- Page 1 Carrier VFD Quick Reference Instruction Manual D2-3466-2...
- Page 2 The information in this manual is subject to change without notice. Throughout this manual, the following notes are used to alert you to safety considerations: ATTENTION: Identifies information about practices or circumstances that can lead to personal injury or death, property damage, or economic loss. Important: Identifies information that is critical for successful application and understanding of the product.
- Page 3 ATTENTION: When the level-sense start feature is enabled (P.054 = ON), the user must ensure that automatic start up of the driven equipment will not cause injury to operating personnel or damage to the driven equipment. In addition, the user is responsible for providing suitable audible or visual alarms or other devices to indicate that this function is enabled and the drive may start at any moment.
- Page 4 Overcurrent or excess heating of the motor could result if this is not done. Failure to observe this precaution could result in damage to, or destruction of, the equipment. The following ATTENTION statements do not apply to the default Carrier VFD configuration. However, they do apply to the Reliance LiquiFlo AC Power Module.
- Page 5 Failure to observe this precaution could result in bodily injury. ATTENTION: Carrier Frequency (P.047) and Current Limit (P.005) must be set correctly before activating the identification procedure (H.020) to avoid motor overloading and/or overheating.
-
Page 7: Table Of Contents
500 Amp and 643 Amp 19XRV Drive Wiring Diagrams ... 2-14 Chapter 3 Using the Keypad/Display to Program, Monitor, and Control the Drive...3-1 Chapter 4 Identifying Parameter Defaults For Carrier Drives...4-1 Chapter 5 Verifying the Installation ..5-1 Chapter 6 Troubleshooting the Drive Test Equipment Needed To Troubleshoot... - Page 8 Carrier VFD Quick Reference...
-
Page 9: Using This Manual
The Carrier VFD Quick Reference is intended for qualified Carrier service personnel, and is to be used during start up, operation, and maintenance of the variable speed drive. 1.1 Required Publications The Carrier VFD Quick Reference must be used with the following manuals: •... - Page 10 Carrier VFD Quick Reference...
-
Page 11: Identifying Drive Components Using Reference Drawings And Parts Lists
HAPTER Identifying Drive Components Using Reference Drawings and Parts Lists Replace with 2.fm (11 X 17 Z-fold) Identifying Drive Components Using Reference Drawings and Parts Lists... - Page 12 Carrier VFD Quick Reference...
-
Page 13: Using The Keypad/Display To Program, Monitor, And Control The Drive
Using the Keypad/Display to Program, If you are unfamiliar with the detailed operation of the keypad/display, refer to chapter 3 of the LiquiFlo Software Start-Up and Reference Manual (D2-3410). Using the Keypad/Display to Program, Monitor, and Control the Drive Monitor, and Control the Drive Display P .--- SPEED... - Page 14 Carrier VFD Quick Reference...
-
Page 15: Identifying Parameter Defaults For Carrier Drives
Use the following table to identify and set the parameter defaults for Carrier drives. Important: Parameter No. P.000 P.001 P.002 P.003 P.004 P.005 P.009 P.010 P.011 P.013 P.027 P.028 P.043 P.044 P.052 H.000 H.001 H.002 H.021 H.022 r.001 r.002 r.003 r.035... - Page 16 Carrier VFD Quick Reference...
-
Page 17: Verifying The Installation
1. Chiller Serial Number: 2. VFD Part Number: 3. VFD Serial Number: 4. Motor Rated Load Amps: 5. Incoming Voltage: 6. Incoming Frequency: 7. Carrier Part Number and Revision: 8. ICVC Software Number: Verifying the Installation HAPTER Verifying the Installation... - Page 18 Carrier VFD Quick Reference...
-
Page 19: Troubleshooting The Drive
This chapter describes how to troubleshoot the drive and the equipment that is needed to do so. 6.1 Test Equipment Needed To Troubleshoot An isolated multimeter will be needed to measure DC bus voltage and to make resistance checks. Note that dedicated troubleshooting test points are not provided. 6.2 Verifying That DC Bus Capacitors Are Discharged The drive’s DC bus capacitors retain hazardous voltages after input power has been disconnected. - Page 20 Initial DC Bus Measurement Points Figure 6.1 – DC Bus Voltage Terminals (414 Amp Drives) Carrier VFD Quick Reference...
- Page 21 Initial DC Bus Measurement Points Figure 6.2 – DC Bus Voltage Terminals (500 Amp and 643 Amp Drives) Troubleshooting the Drive...
-
Page 22: Checking The Power Modules And Motor With Input Power Off
DC bus capacitors are discharged before touching any internal components. Failure to observe this precaution could result in severe bodily injury or loss of life. ensure that the DC bus capacitors are discharged. IGBTs. See table 6.1. Carrier VFD Quick Reference... - Page 23 Input Diode * (+) DC Bus Volts power terminal ** (-) DC Bus Volts power terminal IGBT * (+) DC Bus Volts power terminal ** (-) DC Bus Volts power terminal Troubleshooting the Drive Table 6.1 – Resistance Checks Meter Connection Component is OK if resistance (R) is:...
-
Page 24: Troubleshooting The Drive Using Error Codes
P.030 (Elapsed Time Meter Reset). All entries in the error log and the day and time data are retained if power is lost. Refer to section 6.4.3 for the procedure for accessing and clearing the error log using the keypad. Carrier VFD Quick Reference... -
Page 25: Identifying Alarm Codes And Recovering
6.4.1 Identifying Alarm Codes and Recovering Drive alarm codes are shown in table 6.2. Note that the alarm code will only be displayed for as long as the problem exists. Once the problem has been corrected, the alarm code will disappear from the display. Alarm Code Description... -
Page 26: Identifying Fault Codes And Recovering
Check U.006. Incorrect magnetizing current may be generated by performing self-tuning with a load connected to the motor. Check external interlocks at terminals 16, 20. See H.019 for identification result. Check actual line voltage against U.018 or H.021. Carrier VFD Quick Reference... - Page 27 Fault Code Description High DC bus DC bus voltage too high (capacitor voltage protection). Deceleration time too short. Input phase loss Voltage ripple on DC bus due to missing input phase or an imbalance between phases. Low DC bus DC bus voltage too low. Line dip too voltage long (P.042).
- Page 28 Power Module. Power Module must be configured by Reliance service personnel. Check load to Power Module. Check Power Module sizing versus application. Check DC Braking Current value (H.007). Check Torque Boost (H.003). See parameter U.009 Carrier VFD Quick Reference...
-
Page 29: Accessing, Reading, And Clearing The Faults In The Error Log
Fault Code Description Communication Serial port communication cable, PC loss between or OIM communication port setup. Regulator/PC/OIM Spurious host PC Regulator board failure. comm interrupt Asymmetrical bus One of 3 differnet faults has occurred; fault. Look at the 3 1. Input Ground Fault - Excessive LEDs on the Power current flowing bwtween any of the Module Interface... - Page 30 If more than one fault has ocurred, the first entry is the latest fault that occurred. The display shows the day stamp, which can range from 0 to 248 days. Carrier VFD Quick Reference...
- Page 31 Step 6. Press the ▼ key. Step 7. Press the PROGRAM key, which displays the error log entries again.The Step 8. Repeat steps 4 though 7 for each additional error log entry to view the time Step 9. When you have viewed all the entries, you should clear the error log. Press Step 10.
-
Page 32: Identifying Fatal Fault Codes And Recovering
If intermittent, check for causes of noise, for proper grounding, and that outputs are not exceeding rated current capacities. Replace the option board if necessary. Refer to the appropriate option board instruction manual for more information about the option board. Carrier VFD Quick Reference... -
Page 33: Indentifying Pmc Board Fault Codes And Recovering
6.6 Indentifying PMC Board Fault Codes and Recovering Table 6.5 lists PMC board fault codes. These faults can be identified using the three LEDs located on the Regulator board. Status of LEDs 1-3 LEDs 1-3 all on. LEDs 1-3 all off. LEDs 1-3 flash in a 3-flash sequence. - Page 34 If PUCH is displayed, wait for 0 to display. The procedure is complete. If P.999 is displayed, continue with step 21. code appears. The codes are as follows: Model Amps Code Number 41LR4060 41.4 50LR4060 50.4 64LR4060 64.4 Carrier VFD Quick Reference...
- Page 35 Rockwell Automation / Reliance Electric Drives Technical Documentation 6040 Ponders Court Greenville, SC 29607 Fax: 864-284-5483 Publication Name: LiquiFlo 1.5 AC Drive, Hardware Reference Version 1.2 Publication Number: D2-3466-2 Comments: Your Name: Company Name: Address: Thank you for your comments.
- Page 38 Publication D2-3466-2 - May 2005 -- Supercedes D2-3466-1 - June 2002 Copyright ©2005 Ro ckwell Automation, Inc. All Rights Reserved. Printed in USA.
