Summary of Contents for PIKA REbus Beacon
- Page 1 Installation Manual REbus™ Beacon Part of the Pika Energy Island™ M00020-01...
- Page 2 REbus™ Beacon Serial Number: RCP Number:...
- Page 3 All information in this document is subject to copyright and other intellectual property rights of Pika Energy, Inc. This material may not be modified, reproduced or copied, in whole or in part, without the prior written permission of Pika Energy, Inc. and its licensors. Additional information is available upon request.
-
Page 4: Section 1: Introduction
Section 1: Introduction About This Manual This Installation Manual provides instructions for adding the REbus™ Beacon to a Pika Energy Island system. Use these instructions for retrofits or for new installations. If installing Beacon as part of a new Energy Island installation, install and commission all other parts of the system before attempting to use Beacon. -
Page 5: Section 2: Safety Information
WARNING: Electrical installation in Canada shall be done in accordance with all local electrical codes and/or the Canadian Electrical Code. WARNING: Connecting the Pika Energy Island to the electric utility grid must only be done after receiving prior approval from the utility company and installation completed only by qualified personnel/licensed electrician(s). -
Page 6: Section 3: Installing Beacon
Check that all terminals are de-energized before proceeding. Pro Tip: You no longer need the old wiring compartment cover. You can save it as a spare, recycle it, or hang it next to your desk for quick reference! REbus Beacon Installation Manual M00020-01... - Page 7 Install the new wiring compartment cover with Beacon at- tached Pass the ethernet and power cable assembly through the passthrough opening at the top of the cover. Attach the cover using the wiring compartment cover screws. REbus Beacon Installation Manual M00020-01...
- Page 8 Connect the type-A (rectangular shaped) connector to the back right-hand port on the top face of Beacon. Slip the plastic split-ring grommet over the USB cable, then snap it into place in the Power Core cover. REbus Beacon Installation Manual M00020-01...
-
Page 9: Section 4: Commissioning Beacon
Note: Refer to the Islanding Inverter Operation Manual for more information on enabling devices. Navigate to the Ethernet Settings page on the inverter control panel and disable Ethernet. Refer to the Islanding Inverter Installation Manual for more information on enabling and disabling ethernet. REbus Beacon Installation Manual M00020-01... -
Page 10: Section 5: Troubleshooting
If your system requires manual DHCP setup, contact Pika Energy for assistance. Note: Pika Energy does not recommend or support connection to the internet using a wifi bridge or router set up in “bridge” mode. The Islanding Inverter does not communicate reliably through this type of device. - Page 11 Section 5: Troubleshooting REbus Beacon Installation Manual M00020-01...
- Page 12 35 Bradley Drive #1 Westbrook, Maine 04092...
