Summary of Contents for Velocifero MINI MAD Plus

  • Page 2: Table Of Contents

    Welcome to use Thank you for choosing MINI MAD Plus electric scooter (hereinafter referred to as electric scooter).Electric scooter is a fashionable sports and entertainment equipment. Contents 1. Products and accessories........02 2. Function sketch maps..........03 3. Scooter body assembly........07 4. Connection of charger...........11 5.

  • Page 3: Products And Accessories

    1. Products and accessories Accessories 1.tools 2.charger Tools Contains 5#, 4# inner hexagon wrench.
  • Page 4 2. Functions and schematics Meter and control panel meter Power button...
  • Page 5 Operational instructions Meter...
  • Page 6 ①Speed / Fault code ②Electricity meter ③Odometer ④Trip meter ⑤Light indication ⑥Auto Cruise Control ⑦Bluetooth(reserved) ⑧Sport mode ⑨Normal mode ⑩ECO mode ⑪Logo notice： Electricity meter is divided into seven-grid display, Electricity decreases from top to bottom in turn. When the indicator light is only 2 grid, it is better to be ready to charge.
  • Page 7 Off-road tire Road tire Tyres: There are two options for tyres. One is off-road tire and the other is road tire.

  • Page 8: Scooter Body Assembly

    3. Scooter body assembly 1. Open the side bracket and fix the electric scooter standpipe.
  • Page 9 2. Install the handlebar on the standpipe; Lower folding mechanism wrench limiter.
  • Page 10 3.Use the hexagon wrench in the tool kit to tighten 4 bolts.
  • Page 11 4.Power on and test,Turn on the switch on the battery before use.

  • Page 12: Connection Of Charger

    Connection of charger 1. Open side stand,Open the waterproof plug of the charging port.
  • Page 13 2. Connect charger with charging port 3. After charging, Cover the waterproof plug . If you want to take the battery home to recharge it,We can open the footrest and take the battery out.Then,We connect the charger to the charging port of the battery.
  • Page 14 battery. Step2:Use the key to remove the battery from the scooter. Step3:Turn the switch on before charging. Step4:Connect the charger to the charging port on the battery and strat chanrging. Step5:Unplug the charger after charging. Step6:Before reinstalling the battery to the scooter and connecting the controller, turn off the switch on the battery, connect the power cord of the controller and then turn on the switch, so as to avoid sparking when...

  • Page 15: Learn To Drive

    5. Learn to drive As shown in the figure: Please wear protective gear to drive during study, as well as shoes. 2. Stand on the pedal with 1. Start-up; check battery the one foot and push back Capacity. with the other.
  • Page 16 3. Place one foot on the 4. Release the throttle to ground press slow down slowly, and accelerator gently. When the hold the brake handle scooter moves, place the for emergency braking. other foot on the pedal and keep balance. 5.

  • Page 17: Safety Instruction

    6. Safety instruction ! Don't ride in the rain. ! Don't pass quickly. When encountering...
  • Page 18 unconventional pavement such as deceleration belt, threshold, pitted pavement, etc. ! Beware of high obstacles, Such as door frames. ! Don't accelerate downhill.
  • Page 19 Don't press the throttle when implementing electric scooter. ! Please ride away from obstacles.
  • Page 20 ! Please don't hang heavy objects on the handle. ! Don't put one foot on the pedal when riding.
  • Page 21 It is forbidden to rotate handlebars greatly when driving at high speed. Don’ t drive in over 2CM deep water...
  • Page 22 Manned persons are prohibited. No treading on fenders.
  • Page 23 Don’t touch disc brake. Don’t leave your hands when riding.
  • Page 24 Do not climb stairs or jump over obstacles while riding.
  • Page 25 Attention: ●You should obey the national and local traffic rules. Strictly follow this manual to perfect you and others as much as possible. ●You need to understand: Once the electric scooter is in a public place or on the road, Even if you follow this manual completely, you may be injured due to violations or improper operations by other vehicles or personnel.

  • Page 26: Fold

    7. Fold Make sure the electric scooter is turned off. After holding the riser, First, move the wrench limiter of the folding mechanism upward,then turn the folding wrench downward.

  • Page 27: Daily Maintenance

    8. Daily maintenance Cleaning and Storage of Electric Scooter If there is any stain on the surface of the scooter, please dip it in soft cloth and wipe it with a little water. If dirty stains hardly to clean, toothpaste can be used for scrubbing and then wet cloth cleaning.
  • Page 28 Maintenance of Battery for Electric Scooter 1. Do not use battery packs of other models or brands, otherwise there may be safety risks. 2. It is forbidden to touch the battery contacts and to dismantle or puncture the shell. Avoid short circuit caused by metal contact with battery contacts.
  • Page 29 Modulates the brake If you feel that the brake is too tight or too loose, first use M4 inner hexagonal wrench to loosen the nut, then adjust the brake line, (Shorten the brake line upward if it is too tight, If it's too loose, pull the brake cord down)and then tighten the nut.(The front brake adjusting method is the same as the rear brake adjusting method).
  • Page 30 Adjust the handlebar As shown in the figure, if the standpipe is shaking during the ride, tighten the bolt with the inner hexagonal wrench. How to inflate a tire If a tire is found to be short of air, use an Pneumatic tools to inflate the tire.

  • Page 31: Type And Parameters

    9. Type and parameters Performance Item Specifications index L*W*H(mm) 1180*473*1212(mm) Dimensions Fold size(mm) 1180*473*510(mm) Vehicle weight in Product running order(with 28kg weight battery) Maximum load 100kg Cycling Requirement Applicable age 16-50 Suitable height 130-200cm Full speed 25km/h Max distance with one 30-41km charge Max climbing angle...

  • Page 32: Fault Code

    11. Fault code When the fault occurs, besides the fault light, the speedometer will also display the fault code. The explanation is as follows: E1: Hall fault of motor E2: Controller Signal Fault E3: Fault of Speed Control Rotary Handle E4: Controller MOS Fault E5: Phase Current Fault E6: Average Current Fault...

  • Page 33: Trade Marks And Legal Notices

    Velocifero Co., Ltd. Velocifero Company reserves all rights to trademarks. This manual is produced and copyrighted by Velocifero Co., Ltd. Without the permission of the Company, no other company or individual may modify, copy, disseminate or bundle with its products for use or sale.

  • Page 34: Warranty Policy

    13. Warranty Policy Note: T ools are consumables without warranty. Non-warranty Ordinance： Unauthorized maintenance, misuse, collision, negligence, abuse, infusion, accident, alteration, incorrect use of non-product accessories or tear, alteration of labels, anti-counterfeiting marks; Over the warranty period; Damage caused by force majeure. Performance failure that does not conform to the performance failure list of electric scooter.
