Summary of Contents for Drija Palermo 62L
-
Page 2: Table Of Contents
User Manual MICROWAVE OVEN | PALERMO 62L 1. IMPORTANT SAFETY INSTRUCTIONS ............3 2. PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY ..................5 3. INSTALLATION GUIDE ................. 5 4. OPERATING INSTRUCTIONS ..............9 5. TROUBLESHOOTING ....................… 7. CLEANING AND CARE...………………………………………………………..18... -
Page 3: Important Safety Instructions
User Manual MICROWAVE OVEN | PALERMO 62L IMPORTANT SAFETY INSTRUCTIONS PLEASE READ CAREFULLY AND KEEP FOR FUTURE REFERENCE SECURITY WARNING To reduce the risk of fire, electric shock, injury to persons, or exposure to excessive energy in the microwave oven when using your appliance, follow basic precautions, including the following: (Read all instructions before using the appliance) ... - Page 4 User Manual MICROWAVE OVEN | PALERMO 62L Microwave heating of beverages can cause delayed eruptive boiling, so care should be taken when handling the container. The contents of the bottles and baby food jar should be shaken or stirred and the temperature checked before consumption to avoid burns.
-
Page 5: Precautions To Avoid Possible Exposure To Excessive
User Manual MICROWAVE OVEN | PALERMO 62L PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY Do not attempt to operate this oven with the door open because operation with open doors can result in harmful exposure to microwave energy. It is important not to break or tamper with the safety interlocks. - Page 6 User Manual MICROWAVE OVEN | PALERMO 62L Risk of electric shock Plug into a 3-terminal outlet. Do not remove the ground terminal. Do not use an adapter. Do not use an extension cord. Failure to follow these instructions can result in death, fire, or electric shock.
- Page 7 User Manual MICROWAVE OVEN | PALERMO 62L PALERMO 62L Model: Feeding: 120 V ~ 60 Hz Microwave input power: 1700 W Microwave output power: 1200 W Oven Capacity: 62 L Turntable Diameter: 420 mm External Dimensions (An. x Prof. x Al.):...
- Page 8 User Manual MICROWAVE OVEN | PALERMO 62L 30 cm LIBRE 7.5 cm 7.5 cm 1. Choose a level surface that provides enough open space for air intake and / or exhaust for ventilation. 2. A minimum clearance of 7.5 cm is required between the oven and any adjacent walls.
-
Page 9: Operating Instructions
User Manual MICROWAVE OVEN | PALERMO 62L OPERATING INSTRUCTIONS Control Panel “0:00” will appear on the display. If “0:00” appears on the display at any other time, a power failure has occurred. Reset the watch if necessary. While you are using the microwave oven, the display will show the remaining time and the function icons will flash. - Page 10 User Manual MICROWAVE OVEN | PALERMO 62L Clock This is a 12-hour standard clock (1:00 - 12:59). The watch cannot be erased. If the clock is not set, it will be displayed (0:00) when the microwave is not in use.
- Page 11 User Manual MICROWAVE OVEN | PALERMO 62L The microwave oven has a magnetron that produces microwaves which reflect off the metal floor, walls and ceiling and pass through the turntable and containers inside the oven. These microwaves are attracted to and absorbed by the fat, sugar and water molecules in the food, causing them to move, producing friction and heating the food.
- Page 12 User Manual MICROWAVE OVEN | PALERMO 62L Initial temperature Food that is at room temperature will cook faster than refrigerated foods, and refrigerated foods will cook faster than frozen foods. Composition and density Foods high in fat and sugar will reach a high temperature and cook more quickly than other foods.
- Page 13 User Manual MICROWAVE OVEN | PALERMO 62L Protective layer Use small, thin pieces of aluminum foil to cover thin pieces of irregularly shaped foods, bones, and foods such as chicken wings, legs, and fish tails. See first the section “Aluminum foil and metal”.
- Page 14 User Manual MICROWAVE OVEN | PALERMO 62L 3. (0:00) will appear on the display. Capture the cooking duration time. 4. Press POWER LEVEL, enter the desired power for the first stage. See the section “Cooking power”. 5. Repeat steps 2 and 3 for the second stage.
- Page 15 User Manual MICROWAVE OVEN | PALERMO 62L Sensor Cook A sensor in the microwave oven detects the moisture released from the food as it heats up and adjusts the cook time accordingly. Many sensor cycles require food to be covered. It is recommended to use microwave containers with lids that are loose or do not seal completely.
- Page 16 User Manual MICROWAVE OVEN | PALERMO 62L 8. The display will show the defrost countdown. The cycle can be briefly interrupted by opening the door to turn the food if necessary. Close the door and press START / ENTER to continue the cycle.
-
Page 17: Troubleshooting
User Manual MICROWAVE OVEN | PALERMO 62L TROUBLESHOOTING NORMAL Microwave oven interfering with reception Radio and television reception may be interfered with when using the microwave oven. It is similar to interference from small electrical appliances, such as electric leader, transparent vacuum, and fan. It is normal. -
Page 18: Cleaning And Care
User Manual MICROWAVE OVEN | PALERMO 62L According to waste electrical and electronic equipment. Directive (WEEE), WEEE must be collected separately and treated. If at any time in the future you need to dispose of this product, DO NOT dispose of it with your household waste. Please send this product to WEEE collection points when available. - Page 19 User Manual MICROWAVE OVEN | PALERMO 62L Microwave Oven Door The area where the microwave oven door and frame make contact when closed should also be cleaned. Mild non-abrasive soaps and detergents: Rinse with clean water and dry with a soft, lint-free cloth.
