Installation - Patching Panda OPERAT User Manual

INTRODUCTION:
Operat is a highly functional, analog oscillator with a multitude of blendable
modulation features, making it a module that is just as good as a collaborator
as it is a solo module. Operat offers four basic waveshapes hat are blendable
via an internal mixer, offering a sine, triangle, saw and square wave.
These waves not only have their individual output, but they additionally
have their own individual mixer with CV inputs for introducing complexity at an
early stage, use it as a VCA or for amplitude modulation! The square wave's
pulse width can be modulated via the PWM control, CV input with three different
flavors to choose from for adding variety to PWM.
The Sync input can act as hard or soft sync to force Operat to any other VCO´s
base frequency, a desirable effect to modulate with the additional exp FM input.
Modulate the internal mixer's final output with either AM or RM for metallic
timbres, and a blendable dry/wet control allows you to determine how much of
the effect is heard.
Thru-Zero FM/PM producing a wide range of timbres that can be introduced with
the symmetry parameter, offering subtle sonic shifts to in-your-face aggression.
Operat can act as a VCO or LFO, making it just as great of a tonal source as
much as a modulation source.

INSTALLATION:

.
* Disconnect your synth from the power source.
* Double check polarity from the ribbon cable, unfortanetly if you damage
the module by powering in the wrong direction it will not be covered by
the warranty.
* After connecting the module check again you have connected the right
way, the red line must be on the -12V
