Koden KGC-1 Operation Manual
  1. Manuals
  2. Brands
  3. Koden Manuals
  4. Compass
  5. KGC-1
  6. Operation manual

Koden KGC-1 Operation Manual

Gps compass
Hide thumbs Also See for KGC-1:

Advertisement

Quick Links

Advertisement

loading
Need help?

Need help?

Do you have a question about the KGC-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Koden KGC-1

Summary of Contents for Koden KGC-1

  • Page 3 No part of this publication may be reproduced, transmitted, translated in any form by any means without the written permission of Koden Electronics Co., Ltd. The technical descriptions contained in this publication are subject to change without notice. KODEN assumes no responsibility for any errors, incidentals or consequential damages caused by misinterpretation of the descriptions contained in this publication.
  • Page 4 KGC-1 Preface Preface Keep this operation manual free from lost and damage. Handling this book When the ownership of this equipment is changed due to resale or delivery, please deliver without fail this operation manual to the new owner. SAFETY PRECAUTIONS Symbols used in this manual The following symbols are used in this manual.
  • Page 5 Preface KGC-1 OPERATIONAL PRECAUTIONS This equipment is a navigational aid. For a final determination of navigational command, you should consult regular navigational map Warning chart and other navigational devices in determining own position, depth, information of approaching targets, obstacles, etc, for safer navigation.
  • Page 6 Preface How to use this manual Scope of this manual This manual contains information about installation, operation and maintenance of the KGC-1 GPS Compass unit. Structure of this manual This manual is divided into sections according to the contents as described below. This arrangement will help you overview the whole of the contents as well as refer to detailed information for your specific requirement.
  • Page 7 Preface KGC-1 Unpacking goods Inspection of component unit and accessories Siting the units Instructions for installation Cable layout and connections Connecting the units Check up after installation Chapter 5: Operation Panel layout and operating switches Output ports Selecting the output data...

  • Page 8: Table Of Contents

    KGC-1 Chapter 1 Operation Manual General Chapter 1 General Page No. 1.1 About GPS compass ..............1-1 1.1.1 Principle of GPS positioning system............1-1 1.1.2 How the GPS Compass works ............1-1 1.1.3 For proper use of GPS Compass ............1-1 1.2 Equipment overview..............1-2 1.3 Applicable technical standards............1-2...

  • Page 9: About Gps Compass

    KGC-1 Chapter 1 Operation Manual General Chapter 1 General About GPS compass 1.1.1 Principle of GPS positioning system GPS (Global Positioning System) is a position measuring system using the artificial satellites, which consists 27 artificial satellites (4 satellites per orbit x 6 orbits plus 3 reserve satellites), orbiting the earth every 11hours 58 minutes along a circular path above the earth.

  • Page 10: For Proper Use Of Gps Compass

    From the radio wave broadcast from the GPS satellites, the KGC-1 computes own ship’s bearing in high accuracy by measuring the phase difference between two GPS antennas. Four output ports are available on the KGC-1, two for the compass bearing output, the other two for the GPS position/speed data.
  • Page 11 KGC-1 Chapter 1 Operation Manual General Software type name Application KM-D92 (Program ROM) System control KM-D93 (Program ROM) System control 93121652-01...
  • Page 12 Rectifier PS-003A AC Power Cable VV-2D8-3M To Ship’s AC Supply To Ship’s Main Supply 100/115 VAC 10.8 ~ 31.2 VDC 200/230 VAC The chained lines are optional cables for connecting extra external units. Fig. 1.2 KGC-1 System connecting diagram 93121652-01...
  • Page 13 KGC-1 Chapter 2 Operation Manual Equipment Composition Chapter 2 Equipment Composition Page No. Standard equipment list ............2-1 Spare Parts list................2-1 Installation Material list ............. 2-1 Available antenna cable types ..........2-2 2.5 Optional items list..............2-2 93121652-00 Contents...

  • Page 14: Standard Equipment List

    KGC-1 Chapter 2 Operation Manual Equipment Composition Chapter 2 Equipment Composition 2.1 Standard equipment list Item name Type name Remarks Weight/Length Q’ty １ １ Processor unit KGC-1 1.2kg GPS antenna GA-11 1.4kg １ DC Power cable CW-255-2M Antenna cable CW-392-15M...

  • Page 15: Available Antenna Cable Types

    Chapter 2 KGC-1 Equipment Composition Operation Manual 2.4 Available antenna cable types Type name Cable length Cable type Mating connector CW-392-15M 3D-2V BNC (both ends) (Standard) CW-393-30M 5D-FB BNC (both ends) (Option) CW-394.KIT 8D-SFA - Type N connector one end /...
  • Page 16 3.1 Functional specification .............. 3-1 3.2 Serial data .................. 3-1 3.3 Power supply requirements ............3-2 3.4 Compass safety distance ............3-2 3.5 Environmental conditions ............3-2 3.6 External dimensions and weight..........3-3 3.6.1 Processor unit KGC-1..............3-3 3.6.2 GPS Antenna GA-11..............3-4 93121652-00 Contents...

  • Page 17: Functional Specification

    KGC-1 Chapter 3 Operation Manual Specifications Chapter 3 Specifications 3.1 Functional specification Specification is subject to change without notice. Type Processor unit: KGC-1 GPS antenna: GA-11 Receiving frequency 1575.42MHz±1MHz Receiving channel Parallel 9 channel Sensitivity Better than -130dBm Setting time...

  • Page 18: Power Supply Requirements

    Chapter 3 KGC-1 Specifications Operation Manual Navigation data Satellite in use and DOP Navigation data Available satellite PKODA Navigation data Satellite information *KODEN proprietary format PKODG1 Navigation data Satellite information *KODEN proprietary format PKODG7 Navigation data Satellite information *KODEN proprietary format 3.3 Power supply requirements...

  • Page 19: External Dimensions And Weight

    Chapter 3 Operation Manual Specifications 3.6 External dimensions and weight 3.6.1 Processor unit KGC-1 External dimensions: 220 (W) x 245 (D) x 85 (H), unit in mm Weight: 1.2kg [External dimensions] Unit: mm(inch) Fig. 3.1 External dimensions of KGC-1 93121652-00...
  • Page 20 Chapter 3 KGC-1 Specifications Operation Manual 3.6.2 GPS Antenna GA-11 External dimensions: 593 (W) x 150 (D) x 160(H), unit in mm Weight: 1.4kg [External dimensions] Unit: mm (inch) Fig. 3.2 External dimensions of GA-11 93121652-00...
  • Page 21 KGC-1 Chapter 4 Operation Manual Installation Chapter 4 Installation Page No. 4.1 Installation consideration ............4-1 4.2 Unpacking goods................4-1 4.3 Inspection of component unit and accessories......4-1 4.4 Siting the unit................4-1 4.4.1 Ideal site of GPS antenna..............4-1 4.4.2 Siting the Processor unit..............4-2 4.5 Instructions for installation ............4-3...

  • Page 22: Installation Consideration

    KGC-1 Chapter 4 Operation Manual Installation Chapter 4 Installation 4.1 Installation consideration Installation of the GPS Compass must be made by qualified personnel, which is essential for good and prolonged operation of the unit. Installation includes the following; (1) Unpacking the contents (2) Inspecting the component unit, spare parts, accessories.

  • Page 23: Siting The Processor Unit

    Chapter 4 KGC-1 Installation Operation Manual requirements of item (10) and install the GPS Antenna as far as possible from the antennas described in item (1) to item (9). Put the GPS Antenna as trial on a promising site to make sure that the unit operates as specified before fixing the GPS Antenna position and then fix the antenna firmly.

  • Page 24: Instructions For Installation

    KGC-1 Chapter 4 Operation Manual Installation 4.5 Instructions for installation 4.5.1 GPS Antenna installation The GPS Antenna should be installed, as shown in Fig. 4.2, on the keel line with the BOW mark oriented to the ship’s bow. If this is not possible due to the ship’s superstructure, the antenna may be moved in parallel to the keel line.

  • Page 25: Gps Antenna Ga-11

    Chapter 4 KGC-1 Installation Operation Manual For efficient maintenance work after the installation, we recommend marking with a permanent marker or felt pen on both ends of the bow side antenna cable. This makes things easier when reconnecting the cable to the bow side antenna.

  • Page 26: Installing The Bird Repellent Fixture

    KGC-1 Chapter 4 Operation Manual Installation 4.5.1.1 Installing the Bird repellent fixture Sea birds such as seagulls may be the cause of poor reception of the GPS signal when perched on top of the GPS antenna unit. The use of bird repellent fixtures is recommended to alleviate this problem.

  • Page 27: Heading Adjust

    Chapter 4 KGC-1 Installation Operation Manual 4.5.1.2 Heading adjust For post-positional adjustment, the fixing holes on the antenna arm are elongated. If the GPS Antenna direction shifts after fixing, loosen the fixing bolts and gently rotate the entire antenna body to face the correct direction.

  • Page 28: Connecting The 60M Antenna Cable Kit Cw-394.Kit To Gps Antenna

    KGC-1 Chapter 4 Operation Manual Installation 4.5.1.4 Connecting the 60m antenna cable kit CW-394.KIT to GPS Antenna The optional 60 m length cable kit, CW-394.KIT, is composed of the Antenna cable CW-394-60M and the N-to BNC conversion connector. Connect the GPS Antenna and Processor unit via the cable kit as shown in the following figure.

  • Page 29: Installing The Processor Unit

    Chapter 4 KGC-1 Installation Operation Manual 4.5.2 Installing the Processor unit Place the Processor unit and fix it with 4 pieces of 5 mm screw. (The 5 mm screws are not supplied with the unit. Please arrange the suitable screws locally) Unit: mm (inch) Fig.

  • Page 30: Connecting The Units

    Stern side Antenna cable Fuse (3A) Nav data output (NMEA0183) Power rectifier PS-003A Bearing data output (NMEA0183/IEC61162) To ship’s mains supply To ship’s AC supply 10.8 ~ 31.2 VDC 100/115 VAC or, 200/230 VAC Fig. 4.10 Interconnection diagram of KGC-1 93121652-00...

  • Page 31: Connectors Pinouts Of On The Processor Unit

    Chapter 4 KGC-1 Installation Operation Manual 4.7.1 Connectors pinouts of on the Processor unit POWER ALARM DATA POWER DATA1 DATA3 ANT1 DATA4 MODE DATA2 ANT2 Locations of connectors on the Processor unit DC 入力（10.8 ~ 31.2VDC NMEA / IEC61162 IN/OUT ）...

  • Page 32: Connecting The Data Connecting Cable Cw-376-5M

    * The cables with connectors are available on optional basis. Select a suitable cable listed in Para. 2.5 “Optional items list” and Fig. 1.2 “KGC-1 System connecting diagram” in Chapter 1. Appendix Connecting the Data cable CW-376-5M to PC D-SUB 9 pin Blue &...
  • Page 33 KGC-1 Chapter 5 Operation Manual Operation Chapter 5 Operation Page No 5.1 Panel layout and operating switches ··············································· 5-1 5.1.1 POWER switch ····················································································5-1 5.1.2 MODE switch·······················································································5-1 5.1.3 POWER lamp ······················································································5-1 5.1.4 ALARM lamp ·······················································································5-1 5.1.5 DATA lamp···································································································································5-1 5.2 Output port ······················································································ 5-2 5.3 Selecting the output data·································································...
  • Page 34 KGC-1 Chapter 5 Operation Manual Operation Chapter 5 Operation 5.1 Panel layout and operating switches POWER lamp ALARM lamp DATA lamp POWER switch MODE switch Fig. 5.1 Panel layout on the Processor unit 5.1.1 POWER switch This switch is used to turn on and off the GPS Compass unit.
  • Page 35 Operation Manual 5.2 Output port The KGC-1 has 4 output ports. From the DATA1 and DATA2 ports the bearing data output is available at 50 m sec interval From DATA3 and DATA4 ports the navigation data is output at 1 sec interval.
  • Page 36 KGC-1 Chapter6 Operation Manual Maintenance and Trouble shooting Chapter 6 Maintenance and troubleshooting Page No. 6.1 Periodic inspection and cleaning ·············································· 6-1 6.1.1 Monthly check ·····················································································6-1 6.1.2 Maintenance························································································6-1 Trouble shooting ······································································ 6-1 6.2.1 Information required for service··························································6-1 6.2.2 Trouble shooting ···············································································6-1 6.2.3 Replacing the memory back-up battery ··············································6-4...
  • Page 37 KGC-1 Chapter6 Operation Manual Maintenance and Trouble shooting Chapter 6 Maintenance and troubleshooting 6.1 Periodic inspection and cleaning 6.1.1 Monthly check Check if there are any loose connections on the Processor unit for GPS Antenna, radar or navigational unit. 6.1.2 Maintenance If the Processor unit is smeared or stained with dirt, wipe the surface of the unit with a soft dry cloth.
  • Page 38 Chapter6 KGC-1 Maintenance and Trouble shooting Operation Manual Faults detected Possible cause of the failure Remedial action The POWER lamp lights 1. Is the GPS Antenna connector 1. Make sure that the GPS but the DATA lamp does firmly connected? Antenna and Processor unit not light or flash.
  • Page 39 1 sec. pause or, 9 long interval flashes with a one second pause: the processing section may be faulty. Record flashing interval inform your local KODEN dealer for service. Incorrect bearing data is Are the antenna connections 1. If antenna output.
  • Page 40 Chapter6 KGC-1 Maintenance and Trouble shooting Operation Manual 6.2.3 Replacing the memory back-up battery The memory back-up battery (Back-up battery, hereafter) is installed in the battery cradle EA1, which is mounted on the Main Printed Board (D73-700*) in the Processor unit. The location of the battery is shown in Fig.
  • Page 41 KGC-1 Chapter 7 Operation Manual Technical References Chapter 7 Technical References Page No. 7.1 Detail of the serial output data····························································7-1 7.1.1 Start bit configuration of output data ·························································7-1 7.1.2 Serial data specification············································································7-1 7.1.3 Detail of output sentences ········································································7-1 7.2 Data input/output serial line ································································7-5 7.3 Setting the Status switch ····································································7-6...
  • Page 42 KGC-1 Chapter 7 Operation Manual Technical References Chapter 7 Technical References 7.1 Detail of the serial output data Serial data name: NMEA0183 Ver.2.0 or IEC61162-1 7.1.1 Start bit configuration of output data A single bite data is configured as follows:...
  • Page 43 Chapter 7 KGC-1 Technical References Operation Manual Rate of turn $ GPROT, 0/-xxx.x, a *hh <CR><LF> Checksum (-Neg)/ Angular speed, deg/min Status A: Valid Sentence name V: Void Talker device Start of sentence GPS position data $ GP GGA, hhmmss, xxxx.xxx, N/S, xxxxx.xxx, E/W, x, xx,...
  • Page 44 KGC-1 Chapter 7 Operation Manual Technical References Available satellite $GPGSV , x , x , xx , xx , xx , xx , xx ,･････････････････ *hh <CR><LF> Sentence sv, 3 sv ….. Checksum name S/N (Signal to Noise ratio) Bearing angle...
  • Page 45 A: Data valid Talker device D: Data void Start of sentence PKODA Satellite information (KODEN proprietary sentence) $ PKODA, P/H, xxx.x, xx, xx, xx, xx, xx, xx, xx, xx, xxx, M, xxx.x, N, xxx.x, 0/-xx.x, x, x <CR><LF> PDOP Satellite No. value Satellite No.
  • Page 46 KGC-1 Chapter 7 Operation Manual Technical References 7.2 Data input/output serial line Port (connector) name: DATA1 ~ DATA4 The connector used: LTWBD-06BFFA-L180 +Vcc Serial Data input (listener side): The IEC 61162-1 standard signal can be received. Input load: 470 ohms...
  • Page 47 10 seconds, turn the unit off and reset the No.7 to OFF. If the switch element No. 7 is left to ON, the unit will be initialized each time the unit is turned on. Status switch 1 2 3 4 5 6 7 8 Fig 7.1 The location of the Status switch in KGC-1 Processor unit 0093121652-04...
