CMD Reach Plus Dual Installation And User Care Manual

Reach Plus Dual
Dimensions
Designed to fit onto desks with 19-30mm
thickness with the included clamp.
Mounting the base to the desk
Use the supplied M8x20mm grub screws in the clamp if more thread is required
Ensure the EVA pad is Place base on desk with
applied to the bottom of recess facing the edge.
the base to protect the Offer up the clamp to
desk surface. the base as shown.
Nylon bush in no lockout Nylon bush in 180° lockout
position position
The nylon bush can be Flip the bush over so
removed, flipped and the protrusion faces
refitted to remove/apply upwards to apply the
the 180° lockout. 180° lockout as shown.
Part No: 134222 Issue No: 004
Add pad to
clamp if
required
Use 4mm Allen key to
tighten the 2x grub
screws in the clamp into
the base.
Place the clamp cover
over the base with the
recess facing the desk
edge. No fixing required.
Installation, user and care guide
Contents
x1 x1
x1 x2
2.5mm 4mm 6mm
x1 x1
Installing the arm and horizontal rail
Use 2.5mm Allen key to Carefully insert the pin
loosen grub screw and at the bottom of the
allow arm assembly to arm assembly into the
drop into base stem. base stem.
Tighten the grub screw Use 4x M5x25mm bolts
to secure the arm to fix the handle and
assembly to the base. horizontal rail to the
Do not overtighten. head of the arm.
Installing monitors
(max width of 635mm/25" per monitor)
Fix quick release VESA Align the raised square
in place with supplied section on the VESA
fixings. 4x M4x12/16mm with the recess on the
CSK pozi screws. rail mount.
To remove the monitors, Depress the lever at
start by disconnecting the top of the VESA to
any cables. release it from the rail
mount. Lift up monitor.
x1 x1 x1
8x M4x12
x2 8x M4X16 4x M5x25
8mm
x1 x1
If 180° lockout is
required, ensure bush
protrusion sits in recess
at bottom of the arm.
The rail is now fully
assembled and ready
for the monitors to be
installed.
'CLICK'
Lower the monitor onto
the rail mount until it
clicks into place. Repeat
for the second monitor.
The arm may try to
spring up as the weight
is removed. Guide the
arm to prevent this.
x1
2x M8X20
