Jobsite CT2836 Original Instruction

4 in 1 multi-function petrol garden tool
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
4 IN 1 MULTI-FUNCTION PETROL GARDEN TOOL
WARNING
Cannon Tools Limited
Address: 20 Station Road, Rowley Regis, West Midlands, B65 0JU.UNITED KINGDOM
SAVE THESE INSTRUCTIONS FOR REFERENCE
CT2836
ORIGINAI INSTRUCTION
• Before using our products, please read this
manual carefully to understand the proper use
of your unit. Keep this manual handy.
• This product is of a special type designed
especially for garden service. It is only to be
used by a trained operator.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CT2836 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jobsite CT2836

Summary of Contents for Jobsite CT2836

  • Page 1 4 IN 1 MULTI-FUNCTION PETROL GARDEN TOOL CT2836 ORIGINAI INSTRUCTION • Before using our products, please read this manual carefully to understand the proper use of your unit. Keep this manual handy. WARNING • This product is of a special type designed especially for garden service.

  • Page 2: Ec Declaration Of Conformity

    In case of alteration of the machine, not agreed upon by us, this declaration will lose its validity. Product description: 4 IN 1 MULTI-FUNCTION PETROL GARDEN TOOL Model: CT2836 Applicable EC Directives: EC Machinery Directive 2006/42/EC EC Directive of Electromagnetic Compatibility 2014/30/EU EU Noise Directive 2000/14/EC &...

  • Page 3: Technical Information

    1. TECHNICAL INFORMATION Engine information Volume of the fuel tank 1200ml Max engine speed 9500/min Engine idling speed 3000/min Clutch engagement speed 3910 /min Engine displacement 52 cm³ Maximal power 1.45 kW / 7500/min Noise level and vibration Sound power level: 105,4 dB(A) Guarantee sound power level: 111dB(A) Sound pressure level: 96,2 dB(A) Uncertainties K = 3 dB(A)

  • Page 4: Safety Instructions

    2. SAFETY INSTRUCTIONS 2.1.1 General warnings Proper safety precautions must be observed. This unit must be handled carefully. DO NOT EXPOSE YOURSELF OR OTHERS TO DANGER. Follow these general rules. Do not permit others to use this machine unless they are thoroughly responsible and have read, and understand the machine manual and are trained in its operation.
  • Page 5  Inspect the area to be cut and remove all debris that could become entangled in the nylon cutting head. Also remove any objects that the unit may throw during cutting.  Keep children away. Onlookers should be kept at a safe distance from the work area, at least 15 meters.
  • Page 6 necessary, have the machine serviced by an authorized dealer. Never continue to operate a machine which may be malfunctioning.  In start-up or during operation of the engine, never touch hot parts such as the muffler, the high voltage wire or the spark plug. ...
  • Page 7 others to danger.  Envelop the blade before storage. Keep children away from it.  Never remove the machine’s guard.  Clean and maintain the tool before storage . Bring maintenance after each use according the instructions of this manual. Improper maintenance can reduce the lie of the tool, bring bad results and wear the tool and its accessories.
  • Page 8 Never place your hand near the rotating accessory. Accessory may kickback over your hand. Do not position your body in the area where power tool will move if kickback occurs. Kickback will propel the tool in direction opposite to the wheel’s movement at the point of snagging.

  • Page 9: Intended Use

    3. INTENDED USE 3.1 Brush cutter and grass trimmer 3.1.1 Intended use This machine can be used as a trimmer with the cutting edge, and as a brush cutter with the cutting blade. The grass trimmer must be strictly and only to cut grass or weeds that are not too dense.

  • Page 10: Technical Description

    4. TECHNICAL DESCRIPTION 1- Engine unit 2- Control unit 3- Main pole 4- Handle 5- Connection 6- Shoulder strap 9- Brush cutter & Grass 7- Pole Pruner head 8- Edge trimmer head trimmer head 10- Nylon spool 11- Blade 1. Engine unit 2.

  • Page 11: Operation

    5. OPERATION 5.1 GETTING STARTED 5.1.1 Handle assembly (Fig. 3) a). Place the tool on a flat, solid and clean surface. b). Place the handle holder under the rubber device on the tube. c). Place the handle on the tube and align the Fig.3 Fig.3 holes.
  • Page 12 d). Install and firmly tighten the fuel cap. e). Wipe up any spilled fuel from the power head before restarting. WARNING! •Always allow the product to cool before refueling! •Wipe all spilled fuel and move the product at least 3 meters (10 feet) from the fueling point before restarting! •Never smoke or light any fires near the product or fuels! •Never place any flammable material near the engine muffler!
  • Page 13 Important! Engine ignition is controlled by a two-position START-STOP switch mounted on the throttle body, typically labeled "T" for START and "0" for STOP 5.3 Cranking the engine CAUTION! Never operate the product unless a cutting attachment is installed. The recoil starter can be damaged by abuse. - Always engage the starter before attempting to crank the engine.
  • Page 14 WARNING! The cutting attachment will engage and rotate as the engine starts and accelerates. If the engine did not continue to run, repeat the appropriate cranking procedure (warm or cold engine). When the engine starts, clear excess fuel from the combustion chamber by revving the engine several times with the throttle trigger (operating the trigger will automatically disengage the "fast idle"...

  • Page 15: Maintenance

    - The engine must return to idle speed whenever the throttle trigger is released - Idle speed is adjustable and must be set low enough to permit the engine clutch to disengage the chainsaw when throttle trigger is released. 1. Start the engine and allow it to idle two or three minutes, or until it warm Up. 2.
  • Page 16 2.Carefully remove any accumulating of dirt or debris from the muffler and fuel tank, dirt build-up in these areas can lead to engine overheating, fire, or premature wear. 3.Check for loose or missing screws or components. Make sure the cutting attachment is free of debris and securely fastened.
  • Page 17 7. MANUAL OF BRUSH CUTTER & EDGE TRIMMER 7.1 Parts List 1. Tube 2. Protector shield 3. Gear case 4. Cutting device (blade or nylon thread) 7.2 Special Safety Instructions 7.2.1 Before using the machine a. Read this manual carefully to understand how to operate this unit property. b.
  • Page 18 At night, at time of heavy fog, or at any other time when your field of vision might be limited and it would be difficult to gain a clear view of the area. During rain, storms, during lightning storms, at times of strong or gale-force winds, or at any other time when weather conditions might make it unsafe to use the product.

  • Page 19: Notes On Transportation

    might get in the way while working, and remove any obstacles which can be cleared. The area within a perimeter of 15m of the person using the brush cutter should be considered a hazardous area into which no one should enter while the brush cutter is in use, and when necessary yellow warning rope, warning signs should be placed around the work area.
  • Page 20  Make sure the appropriate blade cover is in place.  When transporting by car, fix the unit firmly using a rope.  Do not transport by bicycle or motorcycle as it is dangerous.  Never transport the brush cutter over rough roads over long distances without first removing all fuel from the fuel tank, as doing so might cause fuel to leak from the tank.
  • Page 21  When sharpening, removing, or reattaching the blade, proper tools and equipment are required to prevent injury.  When replacing blade or any other part or when replacing the oil or any lubricant, always be sure to use products or products which have been certified for use with the brush cutter.
  • Page 22 3. Screw the cutting head fully onto the tool. 4. Then remove the hex key. To remove the cutting head, insert the hex key into the hole and unscrew it. NOTE: Keep bolts and washers to install the blade carefully so as not to lose them.
  • Page 23 7.3.4 Wearing the Strap (Fig. BC7) 1.Hook the strap hook to hanger on the outer pipe. 2.Wear the strap so that the hook stays at your right hand side. Adjust the length of the strap so that you can hold and operate machine comfortably. 7.4 OPERATION Intended use - The product is intended for domestic use.
  • Page 24 right), scraps fly in the direction away from the body. You can avoid getting your clothes dirty. 7.5 MAINTENANCE 7.5.1 Blades (Fig.BC9) Sharpen each cutting blade after 25h of use and make sure the bottom corner is rounded. Do not cool the blade with water in case of using a grinder. It may cause cracks on blade.

  • Page 25: Parts List

    8. MANUAL OF POLE PRUNER 8.1 PARTS LIST 1. Guide bar 2. Chain 3. Oil tank 4. Oil Cap EF 5. Gear case 6.Chain cover 7.Tube 8.2 SPECIAL SAFETY INSTRUCTIONS CAUTION! Always maintain this pole pruner according to the owner's manual and follow the recommended scheduled maintenance.
  • Page 26  Approaching or contacting electrical lines with the pole x pruner could cause death or serious injury.  Keep the pole pruner at least 10 meters away from electrical lines or branches that contact electrical lines This machine is designed especially for cutting small branches.
  • Page 27 NOTE: For longest chain life, let new or replacement chain loops soak in oil overnight before installation. Using the small end of the plug wrench, remove the sprocket cover nut (turn counterclockwise to remove) and remove the sprocket cover. See Fig.PP2 CAUTION! Failure to align the guide bar and chain tensioning pin can cause serious damage to the sprocket cover, guide bar, chain tensioning pin and cutting head assembly...
  • Page 28 IMPORTANT: Proper chain adjustment is essential for maximum performance, long chain life, and operator safety. Always inspect chain tension before operating the pole pruner. 1. Place the pole primer on a clean, flat Surface. (For readjustment during operation, shut down the engine, then allow the guide bar and chain to cool before proceeding with the adjustment procedure.
  • Page 29 1. Oil filter cap pruner. 2. Oil reservoir B. Adjusting Oil Flow Rate CAUTION! An increase in bar oil flow rate will speed oil consumption, requiring more frequent checks on the oil reservoir. To ensure sufficient lubrication, it may be necessary to check the oil level more frequently than at fuel tank refills. The guide bar and chain are lubricated automatically by a pump that operates whenever the chain rotates.
  • Page 30 3.Adjust the length of the strap so that you can hold and operate the machine comfortably. 8.3.6 Preparation Wear suitable protective clothing and equipment-see section "safety Precautions". Choose the best work position for safety against the falling object (Branch etc) Start the engine.

  • Page 31: Working Techniques

    8.5 WORKING TECHNIQUES 8.5.1 Relieving cut (Fig.PP13) To avoid tearing the bark, kickback or pinching the bar when pruning thick branches, always start by performing a relieving cut (1) on the underside of the branch. To do this apply the cutting attachment and pull it across the bottom of the branch as far as the bar nose.

  • Page 32: Sharpening The Chain

    • Using a lever-type grease gun, pump lithium-base grease (about 10 grams) into the grease fitting until you see old grease being purged from the gear case, this can be seen in the outer tube cavity. Clean up excess grease, and then reassemble the gear case onto the outer tube Use a wire hook to extract the fuel filter from inside the fuel tank (See Fig.PP17).
  • Page 33 After all depth gauges have been adjusted, use a flat file to round each depth gauge leading edge to its original curvature and angle.

  • Page 34: Special Safety Instructions

    9. MANUAL OF HEDGE TRIMMER 9.1 PARTS LIST 1.Blade protection 2.Blades 3.Gear case 4.Handle 5.Latch lock/unlock 6.Tube 9.2 SPECIAL SAFETY INSTRUCTIONS CAUTION! 1. Always maintain the articulated hedge trimmer according to this owner's manual and follow the recommended scheduled maintenance. 2.
  • Page 35 9.3 Safety Operation The articulated hedge trimmer is not insulated against electric shock! 1.Approaching or contacting electrical lines with the trimmer could cause death or serious injury. 2.Keep the trimmer at least 10 meters away from electrical lines or branches that contact electrical lines.
  • Page 36 1.Protective cover must be in place 2.Tighten the screw (if needed) 9.4.2 Adjusting the Articulated Hedge Trimmer A. Cutter Assembly WARNING! The cutter blades are very sharp. Do not grasp the blades with your hands. Do not brush the blades against your body. Never run the engine or operate the articulating hedge trimmer when the cutter assembly is in the storage/ transport position.
  • Page 37 B. Cutter assembly for desired cutting angles WARNING! Do not touch the cutter blades when the engine is running. The blades can oscillate even if the engine is idling. The cutter assembly can be adjusted to 10 different positions ranging from 120° to 270° from the outer tube as shown in Fig.HT7.
  • Page 38 9.5.2 Cutting sequence If a radial cut is necessary, cut a Little at a time in several passes. 9.5.3 Working position Hold the control handle with your right hand, and the shaft with your left hand. Your left arm should be extended to the most comfortable position. NOTE: Take a rest when you feel fatigue 9.5.4 Cutting techniques (Fig.

  • Page 39: 50-Hour Maintenance

    9.6 MAINTENANCE 9.6.1 Daily maintenance WARNING! Always wear gloves when working around the cutter assembly.  Clean any debris or dirt from the hedge trimmer cutter blades. Lubricate the blades before use and after refueling. Check the cutters for damage or incorrect adjustment.
  • Page 40 CAUTION! Do not remove the D-shaped shim washer from the gearcase clamp! The shim washer prevents damage from over-tightening the tube damp screw. a. Loosen the gear case clamp bolt. b. Remove the index bolt from the gear case. c. Side the gear case out of the tube. Using a grease gun, pump lithium-base grease (about 10 grams) into the grease fitting on the gear case until you see old grease being purged from the gear case (Fig.HT15).
  • Page 41 IMPORTANT! All stored fuel should be stabilized with a fuel stabilizer. 3.Remove the spark plug and pour about 3cm° of oil into the cylinder through the spark plug hole. Slowly pull the recoil starter 2 or 3 times so oil evenly coat the interior of the engine.

  • Page 42: Troubleshooting

    9.8 Trouble shooting Problems Causes Resolutions The starting process is not Follow the instructions of use of this followed manual Spark plug dirty or moist Clean the spark plug or replace it by a The tool cannot be started new one Incorrect carburettor adjustment Contact your dealer or contact SWAP...
  • Page 43 10. SYMBOLS Warning symbol Wear an equipment of protection including a helmet, protective glasses, hearing protection Wear hearing protection Wear protective and non-skid shoes Read the instruction manual Risk of projection – keep bystanders away - The distance between the machine and bystanders shall be at least 15 m.
  • Page 44 Do not smoke and do use the tool near naked flame Warning! Cutting elements Caution: the accessible surface maybe hot when using the tool Keep 15 meters away from any other person Wait until all machine components have completely stopped before touching them.

  • Page 45: Exploded View

    11. EXPLODED VIEW...
  • Page 46 Description Description screw M5×25(HEX) Cylinder gasket Pull start Piston ring Pull start Piston Center plate Crank shaft Oil seal 12×22×7 Needle Crank case Piston pin Bearing 6202 Piston spring Fuel tank Connecting plate cross screw M5×20 (hex) 1 screw M5×14 (hex) Tank plate Screw M5×12 (hex) Tank protector...
  • Page 47 Plastic cover, cylinder Gear box Plastic cover, cylinder screw 5*12(hex) screw M5×22 (hex) Switch seat Spark plug Blade Air filter cover Switch seat Air filter plate protector cover sponge Nut M10 Ai filter seat trimmer head Screw M5×55（Hex) Nut for pruner cover Carburetor Protect cover Carburetor gasket...
  • Page 48 CANNON TOOLS LTD Add: 20 station road, Rowley Regis, west midlands,B65 0JU.U.K. Made in China...
