- Page 1 GENEVO MAX U S E R M A N U A L...
-
Page 2: Advanced Features
The signal GENEVO MAX DETECTOR: strength has nine levels for better distance expression. GPS points GENEVO MAX is the first member are reported verbally, such as of new lineup of Genevo radar “section speed cameras”. detectors. - Page 3 QUICK GUIDE: Powering by the supplied 12V power cable. Mounting bracket (horizontal attachment) Mounting bracket (Vertical attachement) 1. 12V power input 2. 3.5mm jack for headphones 3. USB-C input for PC updates 4. Control buttons 5. Status indicator 6. Motion sensor 7.
-
Page 4: Home Screen
CONTROL HOME SCREEN: Brightness Increase control the volume Decrease the volume Short press: Short press: Main menu Sensitivity setting Long press: Turn off Long press: Add a custom point MAIN MENU: Move the menu left Move the menu right Short press: Enter the submenu Long press: Return to the home screen... -
Page 5: Setting Submenu
SETTING SUBMENU: Currently selected item to edit Change Move the item menu up value Change Move the item menu value down Short press: Return to main menu Long press: Return to the home screen DURING ALERT: Hand gesture, or short press of any button will silence the alert Any button will lockout false alert location when long pressed... -
Page 6: Main Menu Items
MAIN MENU ITEMS USER INTERFACE SETTINGS: DISPLAY: Setting the information displayed on the right side of the display: • TIME 24H - Displays time in 24h format. • VOLTAGE - Displays the battery voltage. • COMPASS - Displays driving direction. •... - Page 7 G3 TONE: 1-15 - Options for selecting different alert tone. G4 TONE: 1-15 - Options for selecting different alert tone. This option allow you to choose different sound for each band separately. MOTION SENSOR: ON/OFF Selecting “ON” opens the motion sensor sensitivity settings.
- Page 8 When the MR Filter function is active, detector sensitivity to MR CT/CD radars is slightly reduced. New Firmware updates add detections of new types of radars, all supported radars, recommended settings and more information can be found at www.genevo.com/en/radars_en.
-
Page 9: Database Update
1. Simply online for WIN and MacOS at: www.genevoupdate.com 2. By downloading the updater software for Windows OS at: www.genevo.com/en/updates/ On these websites, you will find help on how to update and also a newsletter form, so we will keep you informed about every newly released update. -
Page 10: Operating Frequency
Operation temperature: -20 °C to +85 °C Storage temperature: -20 °C to +85 °C Operation voltage: 11 - 26 V DC Power consumption: 250 mA normal, 330 mA max. (at 12 V) Dimensions: 101 × 68 × 33 mm Power Input: Pmax= 3.96 W... -
Page 11: Explanatory Notes
EXPLANATORY NOTES: Radar frequency bands: Different Wide: Broadband mode, on the radar bands are used to measure other hand, searches for example speed, most often Ka, K, X, or newer the entire Ka band from 33.4 GHz MultaRadars and GATSO Radars to 36.0 GHz. - Page 12 2022-04-01 Manufacturer: GENEVO s.r.o., Radčina 497/22, Liboc, 161 00, Praha 6...
