLE SOUND WIRE LIST MODEL:TC210 mm/dd/yy M1335 QUANTITY________/ ______ WIRE PT# COLOUR LENGTH COMMENTS WIRE CUTTING LIST WIRE PROCESS FINISHING DEP. 3937 YELLOW 20" ADD #3549 1 END, OTHER END #3478 3941 BLACK 20" ADD #3549 1 END, OTHER END #3478...
- Page 29 DATE ISSUED 23-04-08 YORKVILLE SOUND WIRE LIST MODEL:TC410 mm/dd/yy M1334 QUANTITY________/ ______ WIRE PT# COLOUR LENGTH COMMENTS WIRE CUTTING LIST WIRE PROCESS FINISHING 3940 24" ADD #3549 1 END, #3491 OTHER. TO LOW SPK. 3941 BLACK 24" ADD #3549 1 END, #3491 OTHER...
- Page 30 DATE ISSUED 23-10-07 YORKVILLE SOUND WIRE LIST MODEL:TC808 mm/dd/yy M1336 QUANTITY________/ ______ WIRE PT# COLOUR LENGTH COMMENTS WIRE CUTTING LIST WIRE PROCESS FINISHING 3937 YELLOW 20" ADD #3549 1 END,#3491 OTHER.---- TO DRIVER ---- 3941 BLACK 20" ADD #3549 1 END,#3491 OTHER..---TWIST 3940 24"...
- Page 31 #14X2 ALLEN FLAT HD WOOD SCRW J Grille Mounting Logo Mounting Hardware Hardware 18/19 11 Sets Total *NOTE: Replacement grills & HF Driver supports are 'Special-Order' and are only available while the model is in production. ** Internal Lightbulb not shown SERVICE-QuickGuide-TC810-00-1v0.xls ftp.yorkville.com Speaker Enclosure...
- Page 32 #8 X 3/4 OVAL PH TYPE A BLACK O 8508L LARGE DISH ALUMINIZED "L" PAD D 8522 RUBBER BUMPER WITH WASHER -SMAL not shown *NOTE: Replacement grills & HF Driver supports are 'Special-Order' and are only available while the model is in production. SERVICE-QuickGuide-TC1510-00-1v0.xls ftp.yorkville.com Speaker Enclosure...
- Page 33 Yorkville Sound 550 Granite Court Pickering, Ontario Canada L1W 3Y8 www.yorkville.com Auto Attend: (905) 837-8550 Fax: (905) 837-8746...
