CMD Reach and Reach Information And Instruction Sheet

Reach and Reach
This stylish monitor arm, arguably one of the slimmest of its type on the market today, is available in silver, black and
white and comes complete with quick release VESA, Top Fixing C clamp, Split Fixing C clamp, Through Desk Fixing
and Rail Fixing as standard. The arm tension can be adjusted quickly using a simple Allen key system to support
monitors ranging between 2-5kgs and 3-9kgs, which covers most popular brands.
Dimensions
313mm
Height (centre)
188~440mm (+0/-5)
Reach and Reach HD Top Fixing Clamp
CMD Ltd, Sycamore Road, Eastwood Trading Estate, Rotherham, S65 1EN
T: 01709 829 511 | F: 01709 378 380 | E: enquiries@cmd-ltd.com | W: www.cmd-ltd.com
Part Number 133813 Issue 5 Date: 30/07/18
- Information and Instruction Sheet
HD
498mm
185mm
31~41mm
Main features
1. Choice of silver, black or white.
Reach supports monitors up to 2-5kgs and
Reach
HD
2. Available as a single and double arm.
3. Includes Top Fixing C clamp, Split Fixing C clamp,
Through Desk Fixing and Rail Fixing as standard.
4. Comes with quick release VESA (black).
5. Fits a range of desk thicknesses from 10-40mm
depending on the type of fixing required.
6. Includes cable management to secure cables to
upper and lower arm sections.
313mm
Height (centre)
188~440mm (+0/-5)
54mm
Reach and Reach
supports monitors 3-9kgs.
498mm
185mm
46~95mm
HD Split Fixing Clamp
86mm
