StaffCall IQ Pager

Battery Replacement

Instructions
Tools: Phillips Head Screwdriver & Blue Opener Tool

Step 1

Place the pager on a table and then flip it over so that the display is facing down. After, remove the four screws at each
of the four corners of the pager and place them in a safe location.

Step 2

On the top of the pager, by the digital number, use the opener tool to pry the top and bottom of the pager apart. Then
slide the opener tool along both sides to dislodge the top of the pager from the bottom.

Step 3

Once you have the top of the pager removed, undo the two screws above the display to detach the circuit board.
800-321-6221
Page 1 of 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JTECH StaffCall IQ Pager and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HME JTECH StaffCall IQ Pager

Summary of Contents for HME JTECH StaffCall IQ Pager

  • Page 1 StaffCall IQ Pager Battery Replacement Instructions Tools: Phillips Head Screwdriver & Blue Opener Tool Step 1 Place the pager on a table and then flip it over so that the display is facing down. After, remove the four screws at each of the four corners of the pager and place them in a safe location.
  • Page 2 StaffCall IQ Pager Step 4 Do not pull the circuit board away from the pager case until you have detached the battery. After removing the two screws, slowly pull up the circuit board. Detach the white connector going from the battery wires to the circuit board. Ensure that the pagers side button does not fall out.
  • Page 3 StaffCall IQ Pager Step 7 Before replacing the circuit board in the pager, make sure that the side button is still in the side of the pager. If not, place it back in the proper location. Be sure to also confirm that the contacts are still connected to the bottom of the circuit board.
  • Page 4 StaffCall IQ Pager Step 9 Replace the two screws that hold the circuit board in place. Press the side button to make sure that it is working properly. If working, the display will light up. Step 10 Replace the top cover. Then flip the pager over and replace the four screws on the back of the pager. 800-321-6221 Page 4 of 4...
