Wireless Tips........................9 Introduction Thank you for choosing a Galaxy Audio professional wireless in-ear monitor system. You have joined the ranks of countless satisfied customers. Our years of professional experience in design and manufacturing ensure our products’ quality, performance and reliability.
THIS RADIO EQUIPMENT IS INTENDED FOR USE IN PROFESSIONAL ENTERTAINMENT AND SIMILAR APPLICATIONS. Changes or modifications not expressly approved by Galaxy Audio Incorporated could void your authority to operate the equipment. Licensing of Galaxy Audio wireless microphone equipment is the user's responsibility, and licensability depends on the user's classification and application, and on the selected frequency.
System Components All AS-1200 systems include the following components: AS-1200T Transmitter AS-1200R Receiver Power Supply One Pair EB4 Ear Buds One Antenna MONO STEREO Single/Dual Rack Kit PEAK PEAK Quickstart Guide M3/10 (x6) M3/5 (x2) (For other Wireless Systems) (For Coupler) Attaching the Rack Ears What You Need for Rack Mounting: (Not Included)
AS-1200T Transmitter Features AS-1200 Wireless In-Ear Monitor System Transmitter Transmitter Features: Front Panel MONO STEREO PEAK PEAK 1 - Power Switch: Press to switch on, LCD Display will 4 - LCD Screen Channel Display light up. Press again to switch off. 2 - Channel Select: Up and Down Buttons...
AS-1200R Receiver Features AS-1200 Wireless In-Ear Monitor Body Pack Receiver Body Pack Receiver Features: Features: 1 - Antenna 2 - Stereo Headphone Jack 1/8" (3.5 mm) 3 - RF Signal LED: Lights up when RF Signal is Received. 4 - Stereo LED: LED Lights up when transmitter stereo switch is on 5 - Audio Output Control and On/Off...
System Setup - Transmitter System Setup - Transmitter Transmitter Programming: MONO STEREO Unlock the Transmitter: PEAK PEAK Press and hold the Settings button until the lock symbol disappears. Fig 1 Fig. 1 Select a Group and/or Channel, and Mono or Stereo: MONO STEREO Press the Settings button while the system is unlocked.
System Setup - Receiver System Setup - Receiver Body Pack Receiver Programming: PHONES Power On: Turn the Body Pack on by turning the volume control clock-wise. The LCD display will light up as shown in Fig 1 Fig. 1 Unlock the Receiver: Press and hold the Settings button until the lock symbol disappears.
2 (AA) size alkaline or rechargeable batteries Battery Life: About 5 hours (alkaline) Parts and Accessories Many of these parts and accessories may be found and purchased from the Galaxy Audio website in the Galaxy Store ( www.galaxyaudio.com/parts-and-accessories EXTBNC - BNC Cable for front mounting the antennas on the AS-950. For lengths available: 18", 25', 50', 100' CN-BNCPM - BNC Connector for front mounting the antennas on the AS-950.
Wireless Tips Wireless Tips Maintain line of sight between the transmitter and receiver antennas. Do not have walls, metal objects, large crowds, etc. blocking the line of sight between the transmitter and receiver. Antennas on the stationary equipment should be kept 6-8' above the ground. Antennas can be mounted on stands or walls using brackets such as the ANT-LB.
