MODEL #14100
SPECIFICATIONS:
Hose diameter: 5/8 inches
Inlet hose length: 6 feet / 2 meters
Max. Operating pressure: 75 psi
PACKAGE CONTENTS
A. Instruction Manual
B. Hardware Pack
C. Hose Reel
D. Mount Bracket
EarthWay 14100 – 100' Hose Reel
Thank you for selecting EarthWay for your
lawn and garden needs.
Our customer support team is standing ready to
ensure your success. Please visit our website to
see our other lawn & garden tools.
B.1 x 4
100 Foot Length
ASSEMBLY INSTRUCTIONS
IMPORTANT
READ THE ENTIRE GUIDE BEFORE INSTALLATION
OR USE.
CONNECT ONLY TO WATER SOURCE WITH
PRESSURE AT OR BELOW 75 PSI.
RELEASE WATER PRESSURE WHEN NOT IN USE.
PRODUCT CONTAINS CHARGED SPRING. DO NOT
DISASSEMBLE HOUSING.
DO NOT DRINK FROM HOSE.
ALLOW WATER TO RUN FOR 30 SECONDS.
BACTERIA WILL FORM IN STANDING WATER.
IN FREEZING CLIMATES – BEST OPTION IS TO TAKE
REEL INDOORS. OTHERWISE, DISCONNECT &
COMPLETELY UNCOIL HOSE TO DRAIN
REMAINING WATER.
Hose Reel
PAGE 1
