Leaves bypass
mode
Battery-test is
successful
Battery-test
initiated
Battery is charging
Battery stopped
charging
Battery is
discharging
Battery stopped
discharging
Calibration initiated
Calibration finished
Calibration canceled
Output voltage is
boosted
Output voltage is no
longer be boosted
Output voltage is
bucked
Output voltage is no
longer be bucked
Battery capacity is
normal
Battery Backup is
no longer faulty
Utility power has
restored
Leaves bypass mode and switch to line mode or battery
mode, battery power will be used.
The Battery test was successful, battery power is normal.
The Battery test initiated to verify that battery power can
be provided normally.
The battery starts to charge, the battery capacity will
increase.
The battery stopped charging, the battery capacity will
stop increasing.
The battery is being discharged, the battery capacity will
decrease.
Battery stopped discharging; the battery capacity will
stop decreasing.
Calibration was initiated; the battery runtime will be
evaluated.
Calibration finished, battery power no longer is used.
Calibration was canceled; the battery runtime evaluation
was interrupted.
Output voltage is boosted from a lower level.
Output voltage is normal and the boost will stop.
Output voltage is bucked from a higher level.
Output voltage is normal and the buck will stop.
The battery capacity is normal and no longer critically
low.
The battery backup is no longer faulty and is working
normally.
Utility power has restored, no longer using battery power.
