RP3 Model T Assembly Instructions

This guide contains instructions for the assembly of your new RP3 Model T. The Model

T is delivered in two boxes, one containing the bar and one containing the flywheel

assembly, legs, seat, and tools. The machine should take roughly 30 minutes to fully

assemble. The RP3 Model T requires a space of at least 2.5 x 1.2 metres to use safely.

Check out this video for more information on assembly:

RP3 Dynamic || Model T

Unboxing - YouTube

Table of Contents

Need help?

Do you have a question about the T and is the answer not in the manual?

Page 1 The machine should take roughly 30 minutes to fully assemble. The RP3 Model T requires a space of at least 2.5 x 1.2 metres to use safely. Check out this video for more information on assembly:...
Page 2 Parts list Box 1: - Seat - Front leg - Footplate rods - Footplates (L+R) - Flywheel assembly - Rear leg - Rear leg foot - Toolset including: - 4 x bolts - 4 x nuts - Allen keys - RP3 spanner - Connection cables Box 2: - Main bar...
Page 3 Assembly Instructions 1. Firstly, assemble the rear leg by attaching the leg cylinder to the foot. 2. Attach the rear leg to the rear end of the bars using 2x bolts and nuts which sit inside the bar. The rear ends of the bars are labelled and have a slight bend about 50cm from the end to keep you in place while rowing.
Page 4 4. Remove the screws that sit in the sides of the flywheel covers that secure the transport wooden blocks and remove the blocks. Use the RP3 spanner provided. There is one on each side. 5. Carefully slide the flywheel assembly fully onto the bars so the bar comes out the back of the machine and the machine can slide freely on the bar.
Page 5 askfn 7. Attach the footplates to the machine by sliding the two rods through the footplates and the main machine assembly. Secure the rods with the stainless steel end bolts. The footplates are attached with the strap buckle on the outsides.
