Page 1: Table Of Contents
Table of Contents GETTING STARTED AFETY RECAUTIONS ACKAGE ONTENT MAIN UNIT VIEWS GETTING STARTED ARDWARE NSTALLATION AMING OFTWARE NSTALLATION BASIC OPERATIONS IRECTION HEEL UTTON DPI S ETTINGS AMING ETTINGS ROGRAMMABLE UTTONS DJUSTABLE UTTON NTERCHANGEABLE UBBER INGER DJUSTING EIGHT USING GAMING SOFTWARE UTTON ETTINGS ACRO... - Page 2 Warning : This mark indicates actions that could lead to serious injury to personnel operating the device or damage to the device if ignored or handled incorrectly. WARNING: The device complies with IEC 60825-1 Class 1 laser product and emits laser radiation during operation. Do NOT stare into laser beam directly.
-
Page 3: Getting Started
Getting Started Thank you for purchasing Prestigio Gaming Mouse PMSG1, an ultimate gaming mouse designed for extreme gaming experience. You have made an excellent choice and we hope you will enjoy all of its exciting features. Please read through the user manual carefully before using the product, and follow all of the procedures in the manual to fully enjoy all features of the product. -
Page 4: Package Content
1.2 Package Content Item Image Description Quantity Gaming Mouse Main Unit Rubber Finger Grip Weight Box / Weigh Pieces(6) Driver and Documentation CD Quick Guide Warranty Card... -
Page 5: Main Unit Views
Main Unit Views 4-Direction Mode Display LED/ Wheel Button DPI Display LED Lift Adjusting Button Mode Switching Button Changeable DPI Switch Finger Grip Internet Forward Internet Backward Button Button LED Lighting Finger Grip LED Lighting Release Button... -
Page 6: Getting Started
Getting Started 3.1 Hardware Installation Turn on PC or notebook. Insert USB connector into any of the USB port on PC or notebook. Device will be automatically installed in a few seconds. System reboot may be required upon system request. The device now is ready for use. - Page 7 Check/uncheck on the options and click on Next to continue or Cancel to exit installation. Click on Browse to select or type in desired installation path. Click on Install to continue, Back to previous page or Cancel to exit installation. Press Close to complete installation when prompted.
-
Page 8: Basic Operations
Basic Operations 4.1 4-Direction Wheel Button Vertical Scrolling: Roll 4-Direction Wheel Button up/down to scroll page up/down. Horizontal Scrolling: Tilt 4-Direction Wheel Button left/right to scroll page left/right. 4-Direction Wheel Button can also be assigned to Macro functions. Please refer to sections below for more detailed instructions. -
Page 9: Gaming Mode Settings
4.3 Gaming Mode Settings Press Mode Switching Button to toggle between 7 different gaming modes. Current gaming is displayed on Mode display LED. Each Mode is represented by a different color on the display. LED on the front and rear ends of device will also be displaying color in accordance to mode change. -
Page 10: Adjustable Lift Button
4.5 Adjustable Lift Button Please select a surface the device will be working with. Press and hold Lift Adjusting Button and quickly move device on the surface for up to 3 seconds. The DPI Display LED will be blinking during the process. Release the button when DPI Display LED stops blinking. -
Page 11: Adjusting Weight
4.7 Adjusting Weight Release Finger Grip as shown in the above section. Press Weight Cartridge Release Button to release weight cartridge. Add/Remove Weight Piece(s) in the cartridge as desired. Unused Weight Piece(s) can be stored in the Weight Box. Warning Please keep Weight Pieces from reach of children. -
Page 12: Using Gaming Software
Using Gaming Software Upon successful installation of Gaming Software, click on Gaming Software icon located at Windows Notification Area or click on Start Programs Gaming Mouse Gaming Mouse to start the application. 5.1 Button Settings Profile Management A total of 7 Profiles is available for storing Scripts. Each Profile represents a customized gaming button setting group and is capable of storing up to 9 different buttons assigned with Scripts. - Page 13 Button Assignment Press Mode Button to cycle through 7 Modes or click on desired mode to select it. Click on, hold, and drag the user-predefined Script from Macro List to 1 of 9 buttons to complete button assignment. Click on, hold, and release the already assigned button anywhere other than the button itself to discard assignment.
-
Page 14: Macro Settings
5.2 Macro Settings Macro List Window User-defined Macros are stored in Macro List. Macro functions can be organized into different Groups with user-defined names. To create a new Group, click on Add a new folder icon and type in desired character strings (up to 28 alphanumerical characters) in the text box. - Page 15 Macro Editor Window Macro Editor allows user to record/define Commands, collect them into one single Script, and store the Script as Macro function in the Macro List for button assignment. Please follow below procedures to edit Macro: Double-click response type to cycle through from (Commands are executed once), (Commands are executed repeatedly, and...
- Page 16 Click on, hold, and drag the Commands from Macro Editor window to to delete Commands. Edited Commands can be saved onto host PC or loaded into Gaming Software for later use. Simply click on to save Commands in *.inf file or click on to restore Commands from file.
- Page 17 Insert Click-Mouse-Button Command: Click on, hold, and drag the icon to Macro Editor window to insert mouse-button-click command. Click on a mouse button to assign a mouse button clicked. Insert Release-Mouse-Button Command: Click on, hold, and drag the icon to Macro Editor window to insert mouse-button-release command.
-
Page 18: Macro Settings
5.3 Macro Settings DPI Adjustment The device is capable of 4 level DPI resolution adjustment from 90 DPI to 5040 DPI where X-axis and Y-axis resolution can be adjusted independently from each other. Click on the corresponding number or push DPI Switch forward/backward to locate desired DPI level for adjustment. -
Page 19: Appendix
We make every effort to ensure that the information and procedures in this user manual are accurate and complete. No liability can and will be accepted for any erros or omissions. Prestigio reserves the right to make any changes without further notice to any products herein.
