1. Safety instructions

Caution! Strong light may blind other people.
• Do not look directly into the light.
• Do not shine the light directly into the eyes of other people.

2. Technical specifications

Ambient temperature Ta: -20 °C ... +50 °C
Storage temperature:
Batteries / power supply: 3 x LR03 (see Ex-Safety
Lamp:
Luminosity:
Luminous flux:
Operating time:
Dimensions:
Weight:
IP protection class:
ESD protection:
CE-designation:

3. Functional description / operating instructions

Please read these operating instructions carefully so
that you are familiar with, and are able to use, all of the
functions of your Lite-Ex PL 10e. For your own safety and
information please read the instructions on the following
pages carefully!
4
-30 °C ... +60 °C
Manual, table with approved
batteries)
High performance LED:
3000 lx
3000 lx (at a distance of 1 m)
64 lumens
approx. 55 hours
147 x 36 x 36 mm
approx. 120g
(with batteries)
IP 65/67
(according to IEC 60529)
Anti-static housing
‡
0102
