Patching Panda OPERAT User Manual

Download this manual

OPERAT

USER MANUAL

Need help?

Do you have a question about the OPERAT and is the answer not in the manual?

Page 1 OPERAT USER MANUAL...
Page 2: Installation
Thru-Zero FM/PM producing a wide range of timbres that can be introduced with the symmetry parameter, offering subtle sonic shifts to in-your-face aggression. Operat can act as a VCO or LFO, making it just as great of a tonal source as much as a modulation source.
Page 3 MIX output Square signal mix level Ramp signal mix level Square signal out Triangle signal mix level Ramp signal out Sine signal mix level Triangle signal out TZ modulation amount Sine signal out Modulation Symmetry and V/OCT input waveform inversion PWM CV input TZ-FM or PM switch AM-RM Mod input...
Page 4 Hard sync occurs at any point in the oscillating cycle. Operat is a new-generation voltage controlled oscillator with different The HARD SYNC has two modes of operation. modulation inputs. If held high it stops the oscillator. This can be used to force the VCO to stop and wait for some future event.
Page 5 CALIBRATION: Set Symmetry pot in the middle, Coarse, Fine Tune pots to minimum. Connect the CV out from your sequencer to V/OCT input, send the SINE out to your DAW. In your DAW open tuner VST to monitore notes. Send C1 from your sequencer, in your DAW monitor the output while turning the multiturn trimmer to read C1.
