- Page 1 Original instructions PAEC2500 ..10 ..13 ..15 ..18 ..21 ..24 ..27 ..30 ..33 ..36 ..40 ..43...
- Page 2 PAEC2500 The introduction pages consist mainly of pictures. For translation of the English texts used, see the respective language pages. Introduktionssidorna består huvudsakligen av bilder. För översättning av de engelska texter som används, se respektive språksidor. Introduksjonssidene består hovedsakelig av bilder. For oversettelse av de engelske tekstene, se de respektive språksidene.
- Page 3 PAEC2500 1026 / 1536 / 2026 1050 / 1560 / 2050 90,5 min 500 min 500 min 500 Fig. 1...
- Page 4 PAEC2500 Fig. 2: Stepless regulation of airflow. Internal potentiometer (accessible through the outlet grille). TX20 Fig.3: Open the unit.
- Page 5 PAEC2500 Mounting with wall brackets ø8 (3x) ø5 ø10 PAEC2510 2 pcs PAEC2515 2 pcs Fig. 4: Mounting with wall brackets 3 pcs PAEC2520...
- Page 6 PAEC2500 Accessories PA34TR PA2P PA2PF PAMP10 FCDC AGB304 Item Type Consists of Dimension number PA34TR15* 18056 PAEC2510, PAEC2515 4 pcs 18057 PA34TR20* PAEC2520 6 pcs PA2P15* 19568 PAEC2510, PAEC2515 2 pcs 19569 PA2P20* PAEC2520 3 pcs PA2PF15* 19415 PAEC2510, PAEC2515 4 pcs 19417 PA2PF20*...
- Page 7 PAEC2500 Stepless airflow control 6 5 4 PE N 2 1 A White / Tach Red / +10 V L N PE L N PE Yellow / 0-10 V PWM Blue / GND White White Yellow Yellow Blue Blue PAEC2520A PAEC2510A/PAEC2515A Stepless airflow control with external potentiometer 6 5 4...
- Page 8 PAEC2500 Stepless airflow control with door contact / position limit switch 6 5 4 PE N 2 1 A Us / +10 V + / 0 -10 V out - / GND PAMP Com No Nc White / Tach FCDC Red / +10 V L N PE L N PE...
- Page 9 PAEC2500 1 Ambient, no heat - PAEC2500 A (IP44) Item Type Output Airflow Sound Sound Voltage Amperage Length Weight number power* pressure* motor motor* [kW] [dB(A)] [dB(A)] [mm] [kg] 84620 PAEC2510A 1400 33/53 230V~ 0,15/0,80 1050 PAEC2515A 84621 2100 37/55 230V~ 0,20/0,90 1560...
-
Page 10: General Instructions
PAEC2500 Installation and operating instructions General Instructions 3. Bend the top of the console over the the unit and slide the units screws along the rail into Read these instructions carefully prior to the slots on the consoles. (Fig.4C) When the installation and use. -
Page 11: Maintenance
PAEC2500 speaking, the higher the load, the greater the control system. angle required. • That the intake grille/filter is not dirty. Basic setting fan speed If the fault cannot be rectified, please contact a qualified service technician. The fan speed when the door is open is set using the control. - Page 12 Main offi ce Frico AB Tel: +46 31 336 86 00 Industrivägen 41 SE-433 61 Sävedalen mailbox@frico.se Sweden www.frico.net For latest updated information and information about your local contact: www.frico.net...
