MODEL #14050
SPECIFICATIONS:
Hose diameter: 5/8 inches
Inlet hose length: 6 feet / 2 meters
Max. operating pressure: 75 psi
PACKAGE CONTENTS
A. Instruction Manual
B. Hardware Pack
C. Hose Reel
D. Mount Bracket
EarthWay 14050 – 50' Hose Reel
ASSEMBLY INSTRUCTIONS
Thank you for selecting EarthWay for your lawn
and garden needs.
Our customer support team is standing ready to
ensure your success. Please visit our website to
see our other lawn & garden tools.
IMPORTANT
▪ READ THE ENTIRE GUIDE BEFORE INSTALLATION
OR USE.
▪ CONNECT ONLY TO WATER SOURCE WITH
PRESSURE AT OR BELOW 75 PSI.
▪ RELEASE WATER PRESSURE WHEN NOT IN USE.
▪ PRODUCT CONTAINS CHARGED SPRING. DO NOT
DISASSEMBLE HOUSING.
▪ DO NOT DRINK FROM HOSE.
▪ ALLOW WATER TO RUN FOR 30 SECONDS.
BACTERIA WILL FORM IN STANDING WATER.
▪ IN FREEZING CLIMATES – BEST OPTION IS TO TAKE
REEL INDOORS. OTHERWISE, DISCONNECT &
COMPLETELY UNCOIL HOSE TO DRAIN
REMAINING WATER.
Hose Reel
50 Foot Length
PAGE 1
Advertisement
Related Manuals for EarthWay 14050
Summary of Contents for EarthWay 14050
- Page 1 Hose Reel 50 Foot Length MODEL #14050 ASSEMBLY INSTRUCTIONS Thank you for selecting EarthWay for your lawn and garden needs. Our customer support team is standing ready to ensure your success. Please visit our website to see our other lawn & garden tools.
-
Page 2: Installation
DIRECT MOUNT TO WOOD STUD Recommended tools: ▪ masking tape ▪ stud-finder ▪ bubble level ▪ power drill ▪ drill bit - 3mm (1/8 in) ▪ 10mm socket, wrench or adjustable wrench EarthWay 14050 – 50’ Hose Reel PAGE 2... -
Page 3: Mounting Steps
6. Hang the hose reel on the wall bracket and secure it by inserting the mount tube. 7. Connect with inlet hose end with the water source. EarthWay 14050 – 50’ Hose Reel PAGE 3... - Page 4 Open the latch on the stop ball and move it to the desired location. Re-latch the ball. CAUTION: ALWAYS MAKE SURE THE HOSE REEL IS LOCKED BEFORE REMOVING THE STOP-BALL, AND MAKE SURE THE STOP BALL IS SECURELY FASTENED BEFORE UNLOCKING THE REEL. EarthWay 14050 – 50’ Hose Reel PAGE 4...
-
Page 5: Maintenance
ONE YEAR WARRANTY EarthWay Products, Inc. warrants this product free of defects in original workmanship and materials for a period of one year to the end user with the original purchase receipt. If a manufacturing non-conformance is found, EarthWay Products, Inc. at its discretion will repair or replace the part(s)/product at no charge provided the failure is not the result of incorrect installation, mishandling, misuse, tampering, or normal wear and tear as determined by EarthWay.
