LumIdent®
Do not ingest battery, Chemical Burn Hazard
This product contains a coin/button cell battery. If the coin/button cell battery is swallowed, it can cause severe internal burns in
just 2 hours and can lead to death. Keep new and used batteries away from children. If the battery compartment does not close
securely, stop using the product and keep it away from children. If you think batteries might hace been swallowd or placed inside
any part of the body, seek immediate medical attention.
CAUTION
Risk of explosion if the battery is replaced by an incorrect type
This marking indicates that this product should be disposed with other household wastes throughout the EU. To prevent possible
harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable
reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where
the product was purchased. They can take this product for environmental saf recycling.
D Verwendung nur im Innenbereich. GB Indoor use only. F Convient à un usage intérieur seulement. I Solo per applicazioni per inter-
ni. E Sólo para el uso en el interior. P Apenas para uso em interior. GR Για εσωτερική χρήση μόνο. NL Alleen voor binnengebruik. S
Endast för inomhusbruk. FIN Ainoastaan sisäkäyttöön. N Kun for innendørs bruk. DK Kun til indendørs brug. CZ Použití pouze v interiéru.
RUS Для использования только внутри помещений. H Kizárólag beltéri használatra. PL Tylko do użytku w oświetleniu wewnętrznym.
SK Pre použitie v interiéri. SLO Samo za notranjo uporabo. TR Sadece kapalı alan kullanımlı. HR Samo za unutarnju uporabu. RO Utilizare
numai la interior. BG Само за вътрешна употреба. EST EAinult siseruumides kasutamiseks. LT Skirtas naudoti tik vidaus sąlygomis. LV
Izmantošanai tikai iekštelpās. SRB Samo za unutrašnju upotrebu. UA Лише для використання усередині приміщення. KZ Тек үй ішінде
пайдалануға арналған.
LED
LumIdent®
Georg-Simon-Ohm-Straße 50
83301 Traunreut, Germany
mail: technicalsupport@siteco.de
Phone: +49 8669 / 33-844
5MA69-258112_ac
07.12.2020 / AZ
www.siteco.com
Siteco
Connect 31
5LZ910MDL401 - MOVE
5LZ910W1 . 401 - WORK
5LZ910T1 . 401 - MEET
5LZ910100
5LZ910200
5LZ910300
Siteco GmbH
- Controller
- Sensor
- Touchpanel
