Epson PowerLite 1925W Specifications

Epson PowerLite
MULTIMEDIA PROJECTOR
Product Name Product Code
PowerLite 1925W V11H314020
V13H010L53
Replacement Lamp
Replacement Air Filter V13H134A24
Specifications
Projection System
Epson 3LCD, 3-chip optical engine
Projection Method
Front/rear/ceiling mount
Driving Method
Epson Poly-silicon TFT Active Matrix
Pixel Number
1,024,000 dots (1280 x 800) x 3
White Light Output
1
4000 lumens (ISO 21118 Standard)
Color Light Output
1
4000 lumens
Aspect Ratio
16:10
Native Resolution
1280 x 800 (WXGA)
Resize
640 x 480 (VGA), 800 x 600 (SVGA),
1024 x 768 (XGA), 1152 x 864 (SXGA),
1440 x 900 (WSXGA), 1680 x 1050 (WSXGA+),
1400 x 1050 (SXGA+), 1600 x 1200 (UXGA)
Lamp Type
E-TORL 230 W UHE
Lamp Life
3
Up to 3500 hours (ECO Mode)
Up to 2500 hours (Normal Mode)
Throw Ratio Range
1.62 – 2.61
Size (projected distance)
30" – 300" 16:10 aspect (3' – 50.6')
Keystone Correction Automatic
Vertical: ± 30 degrees, (± 45 manual)
Horizontal ± 20 degrees, (± 30 manual)
USB Plug 'n Play
Mac compatible via DVI to VGA adapter (not included)
USB Plug 'n Play for Windows 2000 or later
®
Contrast Ratio
Up to 2000:1
Color Reproduction
16.77 million colors
Projection Lens
Type
Powered focus
Manual (optical) zoom
F-number Focal Length
1.75 – 2.42 24 mm – 38.2 mm
Zoom Ratio
Optical zoom 1.0 – 1.6
Light output varies depending on modes (color and white light output). White light output measured using ISO 21118 standard.
1
Data source: ProjectorCentral.com, Jan. 2009. Average of 796 shipping models, for which manufacturers provided lumens and total power data, all resolutions and brightness levels.
2
Lamp life will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time.
3
4 See our website for convenient and reasonable recycling options at www.epson.com/recycle
5 Recommendation based on normal room conditions. Cleaning requirements may vary depending on use, environment and other conditions. Cleaning intervals may be adjusted to accommodate
the environment in which the projector is used.
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Specifications and terms are subject to change without notice. Epson, Easy Management, EasyMP, E-TORL and Instant Off are registered trademarks, Epson Exceed Your Vision is a registered logo-
mark and Better Products for a Better Future is a trademark of Seiko Epson Corporation. PowerLite and PrivateLine are registered trademarks, Duet is a trademark and Epson Connection is a service
mark of Epson America, Inc. All other product and brand names are trademarks and/or registered trademarks of their respective companies. Epson disclaims any and all rights in these marks.
Copyright 2009 Epson America, Inc. CPD-30493 10/09
1925W
®
UPC
0 10343 87476 3
0 10343 87483 1
0 10343 87484 8
Other
Display Performance
NTSC: 480 lines
PAL: 560 lines
(Depends on observation of the multi-burst pattern)
Input Signal
NTSC/NTSC4.43/PAL/M-PAL/N-PAL/PAL60/SECAM
Interfaces
Computer/component video: D-sub 15 pin x 2
S-video: Mini DIN x 1
Composite video: RCA x 1
Audio in x 3 (RCA (L&R) x 1, mini stereo x 2)
Variable audio out: mini stereo x 1
USB connector: Type-B x 1 (USB display and
mouse/keyboard control), Type A x 2 (for USB
memory device/Epson doc camera)
Serial: RS-232c x 1
LAN networking: RJ-45 x 1
Monitor out: Mini D-sub 15 pin x 1
Wireless LAN port: 802.11 a/b/g
Speaker
10 W (mono)
Operating Temperature
41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
Power Supply Voltage
100 – 240 V ±10%, 50/60 Hz
Power Consumption
341 W
Communication on: 5.5 W standby
Communication off: 0.2 W standby
Fan Noise
29 dB (ECO Mode)
37 dB (Normal Mode)
Security
Kensington - style lock provision, security anchor bar
®
Dimension (W x D x H)
Including feet: 14.1" x 10.12" x 3.74"
Excluding feet: 14.1" x 10.12" x 3.4"
Weight: 7.82 lb

Remote Control

Features
Search, comp, video, USB, LAN, power, aspect, color mode,
volume, e-zoom, A/V mute, freeze, menu, page up and
down, help, auto, mouse functions, user, ID num, pointer,
esc, enter
Operating Angle
Right/left: ± 30 degrees
Upper/lower: ± 30 degrees
Epson Canada, Ltd.
3771 Victoria Park Avenue, Toronto, Ontario M1W 3Z5
Support — The Epson Connection
Pre-sales support
U.S. and Canada
Internet website
Service Programs
Two-year projector limited warranty, Epson
Road Service program, Epson PrivateLine
dedicated toll-free support and 90-day lamp
limited warranty
What's In The Box
Power cord, computer cable (VGA), USB
cable, wireless LAN unit, soft carrying case,
projector remote control, batteries, user manual
CD, projector software CD, Quick Setup Sheet,
PrivateLine support card, and password
protection sticker
Accessory Part Numbers
Replacement wireless LAN module
Quick Wireless Connection USB key
Universal projector ceiling mount
Advanced projector ceiling mount
High-security projector ceiling mount
Adjustable suspended ceiling channel kit ELPMBP01
False ceiling plate kit
Structural round ceiling plate
Adjustable extension column
(pipe) 8" – 11"
Component to VGA video cable
S-video cable
SwissGear
50" portable screen
60" portable pop-up screen
80" portable pop-up screen
Duet
Epson DC-06 document camera
Kensington security lock
Distribution amplifier
Replacement lamp
Replacement air filter
Operating Distance
26' (8 m)
800-463-7766
www.epson.com
®
V12H306P11
V12H005M06
ELPMBPJF
ELPMBPRG
ELPMBATA
ELPMBP02
ELPMBP03
ELPMBC01
ELPKC19
ELPSV01
backpack ELPKS63
®
ELPSC06
ELPSC07
ELPSC08
screen ELPSC80
™
V12H321001
ELPSL01
ELPDA01
V13H010L53
V13H134A24
