- Page 1 BACKHOE BE-BKXX OPERATIONS & PARTS MANUAL FOR MODELS: • BE-BK61 • BE-BK71 PURCHASE DATE MODEL NO. SERIAL NUMBER DEALER...
- Page 2 TABLE OF CONTENTS Safety Specifications Introduction Operation Lubrication & Maintenance Troubleshooting General Information Exploded view & Parts lists...
- Page 3 SAFETY PRECAUTIONS Understand that your safety and the safety of other persons is measured by how you service and operate this backhoe. Know the position and operations of all controls before you try to operate. Make sure you check all controls in all safe area before starting. Read this manual completely and thoroughly and make sure you understand all controls.
- Page 4 SAFETY DECAL LOCATION IMPORTANT: Warning decals are visible when getting on backhoe. Refer to the left and right hands used in this manual, it’s the position of the operator when seated in the operating positions of the backhoe. CARE OF SAFETY DECALS 1.
- Page 5 Location: Main valve cover Location: Right leg guard Location: Left side valve lever Location: Right side valve lever Location: Side or left inner lever Location: Side or right inner lever BK-61 BK-71 Location: Both sides of dipper stick Location: Main valve cover BE-BKXX USER MANUAL...
- Page 6 3. BACKHOE SPECIFICATIONS SPECIFICATIONS REF DESCRIPTION BE-BK61 BE-BK71 Backhoe Model BK215 Digging Depth (2ft Flat Boom) 1860mm 2160mm Reach From Center Line of Swing Pivot 2820mm 3277mm Digging Depth (two foot flat bottom) 2200mm 86.6” Loading Height (Bucket At 60°) 1590mm 2032mm Reach from center line of Swing Pivot...
- Page 7 INTRODUCTION The purpose of this manual is to assist you in maintaining and operating your backhoe. Read it carefully, it furnishes information and instructions that will help you achieve years of dependable performance. Some information may be general in nature due to unknown and varying conditions. However, through experience and these instructions, you should be able to develop operating procedure suitable to your particular situation.
- Page 8 TIRE INFLATION Front tires must be maintained at the maximum recommended inflation to maintain normal tire profile with the added weight of backhoe/material. Rear tires must be maintained at equal pressure within the recommended tire inflation range. Unequal rear tire inflation can prevent backhoe attachment from contacting the ground across its full width. WHEEL TREAD SETTINGS Tractor front wheel tread setting must be restricted to wheel tread spacing recommended in the tractor Operator’s Manual.
- Page 9 CAUTION When lowering a heavy load, ease it downward slowly. Never drop a loaded attachment and “catch it hydraulically”. Stopping a load after it has gained downward momentum places undue strain on the unit and may cause unnecessary damage to the backhoe or tractor or even worse, personal injury. Before disconnecting hydraulic lines, relieve all hydraulic pressure.
- Page 10 Push the left-hand outer control lever, arm (dipperstick) moves toward the operator. and pull back the lever, arm moves away from the operator. Move the left-hand outer control lever to the left, boom swing moves to the left. Move lever right, boom swing moves to the right. Crowd and Swing Controls Push the right-hand outer control lever, boom moves down, and pull back the lever, boom moves up.
- Page 11 CAUTION Move the backhoe to flat, firm and wide place to remove the equipment. Do not allow to be removed without bucket and stabilizers. Also, dump the remaining material from the bucket to empty. Use other lifting equipment to remove when the backhoe has damage. 1.
- Page 12 8. LUBRICATION AND MAINTENANCE LUBRICATION & MAINTENANCE LUBRICATION AND MAINTENANCE ITEM SERVICE SERVICE INTERVAL ITEM SERVICE SERVICE INTERVAL Hydraulic System Oil Level Check Daily/10 hours Hydraulic System Oil Level Check Daily/10 Hours As specified in Tractor Hydraulic System Oil/Filter Replace As specified in Tractor Manual Hydraulic System Oil/Filter Replace...
- Page 13 Refer to “Lubrication & Maintenance Chart” for quick reference to Maintenance Operations. CAUTION Do not operate the backhoe if the fittings are leaking or if the hoses are damaged. A sudden line burst could cause the boom, dipperstick or bucket to drop suddenly, causing damage to the tractor or backhoe or injury to personnel.
- Page 14 TROUBLESHOOTING The trouble shooting chart is provided for reference to possible backhoe operational problems. Determine the problem that best describes the operational problem being experienced and eliminate the possible causes as listed by following the correction procedures. PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY •...
- Page 15 PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY Backhoe drops with valve spool in “centered” position (no external oil • Cylinder piston assembly leakage. • Check cylinders for leakage. leakage evident) Note: A gradual • Control valve internal leakage. • Replace control valve & recheck. drop over an extended period of time is a normal condition.
- Page 16 11. TORQUE TIGHTENING CHART TORQUE TIGHTENING CHART 1 TORQUE TIGHTENING CHART 1 11. TORQUE TIGHTENING CHART TORQUE TIGHTENING CHART 1 TORQUE TIGHTENING CHART 2 TORQUE TIGHTENING CHART 2 TORQUE TIGHTENING CHART 2 BE-BKXX USER MANUAL...
- Page 17 The individual parts in their normal relationship to each other. Reference numbers are used in the illustrations. These numbers correspond to those in the "Number" column and are followed by the quantity required and description. GENERAL INFORMATION Directional Reference "Right hand" and "left hand" sides are determined by standing at the rear of the unit and facing ILLUSTRATIONS in the direction of forward travel.
- Page 18 EXPLODED VIEW & PARTS LIST 12.2 SEAT，CONTROL ASSEMBLY 12.2 SEAT CONTROL ASSEMBLY REF. PART NO. DESCRIPTION REF. PART NO. DESCRIPTION PART No DESCRITION Q’TY REMARK 名称 BK215.033 Seat GB5782-M12x100 Bolt - M12x100 BK215.033 Seat 座椅 GB5782-M12x115 Bolt-M12x115 BK215.104 Foot Plate - Center GB5782-M12x115 Bolt-M12x115 螺栓...
- Page 19 12.3 MAIN FRAME ASSEMBLY 12.3 MAIN FRAME ASSEMBLY REF. PART NO. DESCRIPTION REF. PART NO. DESCRIPTION PART No DESCRITION Q’TY REMARK 名称 GB5782-M16x60 Bolt - M16x60 BK215.130 Washer GB5782-M16x60 Bolt-M16x60 螺栓 M16x60 GB97.1-16 Washer - Plain 16 BK215.129 Bushing GB97.1-16 Washer-Plain 16 平垫...
- Page 20 12.4 SWING FRAME ASSEMBLY 12.4 SWING FRAME ASSEMBLY PART No DESCRITION Q’TY REMARK 名称 GB889.1-M10 Nut Lock-M10 自锁螺母 M10 GB97.1-10 Washer-Plain 10 平垫 10 BK215.118 Lock Plate 锁架铰链板 REF. PART NO. DESCRIPTION REF. PART NO. DESCRIPTION GB5782-M10x35 Bolt-M10x35 螺栓 M10x35 GB889.1-M10 Nut Lock - M10 BK215.112...
- Page 21 12.5 BOOM ASSEMBLY 12.5 BOOM ASSEMBLY PART No DESCRITION Q’TY REMARK 名称 GB5782-M8x70 Bolt-M8x70 螺栓 M8x70 BK215.115 Pin, φ 39.5x193 大臂销 GB889.1-M8 Nut Lock-M8 自锁螺母 M8 REF. PART NO. DESCRIPTION GB5782-M8x70 Nut Lock - M10 GB5782-M8x60 Bolt-M8x60 螺栓 M8x60 102 BK215.115 Washer - Plain 10 BK215.113 Pin, φ...
- Page 22 12.6 BUCKET, DIPPERSTICK ASSEMBLY 12.6 BUCKET, DIPPERSTICK ASSEMBLY PART No DESCRITION Q’TY REMARK 名称 REF. PART NO. DESCRIPTION REF. PART NO. DESCRIPTION GB5782-M8x60 GB5782-M8x60 Bolt-M8x60 Bolt-M8x60 JB7940.1-M6 Grease Nipple-M6 螺栓 M8x60 BK215.112 Pin, Ø29.5x161 BK6N.01.105 Bucket Teeth BK215.112 Pin, φ 29.5x161 小臂销...
- Page 23 12.7 HOSE FITTING ASSEMBLY 12.7 HOSE FITTING ASSEMBLY 注：A5,A6,B5,B6使用 小孔接头M14(锥）-G3/8。 REF. PART NO. DESCRIPTION REF. PART NO. DESCRIPTION PART No DESCRITION Q’TY REMARK 名称 GB/T6172.1-M8 Nut-M8 JB/T982-14 Combination Washer 14 145 JB/T982-14 Combination Washer 14 组合垫圈 14 HC-TR55/6 Control Valve BK215.044 Stabilizer Cylinder-LH 146 BK215.044...
- Page 24 12.8 HYDRAULIC SYSTEM ASSEMBLY 12.8 HYDRAULIC SYSTEM ASSEMBLY 伸 撑 撑 展 挖 提 脚 脚 油 斗 升 油 油 缸 油 油 缸 缸 右 左 缸 缸 右 左 Boom Bucket Stabilizer Stabilizer Dipperstick Swing Swing Cylinder Cylinder Cylinder-RH Cylinder-LH...
- Page 25 12.9 FRONT BRACE ASSEMBLY (OPTIONAL) REF. PART NO. DESCRIPTION 190 FEL - Ø5 Ø5 - R Pin BK215.132 Short Pin BK215.133 Square Tube BK215.034 Front Brace 194 BK215.134 Long Pin BE-BKXX USER MANUAL...
- Page 26 12.10 RUBBER BRACE ASSEMBLY REF. PART NO. DESCRIPTION 201 GB/T5872-2000 Bolt - M10x35 202 GB/T97.1-2002 Plain Washer 10 203 GB/T889.1-2000 Nut M10 204 BK215.05.101 Clip Board 205 BK215.05.102 Rubber 206 GB/T5872-2000 Bolt - M10x180 BE-BKXX USER MANUAL...
- Page 27 12.11 TANK MOUNT ASSEMBLY 出 进 BE-BKXX USER MANUAL...
- Page 28 REF. PART NO. DESCRIPTION GB/T5872-2000 Bolt - M10x25 GB/T97.1-2002 Plain Washer 10 GB/T889.1-2000 Nut - M10 BK215.07.048 Tank GB/T5872-2000 Bolt - M10x40 BK215.07.422 Tank Mount - Left BK215.07.421 Tank Mount - Right BK6N.07.001 Spline Hub Weldment 222 BK6N.06.114 Mount Plate 223 BK215 Gear Box 224 BK6N.06.115...
- Page 29 BE-BKXX USER MANUAL...
