Delphi NE Series Non-Isolated Point of Load
DC/DC Modules:
3.1~13.8Vin, 0.59V-5.1Vout, 6Aout
The Delphi NE 6A Series, 3.1~13.8V wide input, wide trim single
output, non-isolated point of load (POL) DC/DC converters are the
latest offering from a world leader in power systems technology and
manufacturing — Delta Electronics, Inc. The NE product family is
the second generation, non-isolated point-of-load DC/DC power
modules which cut the module size by almost 50% in most of the
cases compared to the first generation NC series POL modules. The
NE 6A product family provides an ultra wide input range to support
3.3V, 5V, 8V, 9.6V, and 12V bus voltage point-of-load applications and
it offers up to 6A of output current in a vertically or horizontally
mounted through-hole miniature package and the output can be
resistor trimmed from 0.59Vdc to 5.1Vdc. It provides a very cost
effective, high efficiency, and high density point of load solution. With
creative
design
technology
placement, these converters possess outstanding electrical and
thermal performance, as well as extremely high reliability under highly
stressful operating conditions.
DATASHEET
DS_NE12S06A_06302008
and
optimization
of
component
FEATURES
High Efficiency: 94.5% @ 12Vin, 5V/6A out
Size: Vertical :
10.4mm x 16.5mm x 11.0 mm
(0.41" × 0.65" × 0.43")
Horizontal:
10.4mm x 16.5mm x 11.5 mm
(0.41" × 0.65" × 0.45")
Wide input range: 3.1V~13.8V
Output voltage programmable from
0.59Vdc to 5.1Vdc via external resistors
No minimum load required
Fixed frequency operation
Input UVLO, output OCP
Remote ON/OFF (Positive, 5 pin version)
ISO 9001, TL 9000, ISO 14001, QS9000,
OHSAS18001 certified manufacturing facility
UL/cUL 60950-1 (US & Canada)
Recognized, and TUV (EN60950-1) Certified
CE mark meets 73/23/EEC and 93/68/EEC
directives
OPTIONS
Vertical or horizontal versions
APPLICATIONS
DataCom
Distributed power architectures
Servers and workstations
LAN/WAN applications
Data processing applications
Advertisement
Table of Contents
Related Manuals for Delta Electronics Delphi 6A Series
Summary of Contents for Delta Electronics Delphi 6A Series
- Page 1 (POL) DC/DC converters are the latest offering from a world leader in power systems technology and manufacturing — Delta Electronics, Inc. The NE product family is the second generation, non-isolated point-of-load DC/DC power modules which cut the module size by almost 50% in most of the cases compared to the first generation NC series POL modules.
-
Page 2: Technical Specifications
TECHNICAL SPECIFICATIONS (Ambient Temperature=25°C, minimum airflow=200LFM, nominal V PARAMETER ABSOLUTE MAXIMUM RATINGS Input Voltage Operating Temperature (Vertical) Operating Temperature (Horizontal) Storage Temperature INPUT CHARACTERISTICS Operating Input Voltage Input Under-Voltage Lockout Turn-On Voltage Threshold Turn-Off Voltage Threshold Lockout Hysteresis Voltage Maximum Input Current No-Load Input Current Off Converter Input Current Input Reflected-Ripple Current... - Page 3 ELECTRICAL CHARACTERISTICS CURVE Figure 1: Converter efficiency vs. output current (0.59V output voltage, 12V input voltage) Figure 3: Converter efficiency vs. output current (1.8V output voltage, 12V input voltage) Figure 5: Converter efficiency vs. output current (3.3V output voltage, 12V input voltage) DS_NE12S06A_06302008 Figure 2: Converter efficiency vs.
- Page 4 ELECTRICAL CHARACTERISTICS CURVES (CON.) Figure 7: Output ripple & noise at 12Vin, 0.59V/6A out Figure 9: Output ripple & noise at 12Vin, 1.8V/6A out Figure 11: Output ripple & noise at 12Vin, 3.3V/6A out DS_NE12S06A_06302008 Figure 8: Output ripple & noise at 12Vin, 0.9V/6A out Figure 10: Output ripple &...
- Page 5 ELECTRICAL CHARACTERISTICS CURVES (CON.) Figure 13: Turn on delay time at 12Vin, 1.0V/6A out Ch1: Vin Ch4: Vout Figure 15: Turn on delay time at 12Vin, 2.5V/6A out Ch1: Vin Ch4: Vout Figure 17: Typical transient response to step load change at 10A/μS from 50%~100% load, at 12Vin, 2.5V out DS_NE12S06A_06302008 Figure 14: Turn on delay time Remote On/Off, 1.5V/6A out...
-
Page 6: Design Considerations
DESIGN CONSIDERATIONS The NE12S0A0V(H)06 uses a single phase and voltage mode controlled buck topology. The output can be trimmed from 0.59Vdc to 5.1Vdc by a resistor from Trim pin to Ground. The converter can be turned ON/OFF by remote control with positive on/off (ENABLE pin) logic. -
Page 7: Output Voltage Programming
FEATURES DESCRIPTIONS (CON.) The ENABLE input can be driven in a variety of ways as shown in Figures 18 and 19. If the ENABLE signal comes from the primary side of the circuit, the ENABLE can be driven through either a bipolar signal transistor (Figure 19).If the enable signal comes from the secondary side, then an opto-coupler or other isolation devices must be used to bring the signal across the voltage isolation... -
Page 8: Output Capacitance
FEATURES DESCRIPTIONS (CON.) Voltage Margining Adjustment Output voltage margin adjusting can be implemented in the NE modules by connecting a resistor, R the Trim pin to the Ground for margining up the output voltage. Also, the output voltage can be adjusted lower by connecting a resistor, R , from the Trim pin to margin-down... -
Page 9: Thermal Consideration
THERMAL CONSIDERATION Thermal management is an important part of the system design. To ensure proper, reliable operation, sufficient cooling of the power module is needed over the entire temperature range of the module. Convection cooling is usually the dominant mode of heat transfer. Hence, the choice of equipment to characterize the thermal performance of the power module is a wind tunnel. - Page 10 THERMAL CURVES (VERTICAL) NE12S0A0V06(standard) Output Current vs. Ambient Temperature and Air Velocity Output Current (A) @Vin=12V Vout=5.0V (Either Orientation) Natural Convection 100LFM 200LFM 300LFM 400LFM 500LFM 600LFM Figure 29: Output current vs. ambient temperature and air velocity @Vin=12V, Vout=5.0V (Either Orientation) NE12S0A0V06(standard) Output Current vs.
- Page 11 THERMAL CURVES (HORIZONTAL) Figure 34: Temperature measurement location* The allowed maximum hot spot temperature is defined at 118 NE12S0A0H06(standard) Output Current vs. Ambient Temperature and Air Velocity Output Current (A) @Vin=12V Vout=0.9V (Either Orientation) Natural Convection 100LFM 200LFM 300LFM 400LFM 500LFM Figure 35: Output current vs.
- Page 12 THERMAL CURVES (HORIZONTAL) NE12S0A0H06(standard) Output Current vs. Ambient Temperature and Air Velocity Output Current (A) @Vin=3.3V Vout=0.9V (Either Orientation) Figure 40: Output current vs. ambient temperature and air velocity @Vin=3.3V, Vout=0.9V (Either Orientation) NE12S0A0H06(standard) Output Current vs. Ambient Temperature and Air Velocity Output Current (A) @Vin=3.3V Vout=2.5V (Either Orientation) Figure 41: Output current vs.
-
Page 13: Mechanical Drawing
MECHANICAL DRAWING VERTICAL HORIZONTAL DS_NE12S06A_06302008... -
Page 14: Part Numbering System
PART NUMBERING SYSTEM Product Input Number of Series Voltage outputs 12- 3.1~13.8V S- Single output 0A0 - Non-isolated Series MODEL LIST Model Name Packaging NE12S0A0V06PNFA Vertical NE12S0A0H06PNFA Horizontal CONTACT: www.delta.com.tw/dcdc USA: Telephone: East Coast: (888) 335 8201 West Coast: (888) 335 8208 Fax: (978) 656 3964 Email: DCDC@delta-corp.com...
