auris audifi Quick Start Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Quick Start Guide
audifi

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the audifi and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for auris audifi

Summary of Contents for auris audifi

  • Page 1 Quick Start Guide audifi...

  • Page 3: Table Of Contents

    8.2.1 Connecting audifi to your stereo system ........................7 8.2.2 Option 1 - Connecting audifi via WiFi ...........................7 8.2.3 Option 2 - Connecting audifi via LAN ........................10 8.2.4 Option 3 - Connecting audifi via Bluetooth ......................10 8.4 App Features ....................................11 8.3.1 Device settings ..................................11...

  • Page 4: Introduction

    1. Introduction The auris audifi is a WiFi music streamer that works with any amplifier or active speakers to unlock and discover a world full of music streaming services and internet radio stations, all streaming in 24-bit Hi-Res audio. It can be used as a standalone streamer alongside your preferred amp or grouped with other players to create a multi-room listening experience.

  • Page 5: Main Features

    3. Main Features - Streaming music via network without distance limitation or Bluetooth 5.0 up to 15 meters. - Qualcomm® aptX™ HD for true high resolution music. - Spotify connect, Airplay, Qplay, DLNA, UPnP streaming protocols supported. - Support streaming source from online services, smart device memory, USB pen drive, NAS, Bluetooth and line in.

  • Page 6: Technical Specifications

    4. Technical Specifications WiFi IEEE 802.11 b/g/n (2.4GHz) Ethernet Single 10/100M RJ45 Connectivity Bluetooth Bluetooth 5.0 with Qualcomm® aptX™ HD, AAC ans SBC USB Host For USB pen drive/stick, 1024 songs limited Streaming Protocols AirPlay, DLNA, UPnP, Spotify connect D/A Converter ESS SABRE ES9023 DAC Frequency Response 20Hz to 20kHz...

  • Page 7: Interface

    5. Interface LED: To show the device status. Display Panel: Display status info. IR receiver: Infrared sensor for remote control. Trigger Out: 12V trigger output used to control or activate other external devices. Reset Button: Short press to reset the device WiFi, long press to restore the device to factory setting (only works in WiFi mode).

  • Page 8: Remote Control

    6. Remote Control...

  • Page 9: Connection Diagram

    Download and install the free 4STREAM app from the Apple App Store for iOS or from Google Play for Android. This is what you will need to set up and configure audifi. No need to open this app yet as we first need to connect audifi to your music system. Google Play...

  • Page 10: Connection

    5. The audifi display will show “Loading” and in a few seconds a piano tone will play through your music system. 6. The audifi display will then show “Waiting for connection” followed by a voice prompt that will say: “Entering setup mode.
  • Page 11 4. Open the installed 4STREAM app onto your iOS or Android device. In the app, you will see the audifi device “SoundSystem_XXXX” in the device list. Select the "+" icon at the top right corner of the screen.
  • Page 12 7. Rename your audifi device if you wish to, then select the right arrow at the top of the screen. 8. Go to the browse section in the app and enjoy streaming your favorite tracks to your stereo system. *Attention for Android users.

  • Page 13: Option 2 - Connecting Audifi Via Lan

    1. To setup audifi using the LAN port, a wired Ethernet connection is required. Connect one end of the Ethernet cable to the LAN port of your Ethernet broadband router and the other end to the audifi's LAN port. The device will show on the app in about 10 seconds.

  • Page 14: App Features

    8.3 App Features 8.3.1 Device Settings Rename: Change the device name. Speaker info: Display device information like IP address, SSID, firmware version, factory reset, etc. Alarm Clock: Setup up to 4 different alarm clocks with music of your choice. Preset Content: 10 Preset content buttons. Sleep Timer: Countdown to turn off the device.

  • Page 15: To Play Music From Nas

    8.3.3 To Play Music From NAS Please note that audifi only supports NAS with DLNA feature. 8.3.4 To Play in Line In Mode - Connect the provided RCA cables to the TV or other audio sources. - Choose Line In mode on the App or remote control.

  • Page 16: To Play In Optical In Mode

    8.3.6 To Play in Optical In Mode - Connect the Optical cable to the audio source - Choose Optical In mode on the application or remote control 8.4 Streaming Services To use the online streaming services like Spotify, Tidal, Qobuz, iHeartRadio, TuneIn and Deezer, you may need to register the account at the service provider platform.

  • Page 17: Spotify Connect

    8.4.1 Spotify Connect audifi supports Spotify Connect, so you can stream music via WiFi directly from the Spotify app. You will find the device in the device list in the Spotify app. Simply choose the device you want to play.

  • Page 18: Multiroom And Multizone

    8.5 Multiroom and Multizone Users can group multiroom and multizone on the App. For example, you can group device 1, 2, 3 and 4 together and play the same music in sync or group device 1 and 2 as zone A and device 3 and 4 as zone B, and play different music in zone A and zone B.

  • Page 19: Preset

    8.7 Preset There are 6 buttons on the remote control, users can preset play lists (only the lists with speaker icon can preset) on the application from 1~6 for example, then when you press button 1 on the remote, the preset list 1 will play.

  • Page 20: Restore Factory Setting

    8.9 Restore Factory Setting Two methods to restore device to factory setting. Method 1 - Quickly press the reset button 3 times to restore factory settings. Method 2 - Go to "App setting → speaker info → restore factory setting". 8.10 Firmware Update The application will notify you when there is a new firmware version available.

  • Page 21: Play On Pc

    9.1 To play music from iTunes on Mac and Windows PC audifi can stream from your local storage / media library on Mac or Windows PC and online services from iTunes. Users can easily play and switch music, control volume and choose the audio devices to group and upgroup the audio devices.

  • Page 23: To Play Music From Windows Pc Via Musicbee

    9.3 To play music from Windows PC via MusicBee Seamlessly stream music from your Windows PC to audifi with the powerful MusicBee music player. 1. Download the free MusicBee music player from https://www.getmusicbee.com and install it. 2. Download the DLNA/UpnP plugin for the MuiscBee player from https://www.getmusicbee.com/addons/plugins/11/upnp-dlna-device-support/...

  • Page 25: Web Player Interface

    10. Web Player Interface You can access the web player interface by entering the IP address of the device to a web broswer. *The device IP address can be found by clicking on the Devices setup icon, then select Speaker Info. The Web Player allows you to control the Volume, Play/Pause, Previous/Next song, Repeat and Shuffle function for tracks you're currently streaming or access the preset songs/stations you have setup.
  • Page 26 In the setup menu, you can do couple of things: * When entering the setup interface, an admin password is required. The default password is: admin - Manual update the device firmware - Change the Device Name - Setup WiFi connection - Setup Static IP Address - Change Admin password If you want to setup the WiFi connection for the first time without using other method.
  • Page 27 Scan the QR Codes below to explore more 4STREAM app theauris.com Facebook Instagram YouTube If you have any further questions about the operation or use of this product, please contact our customer care team for assistance on support@theauris.com...

  • Page 28: Faq

    A: 12 rooms is the maximum, while 8 zones are recommended. Q: What distance can audifi cover? A: Once audifi is connected to your WiFi router, you can stream your music from wherever there is a WiFi signal. Q: Can it play high resolution music? A: Yes.
  • Page 30 The information contained in this guide is believed to be accurate and reliable. Auris Inc. assumes no responsibility for any errors contained in this guide. Auris Inc. reserves the rights to make changes in the specifications and/or design of the above mentioned product without prior notice.
