Appendix C Technical Specifications

EN
grid
Continuous output power at 40 °C (P nom)
AC output current
AC output voltage (nominal)
AC output range
Protection
Standby losses
User interface
Connectivity
Backup switch over time
Solar
Max. Input
No. of strings
No. of MPP trackers
DC Disconnection switch
Solar Voltage
MPP Voltage
Solar Connections
Max. Efficiency
Max. MPP Efficiency
Battery
Output charge current
Battery types
Battery voltage output range (Vout)
Battery capacity
Charging curve
Short circuit protection
Multipurpose relay
Battery temperature compensation
Battery voltage sense
Current shunt
Environmental
Operating Temperature Range (full power)
Storage Temperature
Humidity
Regulatory Approvals and Standards
Safety
Emission
Immunity
Anti Islanding Protection
Warranty
general
Dimensions (WxHxD)
Protection Category
Weight
Topology
Cooling
18
PR50SB-BU PR37SB-BU
5000 W (4600 W DE) 3700 W
22A 16A
230 Vac ± 2%, 50 Hz ± 0.2%, true sine wave <3% THD, single phase
180-264 Vac 45-55 Hz (limited by local anti-islanding regulations)
electronic, fused
≤ 6W
interactive display with 4-button operation
ethernet RJ45, TCP/IP
<1 second
PR50SB-BU PR37SB-BU
5.5 kWp and 15 A per string 4 kWp and 15 A per string 3.3 kWp 15 A
2 2
2, fully independent 2, fully independent
4-pole, 600V, 15A 4-pole, 600V, 15A
150 – 600 Vdc per string
100 – 480 Vdc per string
MC4
94.5%
99.9%
PR50SB-BU PR37SB-BU
25 - 200 A continuous, 25 - 155 A continuous,
programmable programmable
Gel, AGM, NiCd, Li-ion
18 – 32 Vdc
min. 100 Ah, at 25A charge current
float or 3-stage adaptive with maintenance
electronic, at max. charge current, switch off <1 sec
2 (NO/NC, 250 Vac, 1 A, 24 Vdc, 5 A)
included
included
included
PR50SB-BU PR37SB-BU
-10 °C to +50 °C (derating from 40 °C)
-40 °C to +70 °C
maximum 95%, non-condensing
CE
EN 60950-1, EN 62109-1, EN 60335-2-29
EN 55014-1, EN 61000-3-2, EN 61000-3-3, EN 61000-6-3
EN 55014-2, EN 61000-6-2
VDE 0126.1.1, G83/1(UK), RD1663/2000(ESP), DK5940 E.d. 2.2 (IT), AS4777(AUS)
(check www.PowerRouter.com for other country certifications)
five years (optional: extension to ten years)
PR50SB-BU PR37SB-BU
765 x 502 x 149 mm
IP 21
20.5 kg
galvanic isolated transformer
forced airflow
PR30SB-BU
3000 W
13A
PR30SB-BU
1
1
2-pole, 600V, 15A
PR30SB-BU
25 - 125 A continuous,
programmable
PR30SB-BU
PR30SB-BU
