C
ONNECTING TO
1. This Converter is a plug-and-play device.
2. Connect the supplied AC to DC power adapter with a power voltage
of 5Vdc/1Amp to the DC-Jack on the converter, and then attach the
plug into a standard AC outlet.
L
D
INK
IAGNOSTICS
LLCF (Link Loss Carry Forward)
When a device connected to the converter and the TP line loss the
link, the converter's fiber will disconnect the link of transmit, so that the
other ends will know that there is a linkage error on this end. And
when the Fiber line loss the link, the converter's TP will disconnected,
and the other end will know that there is linkage problem exist.
There is a default LLCF setting on this converter.
LLR (Link Loss Return)
When a device connected to the converter and the fiber line loss the
link, the converter's fiber will disconnect the link of transmit.
There is a special switch to regulate LLR setting on this converter.
S
S
LIDING
There is a two pin DIP switch on the module, defined as switch 1
and switch 2:
P
OWER
WITCH
1 2
S w i t c h 1 : O n - > F o r c e d M o d e
O f f - > A u t o N e g o t i a t i o n m o d e
S w i t c h 2 : O n - > L L R e n a b l e
O f f - > L L R d i s a b l e
1 2
3
