VeriLock
Security Sensor User's Guide
®
for A-Series and 400 Series Windows and Patio Doors, 200 Series Patio Doors
and Renewal by Andersen
(Includes Sensor Model Numbers: 0106512, 0112785, 0112786, 0113412, 0113696, 0113697,
0114371, 0114372, 0115209 and 0116149)
Andersen
VeriLock
®
®
sensors into A-Series, 400 Series and Renewal by Andersen
Series patio doors. The sensors, when applied to our windows and patio doors, can detect when the product
is open or closed and locked or unlocked when properly configured and maintained with a professionally
installed security system and/or self-monitoring system compatible with Honeywell
sensors can be monitored even when you're not at home. This enables a simplified "check the windows and
doors routine" at bedtime or departure.
With VeriLock sensors, the beauty of Andersen and Renewal by Andersen products is maintained without
unsightly wires, sensors or holes. Plus, the product limited warranty is maintained. Generally, third party
security systems can void the manufacturer's warranty with the installation of sensors and wires on windows
and patio doors.
When properly configured and maintained, VeriLock sensors are designed to:
• Detect whether your Andersen or Renewal by Andersen window or door is open or closed.
• Detect whether your Andersen or Renewal by Andersen window or door is locked or unlocked.
• Communicate changes in Open/Closed and Lock/Unlocked wirelessly in a format recognized by
security systems.
• Monitor sensor battery level and communicate low battery state in a format recognized by security
systems.
• Provide open air wireless coverage of over 500 feet.
For more instructions, visit a nd er sen wi nd ows. co m / co n n ect.
"Honeywell" is a registered trademark of Honeywell International, Inc.
"Andersen" and all other marks where denoted are trademarks of Andersen Corporation. ©2018 Andersen Corporation. All rights reserved.
Printed and effective as of May 2016. Updated January 2018.
Windows
®
security sensors are an innovative security option that integrates wireless security
windows and A-Series, 400 Series and 200
®
5800 controls. VeriLock
®
9142268 B D - 0 0
Revised 02/12/18
Advertisement
Table of Contents
Related Manuals for Andersen Verilock 0106512
Summary of Contents for Andersen Verilock 0106512
-
Page 1: Introduction
For more instructions, visit a nd er sen wi nd ows. co m / co n n ect. “Honeywell” is a registered trademark of Honeywell International, Inc. “Andersen” and all other marks where denoted are trademarks of Andersen Corporation. ©2018 Andersen Corporation. All rights reserved. Printed and effective as of May 2016. Updated January 2018. -
Page 2: Table Of Contents
Tools Needed for Battery Replacement ........................5 400 Series & A-Series Casement, Awning Windows ....................6 Renewal by Andersen Casement, Awning Windows ....................7 400 Series & Renewal by Andersen DB Double-Hung Windows ................8 Renewal by Andersen DG Double-Hung Windows .....................8 A-Series Double-Hung Windows..........................9 Renewal by Andersen Gliding Windows ........................10... -
Page 3: Operating Instructions
(unlocked) center of the unit). A-Series Renewal by Andersen Gliding – To lock the window, first make sure that both window sash are in the closed position. Then rotate each lock handle from the up position to the down position. -
Page 4: Keypad And Control Panel
User’s Guide Locking Windows and Doors (Continued) Hinged Patio Doors Hinged Patio Doors – To lock the patio door, first move the door panel to the closed position, lift door Thumb Turn Latch handle and allow the multi-point locking mechanism to engage at top, middle and bottom. -
Page 5: Battery Information
For 400 Series & A-Series Casement and Awning from children. Window: CR-2025 (1 per window) AVERTISSEME For Renewal by Andersen Casement and Awning Window: CR-2032 (1 per window) Batteries are small parts and, if swallowed, could Lithium Coin Cell Batteries pose a choking hazard to young children. -
Page 6: 400 Series & A-Series Casement, Awning Windows
User’s Guide Battery Replacement Instructions - continued 400 Series & A-Series Casement and Awning Windows 400 Series & A-Series Casement and Awning Windows 1. Move the window lock handle to the center Lock VeriLock position. The sash can be open or closed. Lever Sensor Assembly... -
Page 7: Renewal By Andersen Casement, Awning Windows
Battery Replacement Instructions - continued Renewal by Andersen Casement and Awning Windows Renewal by Andersen Casement and Awning Windows 1. Move the window lock handle on the lower lock to the center position. The sash can be open or closed. -
Page 8: 400 Series & Renewal By Andersen Db Double-Hung Windows
User’s Guide Battery Replacement Instructions - continued 400 Series and Renewal by Andersen DB 400 Series and Renewal by Andersen DB Double-Hung Windows Double-Hung Windows 1. Rotate the lock handle 90 degrees from the locked position and remove both screws. -
Page 9: A-Series Double-Hung Windows
User’s Guide Battery Replacement Instructions - continued A-Series Double-Hung Windows A-Series Double-Hung Windows 1. Remove both screws. Do not remove or lift lock after unscrewing. 2. Remove VeriLock sensor assembly. NOTE: VeriLock sensor assembly 3. Locate the VeriLock sensor battery compartment on is installed on the right lock of the bottom of the VeriLock sensor assembly. -
Page 10: Renewal By Andersen Gliding Windows
User’s Guide Battery Replacement Instructions - continued Renewal by Andersen Gliding Windows Renewal by Andersen Gliding Windows 1. Rotate the lock handle 90 degrees from the locked position and remove both screws. 2. Rotate lock handle an additional 90 degrees to the full unlocked position. -
Page 11: A-Series, 400 Series & 200 Series Hinged Patio Doors
User’s Guide Battery Replacement Instructions - continued A-Series, 400 Series & 200 Series A-Series, 400 Series & 200 Series Hinged Patio Doors Hinged Patio Doors 1. Unlock and open the door panel. Secure the door panel in the open position. Exterior 2. -
Page 12: A-Series, 400 Series & 200 Series Gliding Patio Doors
User’s Guide Battery Replacement Instructions - continued A-Series, 400 Series & 200 Series A-Series, 400 Series & 200 Series Gliding Patio Doors Gliding Patio Doors 1. Unlock and open the door panel. VeriLock 2. Remove latch lever and VeriLock sensor assembly. Sensor Assembly 3. -
Page 13: Troubleshooting
User’s Guide Troubleshooting Frequently Asked Questions Questions Answers Who do I contact for help? For questions regarding your security system or monitoring services, contact your security system dealer. For questions regarding your A-Series, 400 Series windows and doors and 200 Series Doors, go to Help.AndersenWindows.com. -
Page 14: Regulatory Statements
L'exploitation est autorisée aux deux conditions suivantes: (1) I'appareil ne doit pas produire de brouillage; (2) I'utilisateur de I'appareil doit accepter tout brouillage radioélectrique subi, méme si le brouillage est susceptible d'en compromettre le fonctionnement. Changes or modifications not expressly approved by Andersen may void the user's authority to operate the equipment. Limitations... - Page 15 User’s Guide Appendix A: The following is a general guideline for enrolling the Verilock sensors to the control panel. Please consult the control panel manufacturer for specific panel model detailed instructions. Recommendation: Install sensor on window or door before attempting to enroll into monitoring system. 1.
- Page 16 User’s Guide This page has been intentionally left blank. 9142268...
