INSTALLATION GUIDE AND OWNER'S MANUAL
KwickShot® Tankless Electric Water Heaters
BEFORE ATTEMPTING ANY INSTALLATION, MODIFICATION OR SERVICE OF THE
HEATER, MAKE SURE THE ELECTRICAL POWER IS DISCONNECTED.
Read and understand the instructions thoroughly before attempting the installation or service of the water heater. Failure
to follow the instructions can result in serious injury, death and/or property damage. The warranty of the water heater will
depend upon proper installation according to the instructions. Some heaters come supplied with separate faucet aerators.
If supplied, the aerator must be installed in the faucet for optimum performance. The heater must only be used to heat
water and must be installed in a location where it is not subject to freezing temperatures. The manufacturer is not liable for
any damages resulting from improper installation or misuse.
The installation must conform to the latest requirements of the National Electrical Code and all applicable state and local
codes. This information is available through local authorities. You must fully understand the requirements before
beginning this installation.
This water heater is not required by UL 499 to employ a temperature and pressure relief valve (T&P). Check with local
codes to find out if one is required. If it is, the T&P valve must be installed in the outlet hot water pipe between the heater
and the isolation valve.
IMPORTANT SAFETY INSTRUCTIONS
When using electrical equipment, basic safety precautions should always be followed, including the following:
READ AND FOLLOW ALL INSTRUCTIONS
Supply the water heater only from a grounded system. A green terminal (or a wire connector marked "G", "GR, "Ground",
or "GROUNDING") is provided for wiring the appliance. To reduce the risk of electric shock, connect this terminal, or
connector, to the grounding terminal of the electric service or supply panel with a continuous copper wire. Connection
should be made in accordance with the electrical installation code.
Information contained in this document is subject to change without notice.
1
238-54367-00A REV 09/21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KwickShot and is the answer not in the manual?

Questions and answers

Summary of Contents for Bradford White KwickShot

  • Page 1 INSTALLATION GUIDE AND OWNER’S MANUAL KwickShot® Tankless Electric Water Heaters BEFORE ATTEMPTING ANY INSTALLATION, MODIFICATION OR SERVICE OF THE HEATER, MAKE SURE THE ELECTRICAL POWER IS DISCONNECTED. Read and understand the instructions thoroughly before attempting the installation or service of the water heater. Failure to follow the instructions can result in serious injury, death and/or property damage.
  • Page 2: Table Of Contents

    Bradford White offers thermostatic, and flow controlled tankless electric water heaters. KwickShot® thermostatic heaters are designed to accept cold or preheated water and heat it to temperatures suitable for normal domestic usage up to a maximum temperature setpoint of 140°F.
  • Page 3: Mounting The Unit To The Wall

    “CA” option models: Manufactured for Canadian market and it indicates evaluation and compliance to either Underwriters Laboratories (UL) or Intertek (ETL) under CAN/CSA-C22.2 No. 64/No. 88. KwickShot® flow-controlled heaters are designed to take in cold water and heat it to temperatures suitable for handwashing and other fixed-flow applications.
  • Page 4: Plumbing Hook-Up

    DAMAGE TO THE HEATER WILL RESULT. DOING THIS WILL VOID THE WARRANTY! Bradford White strongly recommends that the heater be supplied directly from the main cold-water trunk line when possible. This helps to avoid a potential water flow interruption to the water heater which could lead to a failure of the heating element.
  • Page 5 For optimum performance, Bradford White recommends the use of isolation valves (full flow ball type) on the inlet and outlet pipes and a 40 mesh Y-Strainer on the inlet of the heater. Clean the screen periodically for best performance. BEFORE ATTEMPTING ANY INSTALLATION, MODIFICATION OR SERVICE OF THIS HEATER, MAKE SURE THE ELECTRICAL POWER IS DISCONNECTED.
  • Page 6 Sample installation diagrams: Note: KwickShot® Thermostatic Models only Open the hot water faucet and run water for a minimum of 60 seconds and until the flow is continuous and free of air pockets. Close the faucet and install the aerator (if supplied).
  • Page 7: Electrical Hook-Up

    SECTION 4: ELECTRICAL HOOK-UP BEFORE BEGINNING ANY WORK ON THIS INSTALLATION, CONFIRM THE ELECTRICAL BREAKER IS “OFF” AND THAT ALL MOUNTING AND PLUMBING WORK HAS BEEN COMPLETED PER THE STATED INSTRUCTIONS. For use on an individual branch circuit only. The heater shall be installed using insulated, UL listed, 2 wire cable (2 wire plus ground) of the appropriate size suitable for up to 75°C and protected by the correctly rated circuit breaker.
  • Page 8 Power cable entry to the heater should be made through one of the knock-out holes located on the back plate or top/bottom ends of the unit. Use the appropriate strain relief fitting. The power leads are to be secured to the L1 and L2 or L and N connectors on the terminal block or relay.
  • Page 9: Commissioning The Heater

    The following steps are dependent on the water heater, please be sure to read all instructions to best commission the appropriate model. KwickShot® Flow Controlled Models The LED indicator light will flash rapidly while water flows through the unit. Maintain flow.
  • Page 10 Congratulations! Your KwickShot® tankless electric water heater is installed and ready for use! For temperature rise at specified flow rate, please consult the table below: BASE MODEL* FLOW RATE, GPM (LPM) KwickShot® (0.76) 0.25 (0.95) (1.14) (1.51) (1.89) (2.65) (3.03) (3.79)
  • Page 11 SECTION 6: KwickShot® THERMOSTATIC MODEL OPERATION Factory temperature setpoints/maximum adjustable range: KwickShot® Default Minimum Maximum Thermostatic Setpoint Setpoint Setpoint models (°F) (°F) (°F) Base Model <4kW >4kW ML (Multi Lavatory) CHANGING SETPOINT TEMPERATURE To INCREASE temperature, tap the “+” button repeatedly, or hold the “+” down to INCREASE the temperature quickly. To DECREASE temperature, tap the “–”...
  • Page 12 Information contained in this document is subject to change without notice. 238-54367-00A REV 09/21...
  • Page 13: Troubleshooting

    SECTION 7: TROUBLESHOOTING ENSURE POWER TO THE UNIT IS “OFF” BEFORE REMOVING THE PROTECTIVE COVER FOR ANY REASON. For status resolution, please consult the table for your heater model below. KwickShot® Thermostatic models Code Name Possible causes Heater response Possible solutions...
  • Page 14 KwickShot® Flow controlled models LED Pattern Status/Problem Possible causes Heater response Possible solutions Solid light Heating One flash every four Idle - unit waits for flow seconds Two flashes once, Low heat - outlet temperature below 90°F/32°C - unit keeps running,...
  • Page 15: Periodic Maintenance

    The heater is designed for many years of carefree use. In order to maintain consistent water flow, it may be necessary to periodically clean the faucet aerator, or the filter screen located in the brass inlet fitting at the heater. Element cartridge installs inside heating chamber of all heaters KwickShot® Flow controlled models KwickShot® Thermostatic models Triacs Heating chamber Triacs...
  • Page 16: Repair Parts

    SECTION 10: REPAIR PARTS KwickShot® Thermostatic models KwickShot® Flow controlled models MODEL ELEMENT CONTROL RELAY MODEL ELEMENT NUMBER* CARTRIDGE BOARD CONTROL BOARD RELAY NUMBER* CARTRIDGE TEF024V120 EX610 EX383 EX250B TEF030V120 EX480 EX383 EX250B TET055V240 EX1050 EX384-240 EX255B TEF035V120 EX410 EX383...
  • Page 17 GUIDE D'INSTALLATION ET MANUEL D'UTILISATION ® Chauffe-eau électriques sans réservoir KwickShot AVANT DE TENTER TOUTE INSTALLATION, MODIFICATION OU ENTRETIEN DU AVERTISSEMENT CHAUFFE-EAU, ASSUREZ-VOUS QUE L'ALIMENTATION ÉLECTRIQUE EST DÉBRANCHÉE. Lisez et comprenez attentivement les instructions avant de tenter l'installation ou l'entretien du chauffe-eau. Le non- respect des instructions peut entraîner des blessures graves, la mort et/ou des dommages matériels.
  • Page 18 Des valves de limitation de température sont disponibles. SECTION 1 : GÉNÉRALITÉS Bradford White propose des chauffe-eau électriques sans réservoir thermostatiques et à débit contrôlé. ® Les chauffe-eau thermostatiques KwickShot sont conçus pour accepter de l'eau froide ou préchauffée et la chauffer à...
  • Page 19: Montage De L'appareil Au Mur

    à d'autres applications à débit fixe. ® AVIS : Les chauffe-eau électriques sans réservoir KwickShot sont testés à 125 degrés selon le Department of Energy (DOE) 10CFR Part 430, Energy Conservation Program for Consumer Products.
  • Page 20: Raccordement De Plomberie

    CHAUFFE-EAU. FAIRE CELA ANNULERA LA GARANTIE ! Bradford White recommande fortement que le chauffe-eau soit alimenté directement à partir de la conduite principale d'eau froide lorsque cela est possible. Cela permet d'éviter une interruption potentielle du débit d'eau vers le chauffe-eau, ce qui pourrait entraîner une défaillance de du chauffe-eau.
  • Page 21 Pour des performances optimales, Bradford White recommande l'utilisation de vannes d'isolement (type à bille à plein débit) sur les tuyaux d'entrée et de sortie et une crépine en Y de 40 mailles à l'entrée du chauffe-eau. Nettoyez l'écran périodiquement pour de meilleures performances.
  • Page 22 électrique électrique ® Remarque : modèles thermostatiques KwickShot uniquement Ouvrez le robinet d'eau chaude et faites couler l'eau pendant au moins 60 secondes et jusqu'à ce que le débit soit continu et sans poches d'air. Fermez le robinet et installez l'aérateur (si fourni).
  • Page 23: Branchement Électrique

    SECTION 4 : BRANCHEMENT ÉLECTRIQUE AVANT DE COMMENCER TOUT TRAVAIL SUR CETTE INSTALLATION, VÉRIFIEZ QUE LE AVERTISSEMENT DISJONCTEUR ÉLECTRIQUE EST « OFF » ET QUE TOUS LES TRAVAUX DE MONTAGE ET DE PLOMBERIE ONT ÉTÉ EFFECTUÉS CONFORMÉMENT AUX INSTRUCTIONS INDIQUÉES. À...
  • Page 24 L'entrée du câble d'alimentation vers le chauffe-eau doit être effectuée par l'un des trous situés sur la plaque arrière ou aux extrémités supérieure/inférieure de l'unité. Utilisez le raccord de décharge de traction approprié. Les câbles d'alimentation doivent être fixés aux connecteurs L1 et L2 ou L et N du bornier ou du relais.
  • Page 25: Mise En Service Du Chauffe-Eau

    Les étapes suivantes dépendent du chauffe-eau, assurez-vous de lire toutes les instructions pour mettre en service au mieux le modèle approprié. ® Modèles à débit contrôlé KwickShot Le voyant LED clignotera rapidement pendant que l'eau s'écoule à travers l'unité. Maintenir le débit.
  • Page 26 Toutes nos félicitations! ® Votre chauffe-eau électrique sans réservoir KwickShot est installé et prêt à l'emploi! Pour la température souhaitée au débit spécifié, veuillez consulter le tableau ci-dessous : MODÈLE DE DÉBIT, GPM (LPM) BASE* (0,76) 0,25 (0,95) (1,14) (1,51)
  • Page 27 ® SECTION 6 : FONCTIONNEMENT DU MODÈLE THERMOSTATIQUE KwickShot Consignes de température d'usine/plage maximale réglable : Modèles Point de Point de Point de thermostatique consigne consigne consigne ® s KwickShot par défaut minimum maximum (°F) (°F) (°F) Modèle de base <4kW...
  • Page 28 Point de Consigne Avancé Codes d'erreur et d'unités Maintenez + et - pendant 3s Point de consigne de Débit Maintenez + et - pendant 10s Erreurs actuelles température Maintenez + et - pendant 3s Cliquez sur + pour la prochaine erreur Cliquez sur Maintenez + pendant 1s...
  • Page 29: Dépannage

    MISE EN GARDE RETIRER LE COUVERCLE DE PROTECTION POUR QUELQUE RAISON QUE CE SOIT. Pour la résolution de l'état, veuillez consulter le tableau pour votre modèle de chauffage ci-dessous. ® Modèles thermostatiques KwickShot Code Causes possibles Réponse du chauffe-eau Solutions possibles Pas de - défaillance de l'élément...
  • Page 30 ® Modèles à débit contrôlé KwickShot Modèle LED État/Problème Causes possibles Réponse du chauffe-eau Solutions possibles Lumière fixe Chauffage N / A N / A N / A Un flash toutes les Inactif N / A - l'unité attend le débit...
  • Page 31: Entretien Périodique

    La cartouche d'élément s'installe à l'intérieur de la chambre de chauffage de tous les chauffe-eau Modèles à débit contrôlé KwickShot ® Modèles thermostatiques KwickShot ® Chambre de...
  • Page 32: Pièces De Réparation

    ARTICLE 10 : PIÈCES DE RÉPARATION ® ® Modèles thermostatiques KwickShot Modèles à débit contrôlé KwickShot NUMÉRO DE CARTOUCHE TABLEAU DE RELAIS NUMÉRO DE CARTOUCHE TABLEAU DE MODÈLE* D'ÉLÉMENT CONTRÔLE RELAIS MODÈLE* D'ÉLÉMENT CONTRÔLE TEF024V120 EX610 EX383 EX250B TEF030V120 EX480...
