Infotainment system
INFOTAINMENT SYSTEM
Audio (Without Touch Screen)
System layout
control panel
* The system s actual appearance and layout may differ depending on the
vehicle model and specification.
1. AUDIO button
Press to display the radio/
media mode selection window.
When the mode selection win -
dow displays, turn the [TUNE]
knob to select the desired mode
and then press the knob.
When the Mode popup is not
selected in [MENU/CLOCK] ▶
Mode popup, press the [AUDIO]
button on the control panel to
change the mode.
Each time you press the
[AUDIO] button on the control
panel, the mode switches to
radio ▶ media in order.
Bluetooth Wireless Technology)
(With
Audio (Without Touch Screen)
AU210GYGG AU210GYGN AU210GYGP
AU210GYEG AU210GYEP AU211GYEP
AU212GYGL AU211GYGG AU210GYBB
2. PHONE button
Press to start connecting a
mobile phone via Bluetooth.
After a Bluetooth phone con -
nection is made, press to access
the Bluetooth phone menu.
3. FAV button
While listening to the radio,
press to move to next page of
the preset list.
4. POWER button/VOL knob
Press to turn the system on or off.
Turn to the left or right to
adjust the system sound vol -
ume.
1
AU211GYMG
1
3
Advertisement
Summary of Contents for FCC AU210GYGG
- Page 1 Infotainment system Audio (Without Touch Screen) INFOTAINMENT SYSTEM Audio (Without Touch Screen) AU210GYGG AU210GYGN AU210GYGP System layout control panel AU210GYEG AU210GYEP AU211GYEP AU212GYGL AU211GYGG AU210GYBB AU211GYMG Bluetooth Wireless Technology) (With * The system s actual appearance and layout may differ depending on the vehicle model and specification.
- Page 2 Infotainment system Audio (Without Touch Screen) Bluetooth Wireless Technology) (With * The system s actual appearance and layout may differ depending on the vehicle model and specification. 5. SEEK/TRACK button While searching by turning the knob, press to select the cur - Change the station/track/file.
- Page 3 Infotainment system Audio (Without Touch Screen) System layout steering wheel 3. Volume lever remote control Push up or down to adjust the volume. 4. Up/Down lever (Bluetooth equipped model) Change the station/track/file. * The system s actual appearance While listening to the radio, and layout may differ depending push to listen to the previous/ on the vehicle model and specifi -...
- Page 4 Infotainment system Audio (Without Touch Screen) WARNING WARNING About driving About handling the system Do not operate the system while Do not disassemble or modify the driving. Driving while distracted system. Doing so may result in an may result in a loss of vehicle accident, fire, or electric shock.
- Page 5 Infotainment system Audio (Without Touch Screen) Turning the system on or off CAUTION To turn on the system, start the About handling the system engine. Do not apply excessive force to If you do not want to use the sys - the system.
- Page 6 Infotainment system Audio (Without Touch Screen) Turning the display on or off WARNING To prevent glare, you can turn off the Some functions may be disabled screen. The screen can be turned off for safety reasons while the vehi - only while the system is on.
- Page 7 Infotainment system Radio Numberless items Radio Turn the [TUNE] knob to select the desired item, and then press the Turning on the radio knob. 1. On the control panel, press the [AUDIO] button. 2. When the mode selection window displays, turn the [TUNE] knob to select the desired radio mode and then press the knob.
- Page 8 Infotainment system Radio Sound settings: You can change Mode popup: Set to display mode the settings related to sounds, selection window when the such as location where sound will [AUDIO] button is pressed on the be concentrated and the output control panel.
- Page 9 Infotainment system Radio FM/AM Mode (With RDS) - Equaliser (Tone): Adjust the output level for each sound tone mode. - Speed dependent vol.: Set the volume to be adjusted auto - matically according to your driving speed. 1. Current radio mode 2.
- Page 10 Infotainment system Radio Changing the radio mode 2. When the option selection window displays, turn the [TUNE] knob to 1. On the control panel, press the select Scan, and then press the [AUDIO] button. knob. 2. When the mode selection window The system searches for radio displays, turn the [TUNE] knob to stations with strong radio sig -...
- Page 11 Infotainment system Radio Using the auto save function Saving radio stations You can save your favourite radio You can search for radio stations in stations and listen to them by your area where there is a strong selecting them from the preset list. signal.
-
Page 12: Media Player
Infotainment system Media player Media player When the Mode popup is not selected in [MENU/CLOCK] ▶ Mode popup, press the [AUDIO] Using the media player button on the control panel to You can play music stored in various change the media player. media storage devices, such as USB Each time you press the [AUDIO] storage devices, smartphones. - Page 13 Infotainment system Media player Using the USB mode Sound settings: You can change the settings related to sounds, You can play media files stored in such as location where sound will portable devices, such as USB stor - be concentrated and the output age devices and MP3 players.
- Page 14 Infotainment system Media player Restarting the current playback Song information (Media Display): Select information such as Folder/ On the control panel after the song File or Artist/Title/Album to dis - has played for 2 seconds, press the play when playing MP3 files. [<...
- Page 15 Infotainment system Media player Playing repeatedly CAUTION On the control panel, press the Start the engine of your vehicle [1 RPT] button. The repeat play before connecting a USB device to mode changes each time you press your system. Starting the engine it.
- Page 16 Infotainment system Bluetooth Bluetooth NOTICE When connecting a USB storage Connecting Bluetooth devices device, do not use an extension Bluetooth is a short-range wireless cable. Connect it directly to the networking technology. Via Blue - USB port. If you use a USB hub or tooth, you can connect nearby an extension cable, the device mobile devices wirelessly to send...
- Page 17 Infotainment system Bluetooth Depending on the connected 1. From the control panel, press the Bluetooth device or mobile phone, [PHONE] button, and then select some functions may not be sup - Phone settings ▶ Add new device. ported. If you are pairing a device with If the system is not stable due to your system for the first time, a vehicle-Bluetooth device com -...
- Page 18 Infotainment system Bluetooth Connecting a paired device NOTICE To use a Bluetooth device on your The screen image in this manual is system, connect the paired device an example. Check your system to the system. Your system can screen for the exact vehicle name connect with only one device at a and Bluetooth device name.
- Page 19 Infotainment system Bluetooth Disconnecting a device Using a Bluetooth audio device If you want to stop using a Blue - You can listen to music stored in the tooth device or connect another connected Bluetooth audio device device, disconnect your currently via your vehicle s speakers.
- Page 20 Infotainment system Bluetooth Pausing/Resuming playback - Speed dependent vol.: Set the volume to be adjusted auto - To pause playback, press the [TUNE] matically according to your knob on the control panel. To driving speed. resume playback, press the [TUNE] knob again.
- Page 21 Infotainment system Bluetooth Depending on the connected Blue - Using a Bluetooth phone tooth device or mobile phone, You can use Bluetooth to talk on the some functions may not be sup - phone hands free. View call infor - ported.
- Page 22 Infotainment system Bluetooth Making a call NOTICE If your mobile phone is connected to You cannot access the Phone the system, you can make a call by screen if there is no connected selecting a name from your call his - mobile phone.
- Page 23 Infotainment system Bluetooth Registering the favourites list Press the [MENU/CLOCK] button on the control panel to access the fol - You can more easily use Bluetooth lowing menu options: to talk on the phone hands-free by Add new favourites: Add a fre - registering phone numbers as your quently used phone number to favourites.
- Page 24 Infotainment system Bluetooth Using your call history NOTICE 1. From the Phone screen, turn the Some mobile phones may not [TUNE] knob on the control panel support the download function. to select Call history, and then The call history is accessed only press the knob.
- Page 25 Infotainment system Bluetooth Depending on the system s speci - Using the contacts list fications, some of the down - 1. From the Phone screen, turn the loaded contacts may be lost. [TUNE] knob on the control panel Contacts stored both in the phone to select Contacts, and then press and in the SIM card are down - the knob.
- Page 26 Infotainment system Bluetooth Answering calls Using options during a call When a call comes in, a notification During a call, you will see the call pop-up window of the incoming call screen shown below. Press a button appears on the system screen. to perform the function you want.
- Page 27 Infotainment system System status icons System status icons NOTICE Status icons appear at the top of If the caller information is saved in the screen to display the current your contacts list, the caller s system status. name and phone number will be displayed.
-
Page 28: System Specifications
Infotainment system System specifications Signal strength System specifications Icon Description Signal strength of the mobile phone connected via Supported audio formats Bluetooth Audio file specification - WAVeform audio format NOTICE - MPEG1/2/2.5 Audio Layer3 - Windows Media Audio Ver 7.X/ The battery level displayed on the screen may differ from the bat - Bit rates... - Page 29 Infotainment system System specifications Supported USB storage devices Supported characters for folder/ file names (Unicode support): Byte/Sector: 64 kbyte or less 2,604 Korean characters, 94 Format system: FAT12/16/32 alphanumeric characters, 4,888 (recommended), exFAT/NTFS Chinese characters in common use, 986 special characters NOTICE Maximum number of folders: Operation is guaranteed only for a...
- Page 30 Infotainment system Trademarks Bluetooth Trademarks Bluetooth Power Class 2: -6 to 4 Other trademarks and trade names are those of their respective own - Aerial power: Max 3 mW ers. Frequency range: 2400 to 2483.5 The Bluetooth word mark and logos are registered trademarks Bluetooth patch RAM software owned by Bluetooth SIG, Inc.
- Page 31 FCC Certification This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 32 Infotainment system Declaration of Conformity...
- Page 33 Infotainment system Declaration of Conformity NBTC...
