Introduction
This manual describes the installation and connection of the product and also describes how to
use the product. Mounting and installing of the Octopus X Series LEDs may only be executed by
certified service personnel. Please read and understand this manual completely before using the
product. Only use the product as specified in this manual.
2
Product Information & Specifications
2.1
General Information
Product Name
Manufacturer
Version
Plug Type
Input Voltage
US 5-15P
US 6-15P
!
Note:
Other types of plug are also available, please check with our sales engineers directly.
800W/400W LED Grow Lights
Octopus X Series LED Grow Lights
Shenzhen VANQ Technology Co., Ltd.
US
US plug 120-277V
120-277VAC
US L7-15P
Octopus 400X
EU
UK
EU plug 230V
UK plug 240V
100-230VAC
100-240VAC
EU plug 230V
AUS
AUS/NZS plug 240V
100-240VAC
UK plug 240V
AUS/NZS
plug 240V
TM
