- Page 1 LoRaWAN indoor gateway_MG6810_User manual_V1.0.0 MG6810 LoRaWAN Indoor Pico Gateway User Manual V1.0.0 Document Information Version Time Description Remark V1.0.0 2019-9-21 Preliminary version Mike Origo Electronic Co.,LTD. www.origoelec.com...
-
Page 2: Table Of Contents
3. Mechanical and interfaces ..........................- 3 - 4. Specification ............................... - 4 - 5. Gateway config guide ..........................- 5 - 6. Installation ..............................- 9 - 7. Packing List ..............................- 11 - Origo Electronic Co.,Ltd. - 1 - www.origoelec.com... -
Page 3: General Description
LoRaWAN indoor gateway_MG6810_User manual_V1.0.0 General Description MG6810 is designed to be a fully compliant LoRaWAN gateway, with WiFi and ethernet as the backhaul （4G Optional）. It includes one or two LoRa concentrator, which provides up to 16 programmable parallel demodulation paths. This gateway is perfectly designed for indoor public network extension or for ad-hoc indoor private coverage, like manufacturing, logistics or industrial sites requiring continuous connectivity for their IoT applications. -
Page 4: Mechanical And Interfaces
Blinking 1s during data transmission Solid Green 4G connected 4G LED Blinking Blinking 1s during data transmission Solid Green LoRa1 Connected LoRa1 LED Blinking Blinking 1s during data transmission LoRa2 LED Solid Green LoRa2 Connected Origo Electronic Co.,Ltd. - 3 - www.origoelec.com... -
Page 5: Specification
− More than 10km in LoS and1～ 3km in dense environment − Average power consumption: 5W GENERAL INFORMATION: − Dimensions: 126*148*49 mm Enclosure: − Alloy − Operation temperature: -40 C~+80 − Storage temperature: -40 C~+80 Install: Strand mount/wall mount、 − Weight：0.875KG − Origo Electronic Co.,Ltd. - 4 - www.origoelec.com... -
Page 6: Gateway Config Guide
LoRaWAN indoor gateway_MG6810_User manual_V1.0.0 5. Gateway config guide 5.1 Power on Power on the device and connect the LAN port 5.2 Config Internet protocol TCP/IPv4 Control Panel→Network&internet→networking properties→TCP/IPv4. Change computer access IP to fixed IP: 192.168.15.1 Origo Electronic Co.,Ltd. - 5 - www.origoelec.com... - Page 7 Login with your user name and password. (User name: admin, Password: Admin17) 5.4 Change Password Click User→Password→Type new password→Confirm→Save →Refresh the page 5.5 Network config 5.5.1 View network status Click Network→Interfaces to view the network status Origo Electronic Co.,Ltd. - 6 - www.origoelec.com...
- Page 8 LoRaWAN indoor gateway_MG6810_User manual_V1.0.0 5.5.2 Connect to a wireless network Click Network→Wireless→Scan→Choose the wireless network you want to join→Add Origo Electronic Co.,Ltd. - 7 - www.origoelec.com...
- Page 9 LoRaWAN indoor gateway_MG6810_User manual_V1.0.0 5.6 LoRa Config 5.6.1 Server address setting 5.6.2 Gateway parameters setting Origo Electronic Co.,Ltd. - 8 - www.origoelec.com...
-
Page 10: Installation
10000 All wireless network cleared 6. Installation MG6810 series gateway has 2 installation methods: 6.1 Desktop Put the gateway on a flat surface such as the top of a table, then adjust antenna direction accordingly, which is suitable for temporary demonstration and debugging. - Page 11 The gateway should be handled gently without violent collisions and drops. The gateway should be mounted on a flat and dry surface with little dust and good ventilation. Do not expose the gateway to rain, water leakage and any humidity. Origo Electronic Co.,Ltd. www.origoelec.com - 10 -...
-
Page 12: Packing List
LoRaWAN indoor gateway_MG6810_User manual_V1.0.0 7. Packing List Item QTY(PCS) Remark MG6810 gateway Power Code EU/US/CH standards optional Ethernet cable WIFI/4G antenna LoRa antenna Wall mount bracket User manual Warranty card Gift box package, G.W:1.7KG, Dimensions: 350*300*100mm Origo Electronic Co.,Ltd. - 11 -...
